@bensitu/image-editor

A lightweight, TypeScript-first canvas image editor built on top of Fabric.js v7. ImageEditor wraps a Fabric canvas with image loading, scale and rotation, mask creation, Text and Draw annotations, crop, Mosaic mode, base-image flips, history (undo/redo), layer operations, and base64/file export — exposed as a single canonical class with a stable public surface.

Demo

https://bensitu.github.io/image-editor/

Features

• TypeScript source with .d.ts declarations published alongside the runtime
• Single canonical class ImageEditor exported as both default and named
• Fabric.js v7 declared as a peer dependency (no bundled Fabric copy)
• Multi-format publish: ESM (import), CommonJS (require), UMD (<script>), TypeScript declarations (types)
• Transactional loadImage with rollback on decode, Fabric, downsample, or timeout failures
• Animation queue serializes scaleImage, rotateImage, resetImageTransform, undo, and redo so concurrent clicks never interleave
• Bounded history stack with idempotent dispose
• Crop session with mask preservation toggle and atomic apply/cancel
• Mosaic mode with circular brush preview, runtime brush/block controls, and one undo step per successful pixelation click
• Unified editor-owned object model for base images, masks, annotations, and session overlays
• Text annotations, Draw mode, annotation update/delete APIs, and layer operations
• Base64 and File exports with PNG/JPEG/WebP support, configurable multiplier, independent mask/annotation rendering toggles, and state-mutating mask/annotation merge APIs

Requirements

• Node.js: >= 20 for development / building from source
• Fabric.js: peer dependency ^7.0.0 (must be installed by the consumer)
• Browsers: modern evergreen (Chrome, Firefox, Safari, Edge). The library uses ES2022 features and the Fabric v7 promise-based API.
• TypeScript: strict consumers that compile dependencies with skipLibCheck: false should include the ES2022 library in tsconfig.json. Fabric v7.4 declarations also reference jsdom types, so install @types/jsdom when your project type-checks Fabric's declaration files.

Installation

npm install @bensitu/image-editor fabric
# or
pnpm add @bensitu/image-editor fabric
# or
yarn add @bensitu/image-editor fabric

fabric@^7.0.0 is a peer dependency: install it explicitly so the editor resolves the exact version your application uses.

Module formats and entry points

The package ships a single public entry, resolved by tooling via the exports map in package.json:

| Consumer | Resolves to | | ------------------------------------- | ------------------------------ | | ESM (import) | dist/esm/index.js | | CommonJS (require) | dist/cjs/index.cjs | | TypeScript (types) | dist/types/index.d.ts | | UMD (<script>, unpkg, jsdelivr) | dist/umd/image-editor.umd.js | | default fallback | dist/esm/index.js |

The UMD bundle exposes a global named ImageEditor and treats fabric as an external global named fabric.

Dual entry-point convention

ImageEditor's constructor accepts the Fabric module either explicitly (ESM consumers) or via globalThis.fabric (UMD consumers). The same source ships in all four formats:

• Explicit module form (recommended for bundled apps): pass the Fabric module as the first argument.

  import * as fabric from 'fabric';
  import { ImageEditor } from '@bensitu/image-editor';

  const editor = new ImageEditor(fabric, {
      canvasWidth: 800,
      canvasHeight: 600,
  });

• Global form (UMD <script> consumers): omit the first argument; the constructor reads globalThis.fabric.

  <script src="https://cdn.jsdelivr.net/npm/fabric@7/dist/index.min.js"></script>
  <script src="https://cdn.jsdelivr.net/npm/@bensitu/image-editor/dist/umd/image-editor.umd.js"></script>
  <script>
      const editor = new ImageEditor({
          canvasWidth: 800,
          canvasHeight: 600,
      });
  </script>

If neither form yields a usable Fabric module, the constructor logs a single descriptive console.error and init() and loadImage() become no-ops that resolve to undefined.

