@altara/ros

ROS2 rosbridge adapter for Altara. Subscribe to a ROS2 topic from React in one line and pipe live samples (IMU, GPS, battery, range, temperature, ...) into any @altara/core component. Built for robotics dashboards, drone ground stations, and rover monitoring UIs.

Install

npm install @altara/core @altara/ros

You'll also need rosbridge_suite running on your robot (or in a Docker container during development):

ros2 launch rosbridge_server rosbridge_websocket_launch.xml
# → ws://localhost:9090

Quick start

import { AltaraProvider, TimeSeries } from '@altara/core';
import { createRosbridgeAdapter } from '@altara/ros';

const source = createRosbridgeAdapter({
  url: 'ws://localhost:9090',
  topic: '/imu/data',
  messageType: 'sensor_msgs/Imu',
  valueExtractor: (msg) => msg.angular_velocity.z,
});

export function App() {
  return (
    <AltaraProvider theme="dark">
      <TimeSeries dataSource={source} height={240} />
    </AltaraProvider>
  );
}

What you get

createRosbridgeAdapter handles:

• rosbridge v2 envelope ({ op: 'subscribe', topic, type }) on connect
• Auto-reconnect with exponential backoff (1 s → 30 s)
• ROS header.stamp.{sec, nanosec} → unix milliseconds normalization
• Optional throttleMs to drop samples that arrive faster than you want to render
• Three timestamp modes ('wallclock' / 'message' / 'relative')
• Cleanup on destroy() including the unsubscribe envelope

Typed convenience factories

For common ROS message types, skip the messageType + valueExtractor boilerplate:

| Factory | Message type | Extracted value | | --- | --- | --- | | createBatteryStateAdapter | sensor_msgs/BatteryState | percentage * 100 (voltage fallback — see below) | | createRangeAdapter | sensor_msgs/Range | range (m) | | createTemperatureAdapter | sensor_msgs/Temperature | temperature (°C) | | createNavSatFixAdapter({ axis }) | sensor_msgs/NavSatFix | latitude / longitude / altitude | | createImuAdapter | sensor_msgs/Imu | { roll, pitch, yaw } in degrees (see below) | | createFloat32Adapter | std_msgs/Float32 | data | | createFloat64Adapter | std_msgs/Float64 | data |

import { createBatteryStateAdapter } from '@altara/ros';

const battery = createBatteryStateAdapter({
  url: 'ws://localhost:9090',
  topic: '/battery',
});
// hand to any component that takes `dataSource={…}`

Battery state of charge with a voltage fallback

PX4 and ArduPilot publish BatteryState.percentage as -1 (or NaN) when the firmware has no fuel-gauge estimate — the common case on a bare LiPo pack. By default that sample is dropped and the gauge stays blank. Pass a voltageRange to derive an estimate from voltage instead:

const battery = createBatteryStateAdapter({
  url: 'ws://localhost:9090',
  topic: '/mavros/battery',
  voltageRange: { min: 14.0, max: 16.8 }, // 4S LiPo (3.5–4.2 V/cell)
});

⚠️ The voltage→charge map is a clamped linear approximation. A LiPo's discharge curve is non-linear, so treat this as presence-of-charge (is there juice left?), not an accurate range-remaining percentage. A valid percentage from the firmware always takes precedence.

Multi-channel sources & the PFD

A flight display needs several signals at once (roll, pitch, heading, airspeed, altitude). Two helpers make that one coherent dataSource:

• channels — pass a { name: extractor } map to createRosbridgeAdapter (or use createImuAdapter) to pull several numbers from one message over one socket. Returns { [name]: AltaraDataSource }.
• mergeChannels — union several single-value sources into one channel-tagged source that a multi-input component routes by channel.

createImuAdapter converts sensor_msgs/Imu.orientation (a quaternion) into { roll, pitch, yaw } degree channels for you (the standalone quaternionToEuler(q) is exported too, clamped at the ±90° poles). Note IMU yaw is heading in the IMU frame, not compass heading — drive the PFD's heading from VFR_HUD.

A full Primary Flight Display wires on two sockets — one IMU, one VFR_HUD:

import { PrimaryFlightDisplay } from '@altara/aerospace';
import { createImuAdapter, createRosbridgeAdapter, mergeChannels } from '@altara/ros';

const imu = createImuAdapter({ url, topic: '/mavros/imu/data' }); // { roll, pitch, yaw }
const hud = createRosbridgeAdapter({
  url,
  topic: '/mavros/vfr_hud',
  messageType: 'mavros_msgs/VFR_HUD',
  channels: {
    heading: (m) => m.heading,
    airspeed: (m) => m.airspeed * 1.94384, // m/s -> kt
    altitude: (m) => m.altitude * 3.28084, // m -> ft
  },
});

const source = mergeChannels({
  roll: imu.roll,
  pitch: imu.pitch,
  heading: hud.heading,
  airspeed: hud.airspeed,
  altitude: hud.altitude,
});

// <PrimaryFlightDisplay dataSource={source} showFlightDirector />

mergeChannels is re-exported from @altara/ros (it lives in @altara/core), so a single import line covers the whole wiring.

Documentation

• 📚 Connecting ROS2 guide (live Storybook) — Docker setup, multi-topic dashboards, timestamp source modes, throttling, troubleshooting.
• 🛰️ Live demo dashboard — see the components a rosbridge feed would drive.

Or run Storybook locally:

git clone https://github.com/JayaSaiKishanChapparam/altara.git
cd altara
pnpm install
pnpm --filter @altara/storybook storybook

Then open Guides → Connecting ROS2.

Sibling packages

| Package | What it does | | --- | --- | | @altara/core | Components, hooks, MQTT/mock adapters, design tokens. The starting point. | | @altara/aerospace | Flight instruments — PFD, HSI, altimeter, airspeed, VSI, engine cluster, TCAS, TAWS, FMA, fuel gauge, radio altimeter. | | @altara/mqtt | MQTT-over-WebSocket adapter for IoT brokers. |