Quick start

HTML

<canvas id="canvas"></canvas>

<button id="zoomInButton">Zoom In</button>
<button id="zoomOutButton">Zoom Out</button>
<button id="rotateLeftButton">Rotate Left</button>
<input id="rotateLeftDegreesInput" type="number" value="90" />
<button id="rotateRightButton">Rotate Right</button>
<input id="rotateRightDegreesInput" type="number" value="90" />
<button id="flipHorizontalButton">Flip Horizontal</button>
<button id="flipVerticalButton">Flip Vertical</button>

<button id="createMaskButton">Add Mask</button>
<button id="removeSelectedMaskButton">Remove Mask</button>
<button id="removeAllMasksButton">Remove All Masks</button>
<ul id="maskList"></ul>

<button id="enterTextModeButton">Text</button>
<button id="exitTextModeButton">Exit Text</button>
<input id="textColorInput" type="color" value="#ff0000" />
<input id="textFontSizeInput" type="number" min="8" max="160" value="32" />

<button id="enterDrawModeButton">Draw</button>
<button id="exitDrawModeButton">Exit Draw</button>
<input id="drawColorInput" type="color" value="#ff0000" />
<input id="drawBrushSizeInput" type="range" min="1" max="80" value="8" />

<button id="removeSelectedAnnotationButton">Remove Annotation</button>
<button id="removeAllAnnotationsButton">Remove All Annotations</button>
<button id="deleteSelectedObjectButton">Delete Selected</button>
<button id="bringSelectedObjectForwardButton">Forward</button>
<button id="sendSelectedObjectBackwardButton">Backward</button>
<button id="bringSelectedObjectToFrontButton">Front</button>
<button id="sendSelectedObjectToBackButton">Back</button>
<ul id="annotationList"></ul>

<button id="enterCropModeButton">Crop</button>
<select id="cropAspectRatioSelect">
    <option value="free">Free</option>
    <option value="1:1">1:1</option>
    <option value="3:4">3:4</option>
    <option value="4:3">4:3</option>
    <option value="3:2">3:2</option>
    <option value="2:3">2:3</option>
    <option value="9:16">9:16</option>
    <option value="16:9">16:9</option>
</select>
<button id="applyCropButton">Apply Crop</button>
<button id="cancelCropButton">Cancel Crop</button>

<button id="enterMosaicModeButton">Mosaic</button>
<button id="exitMosaicModeButton">Exit Mosaic</button>
<label>
    Brush size
    <input id="mosaicBrushSizeInput" type="range" min="8" max="160" step="1" value="48" />
</label>
<label>
    Block size
    <input id="mosaicBlockSizeInput" type="range" min="2" max="40" step="1" value="8" />
</label>

<button id="mergeMasksButton">Merge Masks</button>
<button id="mergeAnnotationsButton">Merge Annotations</button>
<button id="downloadImageButton">Download</button>
<button id="undoButton">Undo</button>
<button id="redoButton">Redo</button>
<button id="resetImageTransformButton">Reset</button>

<input id="imageInput" type="file" accept="image/*" />

TypeScript / ESM

import * as fabric from 'fabric';
import { ImageEditor } from '@bensitu/image-editor';
import type { ImageEditorOptions, MaskConfig } from '@bensitu/image-editor';

const editor = new ImageEditor(fabric, {
    canvasWidth: 800,
    canvasHeight: 600,
    backgroundColor: '#ffffff',
    defaultMosaicConfig: {
        brushSize: 48,
        blockSize: 8,
    },
    defaultTextConfig: {
        fill: '#ff0000',
        fontSize: 32,
    },
    defaultDrawConfig: {
        color: '#ff0000',
        brushSize: 8,
    },
} satisfies ImageEditorOptions);

editor.init({
    canvas: 'canvas',
    zoomInButton: 'zoomInButton',
    zoomOutButton: 'zoomOutButton',
    rotateLeftButton: 'rotateLeftButton',
    rotateLeftDegreesInput: 'rotateLeftDegreesInput',
    rotateRightButton: 'rotateRightButton',
    rotateRightDegreesInput: 'rotateRightDegreesInput',
    flipHorizontalButton: 'flipHorizontalButton',
    flipVerticalButton: 'flipVerticalButton',
    createMaskButton: 'createMaskButton',
    removeSelectedMaskButton: 'removeSelectedMaskButton',
    removeAllMasksButton: 'removeAllMasksButton',
    maskList: 'maskList',
    enterCropModeButton: 'enterCropModeButton',
    cropAspectRatioSelect: 'cropAspectRatioSelect',
    applyCropButton: 'applyCropButton',
    cancelCropButton: 'cancelCropButton',
    enterMosaicModeButton: 'enterMosaicModeButton',
    exitMosaicModeButton: 'exitMosaicModeButton',
    mosaicBrushSizeInput: 'mosaicBrushSizeInput',
    mosaicBlockSizeInput: 'mosaicBlockSizeInput',
    enterTextModeButton: 'enterTextModeButton',
    exitTextModeButton: 'exitTextModeButton',
    textColorInput: 'textColorInput',
    textFontSizeInput: 'textFontSizeInput',
    enterDrawModeButton: 'enterDrawModeButton',
    exitDrawModeButton: 'exitDrawModeButton',
    drawColorInput: 'drawColorInput',
    drawBrushSizeInput: 'drawBrushSizeInput',
    removeSelectedAnnotationButton: 'removeSelectedAnnotationButton',
    removeAllAnnotationsButton: 'removeAllAnnotationsButton',
    deleteSelectedObjectButton: 'deleteSelectedObjectButton',
    mergeAnnotationsButton: 'mergeAnnotationsButton',
    bringSelectedObjectForwardButton: 'bringSelectedObjectForwardButton',
    sendSelectedObjectBackwardButton: 'sendSelectedObjectBackwardButton',
    bringSelectedObjectToFrontButton: 'bringSelectedObjectToFrontButton',
    sendSelectedObjectToBackButton: 'sendSelectedObjectToBackButton',
    annotationList: 'annotationList',
    mergeMasksButton: 'mergeMasksButton',
    downloadImageButton: 'downloadImageButton',
    undoButton: 'undoButton',
    redoButton: 'redoButton',
    resetImageTransformButton: 'resetImageTransformButton',
    imageInput: 'imageInput',
});

// Load an image programmatically (base64 data URL).

// Add a rectangular mask, then export the result as base64.
const mask: MaskConfig = { shape: 'rect', width: 120, height: 80, left: '25%', top: '25%' };
editor.createMask(mask);
editor.createTextAnnotation({ text: 'Label', left: 120, top: 80 });
editor.enterDrawMode();
editor.setDrawConfig({ color: '#00aaff', brushSize: 10 });

const dataUrl = await editor.exportImageBase64({ fileType: 'png' });

CommonJS

const fabric = require('fabric');
const { ImageEditor } = require('@bensitu/image-editor');

const editor = new ImageEditor(fabric, { canvasWidth: 800, canvasHeight: 600 });

In v2, require('@bensitu/image-editor') returns a namespace object with ImageEditor, default, and the editor object guards (isBaseImageObject, isMaskObject, isAnnotationObject, isTextAnnotationObject, isDrawAnnotationObject, isSessionObject, and isEditableOverlayObject); it does not return the constructor directly.

Public API

ImageEditor is the only public class. The package barrel re-exports it as both the default export and a named export, alongside the editor object guards and the documented public types. Internal helpers (animation queue, command, history manager, controllers, services, managers, utility modules) are intentionally not exported and may change without notice.

Object model

Every editor-owned Fabric object carries strict editorObjectKind metadata:

| Kind | Meaning | | ------------ | ------------------------------------------------------------------------ | | baseImage | The committed image at the bottom of the stack. | | mask | Editable mask overlay with required maskId, maskUid, and maskName. | | annotation | Editable Text or Draw overlay. Masks are not annotations. | | session | Internal crop labels, mask labels, Mosaic previews, and tool previews. |

Session objects are never persisted, exported, or user-deletable. Strict type guards reject legacy mask-like objects that do not carry editorObjectKind.

Constructor

new ImageEditor(fabric: FabricModule, options?: ImageEditorOptions)
new ImageEditor(options?: ImageEditorOptions)  // UMD: reads globalThis.fabric

Lifecycle

| Method | Description | | -------------- | ------------------------------------------------------------------------------------ | | init(idMap?) | Bind the editor to DOM elements. Pass an ElementIdMap; any key may be omitted. | | dispose() | Tear down the editor, drain DOM bindings, and dispose the Fabric canvas. Idempotent. |

Image loading

| Method | Description | | ----------------------------- | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | loadImage(base64, options?) | Load a supported raster image data URL (png, jpeg, webp, gif, or bmp). Returns Promise<void>. Transactional: any failure restores the prior canvas, scroll, overflow, and snapshot state. | | isImageLoaded() | Returns true if a valid image is currently loaded on the canvas. | | isBusy() | Returns true while the editor is loading, animating, or in Crop, Mosaic, Text, or Draw mode. | | setLayoutMode(mode) | Select the layout strategy for future image loads. mode is 'fit', 'cover', or 'expand'. |

LoadImageOptions currently includes preserveScroll?: boolean for preserving the container's scroll position across both successful loads and rollback paths.

Use defaultLayoutMode to choose the initial image-load strategy, then call setLayoutMode() when a UI should change how future images are placed:

const editor = new ImageEditor(fabric, {
    defaultLayoutMode: 'fit',
});

await editor.loadImage(imageA);

// Future loads use cover. The current image is not re-laid out immediately.
editor.setLayoutMode('cover');
await editor.loadImage(imageB);

Invalid JavaScript defaultLayoutMode values fall back to 'expand'. Invalid setLayoutMode() calls are ignored and preserve the current mode.

File-input helpers accept JPG, PNG, WebP, GIF, and BMP files. GIF and BMP are decoded as static raster input for canvas editing; GIF animation and BMP/GIF source-format preservation are not retained. Export output remains controlled by the JPEG, PNG, or WebP export options.

Transforms

| Method | Description | | ----------------------- | ---------------------------------------------------------------------------------------------------------------------------------- | | scaleImage(factor) | Scale to factor (clamped to [minScale, maxScale]). Non-finite values are no-ops. Animated. | | rotateImage(degrees) | Rotate to degrees. Non-finite values resolve without changing canvas state. Animated. | | flipHorizontal() | Toggle horizontal flip on the base image only. Masks, annotations, and session overlays are not mirrored. Returns Promise<void>. | | flipVertical() | Toggle vertical flip on the base image only. Masks, annotations, and session overlays are not mirrored. Returns Promise<void>. | | resetImageTransform() | Animate to scale 1, rotation 0, and an unflipped state. Records exactly one history entry covering the entire transform. |

await editor.flipHorizontal();
await editor.flipVertical();

Masks

| Method | Description | | -------------------------- | ----------------------------------------------------------------------------- | | createMask(config?) | The single mask-creation entry point. Returns the new MaskObject or null. | | removeSelectedMask() | Remove the currently selected mask and push one history entry. | | removeAllMasks(options?) | Remove every mask. options.saveHistory defaults to true. |

MaskConfig supports rect, circle, ellipse, polygon, and a custom fabricGenerator. Falsy values in styles (0, false, null, '', NaN) are applied verbatim. Every mask is marked as editorObjectKind: 'mask' and includes required maskId, maskUid, and maskName metadata.

Use defaultMaskConfig to define constructor-level defaults for masks created through either createMask() or the built-in createMaskButton. Per-call createMask(config) values override defaultMaskConfig.

const editor = new ImageEditor(fabric, {
    defaultMaskConfig: {
        color: 'rgba(255, 0, 0, 0.35)',
        alpha: 0.35,
        styles: {
            stroke: '#ff0000',
            strokeWidth: 2,
            strokeDashArray: [6, 4],
        },
    },
});

editor.createMask(); // Uses defaultMaskConfig.
editor.createMask({ color: 'rgba(0, 128, 255, 0.35)' }); // Per-call override.

Crop

| Method | Description | | --------------------------- | ------------------------------------------------------------------------------------ | | enterCropMode(options?) | Add an interactive crop rectangle on top of the image. | | setCropAspectRatio(ratio) | Update the active crop rectangle ratio while crop mode is open. | | applyCrop() | Apply the current crop region. Atomic: failure rolls back to the pre-crop snapshot. | | cancelCrop() | Cancel crop mode and restore the prior canvas state without pushing a history entry. |

enterCropMode({ aspectRatio }) locks the crop rectangle to a preset or custom ratio. Supported preset strings are 'free', '1:1', '3:4', '4:3', '3:2', '2:3', '16:9', and '9:16'. Custom ratios use { width, height }. Per-call options override crop.aspectRatio from the constructor.

When cropAspectRatioSelect is bound through init(idMap), the built-in Crop button uses the select's current value and changing the select while crop mode is open calls setCropAspectRatio() to resize the active crop rectangle.

editor.enterCropMode({ aspectRatio: '1:1' });
editor.enterCropMode({ aspectRatio: '16:9' });
editor.setCropAspectRatio('4:3');
editor.enterCropMode({ aspectRatio: { width: 2, height: 1 } });

Mosaic mode

| Method | Description | | -------------------------- | ---------------------------------------------------------------------- | | enterMosaicMode() | Enter circular-brush Mosaic mode and show the hover preview on canvas. | | exitMosaicMode() | Leave Mosaic mode and remove preview/session handlers. | | isMosaicMode() | Returns true while a Mosaic session is active. | | getMosaicConfig() | Returns a defensive copy of the current runtime Mosaic config. | | setMosaicConfig(config) | Patch current Mosaic config without creating a history entry. | | resetMosaicConfig() | Restore current Mosaic config from constructor defaults. | | setMosaicBrushSize(size) | Set brush diameter in canvas pixels. | | setMosaicBlockSize(size) | Set source-pixel block size; values are floored to integers. |

defaultMosaicConfig initializes the current runtime Mosaic config. Runtime setters update only the current config and never mutate constructor defaults. resetMosaicConfig() clones the constructor defaults back into the current config.

const editor = new ImageEditor(fabric, {
    defaultMosaicConfig: {
        brushSize: 48,
        blockSize: 8,
    },
});

editor.init({
    canvas: 'canvas',
    enterMosaicModeButton: 'enterMosaicModeButton',
    exitMosaicModeButton: 'exitMosaicModeButton',
    mosaicBrushSizeInput: 'mosaicBrushSizeInput',
    mosaicBlockSizeInput: 'mosaicBlockSizeInput',
});

editor.enterMosaicMode();
editor.setMosaicConfig({ brushSize: 64, blockSize: 12 });
editor.resetMosaicConfig();

brushSize is the circular brush diameter in canvas pixels. blockSize is the source-image pixel block size; larger values produce chunkier pixelation. Clicking outside the image is a no-op. Each successful Mosaic click bakes the pixelated region into the base image and creates exactly one undo step. Because Mosaic edits replace base image pixels rather than adding Fabric overlay objects, exported images include the Mosaic naturally while the preview circle is never exported or saved in history.

Text and Draw annotations

Tool modes are mutually exclusive: Crop, Mosaic, Text, and Draw cannot be active at the same time. getEditorState() reports activeToolMode plus isCropMode, isMosaicMode, isTextMode, and isDrawMode.

| Method | Description | | ------------------------------------ | -------------------------------------------------------------------------- | | getAnnotations() | Return current annotation objects in canvas order. Masks are not included. | | enterTextMode() / exitTextMode() | Click empty canvas space to create editable text annotations. | | createTextAnnotation(config?) | Create a text annotation directly and return it. | | getTextConfig() | Return a defensive copy of the current Text config. | | setTextConfig(config) | Patch current Text config without history. | | resetTextConfig() | Restore Text config from constructor defaults. | | setTextColor(color) | Convenience setter for text fill color. | | setTextFontSize(size) | Convenience setter for text font size. | | enterDrawMode() / exitDrawMode() | Use Fabric free drawing; each stroke becomes a Draw annotation. | | getDrawConfig() | Return a defensive copy of the current Draw config. | | setDrawConfig(config) | Patch current Draw config without history. | | resetDrawConfig() | Restore Draw config from constructor defaults. | | setDrawColor(color) | Convenience setter for brush color. | | setDrawBrushSize(size) | Convenience setter for brush size. | | updateAnnotation(id, config) | Update an annotation by id. | | updateSelectedAnnotation(config) | Update selected annotation objects. | | removeSelectedAnnotation() | Remove selected unlocked annotations. | | removeAllAnnotations(options?) | Remove annotations only. Masks are preserved. | | deleteSelectedObject() | Convenience deletion for selected masks and unlocked annotations. |

editor.enterTextMode();
editor.setTextConfig({ fill: '#ff0000', fontSize: 32 });
editor.updateSelectedAnnotation({ fill: '#00aaff' });

editor.enterDrawMode();
editor.setDrawConfig({ color: '#00aaff', brushSize: 10 });

Annotations carry annotationHidden and annotationLocked metadata. Hidden annotations are not rendered during export. Locked annotations are not selectable/editable and are skipped by selected-annotation update/delete operations unless an API explicitly opts into forced removal.

Layer operations

Editable overlays include masks and annotations. Layer operations keep the base image below overlays and session objects above overlays.

| Method | Description | | ------------------------------ | ------------------------------------------------- | | bringSelectedObjectForward() | Move selected editable overlays one step up. | | sendSelectedObjectBackward() | Move selected editable overlays one step down. | | bringSelectedObjectToFront() | Move selected editable overlays to overlay front. | | sendSelectedObjectToBack() | Move selected editable overlays to overlay back. |

Merge and export

| Method | Description | | ----------------------------- | ---------------------------------------------------------------------------------------------- | | mergeMasks() | Bake masks into the base image atomically. Returns Promise<void>. | | mergeAnnotations() | Bake annotations into the base image atomically. Returns Promise<void>. | | exportImageBase64(options?) | Returns Promise<string> (data URL). Resolves to '' with a warning when no image is loaded. | | exportImageFile(options?) | Returns Promise<File>. Rejects when no image is loaded. | | downloadImage(options?) | Returns Promise<void> and triggers a browser download. No-op when no image is loaded. |

All export APIs use the same ImageExportOptions shape:

| Option | Default | Description | | ------------------ | --------- | --------------------------------------------------------------------------------- | | mergeMasks | true | Render masks into exported pixels. Mask labels are never exported. | | mergeAnnotations | true | Render non-hidden annotations into exported pixels. | | exportArea | 'image' | 'image' clips to the image bounding box; 'canvas' exports the canvas. | | fileType | 'jpeg' | 'png', 'jpeg', 'jpg', 'webp', or matching full MIME strings. | | format | 'jpeg' | Alias for fileType on all export APIs; fileType wins when both set. | | quality | 0.92 | Lossy quality clamped to [0, 1]; ignored for PNG. | | multiplier | 1 | Output resolution multiplier. | | fileName | option | exportImageFile() and downloadImage(). Defaults to defaultDownloadFileName. |

await editor.exportImageBase64({ mergeMasks: true, mergeAnnotations: true });
await editor.exportImageBase64({ mergeMasks: false, mergeAnnotations: true });
await editor.exportImageBase64({ mergeMasks: true, mergeAnnotations: false });
await editor.exportImageBase64({ mergeMasks: false, mergeAnnotations: false });

const dataUrl = await editor.exportImageBase64({ fileType: 'png', exportArea: 'image' });
const file = await editor.exportImageFile({
    fileType: 'webp',
    quality: 0.85,
    fileName: 'edited',
});
await editor.downloadImage({
    fileType: 'png',
    fileName: 'edited',
    mergeMasks: false,
    mergeAnnotations: false,
});

mergeMasks and mergeAnnotations in export options affect the rendered output only. They do not mutate editor state, remove objects, or push history entries. State-mutating merge APIs are mergeMasks() and mergeAnnotations(). mergeMasks() preserves annotations; mergeAnnotations() preserves masks.

State and history

| Method | Description | | ------------------------- | ------------------------------------------------------------------------------------- | | saveState() | Capture a snapshot of the canvas plus editor metadata into the history stack. | | loadFromState(snapshot) | Restore canvas, masks, and editor metadata from a snapshot. Returns Promise<void>. | | undo() | Undo the last state change. Routed through the animation queue. No-op while disposed. | | redo() | Redo the next state change. Routed through the animation queue. No-op while disposed. |

Configuration options

Pass an ImageEditorOptions object as the second constructor argument (or as the only argument when using the UMD global form). Unknown keys are ignored; nested label and crop objects are deep-merged with the defaults.

| Option | Default | Description | | --------------------------- | ---------------- | --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | canvasWidth | 800 | Initial and hidden-container fallback canvas width in pixels. | | canvasHeight | 600 | Initial and hidden-container fallback canvas height in pixels. | | backgroundColor | 'transparent' | Fabric canvas background color. | | animationDuration | 300 | Duration of scale and rotate animations (ms). | | minScale | 0.1 | Minimum scale factor. | | maxScale | 5.0 | Maximum scale factor. | | scaleStep | 0.05 | Scale delta per zoom step. | | rotationStep | 90 | Rotation step in degrees. | | defaultLayoutMode | 'expand' | Initial layout mode for image loads until changed by setLayoutMode(). Use 'fit', 'cover', or 'expand'. Invalid runtime values fall back to 'expand'. | | downsampleOnLoad | true | Downsample large images on load. | | downsampleMaxWidth | 4000 | Max width before downsampling kicks in. | | downsampleMaxHeight | 3000 | Max height before downsampling kicks in. | | downsampleQuality | 0.92 | Lossy quality used when downsampling and exporting. | | preserveSourceFormat | true | Preserve PNG/WebP MIME through downsampling unless downsampleMimeType is set. | | downsampleMimeType | null | Explicit downsample MIME type. Overrides preserveSourceFormat. | | imageLoadTimeoutMs | 30000 | Maximum duration for both decode and Fabric image creation during loadImage. | | exportMultiplier | 1 | Output resolution multiplier. | | maxExportPixels | 50000000 | Maximum output pixel count after applying the export multiplier. Invalid values fall back to this default. | | maxHistorySize | 50 | Maximum undo-history entries. Snapshots may include full image data URLs, so large images can duplicate memory across history entries. Lower this for memory-constrained pages. | | exportAreaByDefault | 'image' | Default export region for exportImageBase64, exportImageFile, and downloadImage. | | mergeMasksByDefault | true | Default mask rendering behavior for exportImageBase64, exportImageFile, and downloadImage. | | mergeAnnotationsByDefault | true | Default annotation rendering behavior for exportImageBase64, exportImageFile, and downloadImage. | | defaultMaskWidth | 50 | Default mask width. | | defaultMaskHeight | 80 | Default mask height. | | defaultMaskConfig | {} | Defaults applied by createMask() after defaultMaskWidth / defaultMaskHeight and before per-call config. Supports MaskConfig fields except onCreate and fabricGenerator. | | defaultMosaicConfig | see source | Defaults used to initialize the current Mosaic tool config. Supports brushSize, blockSize, preview circle styling, outputFileType, and outputQuality. Runtime Mosaic setters update the current config only. | | defaultTextConfig | see source | Defaults used to initialize the current Text annotation config. Runtime Text setters update the current config only. | | defaultDrawConfig | see source | Defaults used to initialize the current Draw mode config. Runtime Draw setters update the current config only. | | maskRotatable | false | Allow masks to be rotated by the user. | | maskLabelOnSelect | true | Show a label above a selected mask. | | maskLabelOffset | 3 | Pixel offset of the label from the mask's top-left corner. | | maskName | 'mask' | Prefix used for auto-generated mask names. | | textAnnotationName | 'text' | Prefix used for auto-generated text annotation names. | | drawAnnotationName | 'draw' | Prefix used for auto-generated draw annotation names. | | groupSelection | false | Allow Fabric multi-object group selection on the canvas. | | showPlaceholder | true | Show a placeholder element while no image is loaded. | | initialImageBase64 | null | Base64 data URL auto-loaded after construction. | | defaultDownloadFileName | 'edited_image' | Default filename base used by exportImageFile() and downloadImage(). The resolved export format supplies or corrects the extension. | | onImageLoadStart | null | Called before a valid image load begins. | | onImageLoaded | null | Called as (info, context) once after a successful loadImage. Extra arguments are ignored by existing zero-argument JavaScript handlers. | | onImageCleared | null | Called when a committed image is replaced or cleared. | | onImageChanged | null | Called with a safe editor state snapshot after visible editor state changes. | | onBusyChange | null | Called only when the public busy state changes. | | onEditorDisposed | null | Called once when dispose() performs teardown. | | onMasksChanged | null | Called with a shallow copy of current mask objects after the mask collection changes. | | onAnnotationsChanged | null | Called with a shallow copy of current annotation objects after the annotation collection changes. | | onSelectionChange | null | Called with selected object payload after selection changes. | | onError | null | Called as (error, message) when the editor reports an error. | | onWarning | null | Called as (error, message) when the editor reports a recoverable warning. | | label | see source | LabelConfig for selected-mask labels (getText, textOptions, create). | | crop | see source | CropConfig (minWidth, minHeight, padding, aspectRatio, hideMasksDuringCrop, preserveMasksAfterCrop, allowRotationOfCropRect, exportFileType, exportQuality). applyCrop() preserves the current image format by default ('source') and falls back to PNG when unknown. |

crop.exportFileType defaults to 'source'. Supported explicit values are 'png', 'jpeg', 'jpg', 'webp', and full image MIME strings. PNG is lossless and ignores crop.exportQuality; JPEG/WebP use crop.exportQuality when finite, otherwise downsampleQuality, otherwise 0.92. Choose JPEG/WebP only when smaller intermediate crop output is preferred.

defaultMosaicConfig.outputFileType also defaults to 'source'. Mosaic commits preserve the current image MIME type when known and fall back to PNG when the source format cannot be determined. JPEG/WebP commits use defaultMosaicConfig.outputQuality when finite, otherwise downsampleQuality.

Breaking changes in v2

• Base64ExportOptions, ImageFileExportOptions, and DownloadImageOptions were replaced by ImageExportOptions.
• downloadImage(fileName: string) was removed. Use downloadImage({ fileName }).
• downloadImage() now returns Promise<void>.
• defaultDownloadFileName now defaults to 'edited_image'; export format resolution supplies or corrects the final extension.
• All editor-owned Fabric objects now require editorObjectKind.
• isMaskObject() is strict and rejects legacy objects with only maskId.
• MaskObject.maskUid is required.
• Serialized states without editorObjectKind are not migrated.
• Export option mergeMask was removed; use mergeMasks.
• Constructor option mergeMaskByDefault was removed; use mergeMasksByDefault.

Example workflow

1. Construct ImageEditor with options and call init(idMap) to wire it up.
2. Load an image via loadImage(base64) or the bound file input.
3. Adjust with scaleImage, rotateImage, flipHorizontal, flipVertical, resetImageTransform, Crop mode, Mosaic mode, Text mode, or Draw mode.
4. Add createMask and annotation calls, then inspect via maskList and annotationList.
5. Use mergeMasks() or mergeAnnotations() to bake overlays into the image, then exportImageBase64, exportImageFile, or downloadImage to produce the final output.
6. Call dispose() when the editor is unmounted.

Building from source

npm install
npm run build

npm run build runs clean → build:esm → build:cjs → build:types → build:umd in order, emitting:

• dist/esm/index.js (and the rest of the decomposed source tree)
• dist/cjs/index.cjs
• dist/types/index.d.ts
• dist/umd/image-editor.umd.js

npm test runs the Node-based unit and property tests under tests/.

For the full local release gate, run:

npm run format:check
npm run lint
npm run typecheck
npm test
npm run build
npm run package:check
npm audit --audit-level=high
npm pack --dry-run

npm run ci combines format, lint, typecheck, tests, build, and package linting. The test suite also supports a clean checkout where dist/ has not been built yet; integration helpers use source modules until build artifacts exist, while partial dist/ trees still fail the artifact checks.

Browser support

• Chrome 100+
• Firefox 100+
• Safari 15+
• Edge 100+

The library uses modern DOM and ES2022 features (optional chaining, classes, async/await, native promises). Older targets must be transpiled by the consumer.

Type declarations

Public types are re-exported from the package root:

import type {
    ImageEditorOptions,
    ResolvedOptions,
    LabelConfig,
    CropConfig,
    MosaicConfig,
    ResolvedMosaicConfig,
    LoadImageOptions,
    RemoveAllMasksOptions,
    DefaultMaskConfig,
    MaskConfig,
    MaskObject,
    MaskNumericProp,
    ResolvedMaskConfig,
    ImageMimeType,
    ImageFileType,
    NormalizedImageFormat,
    ExportArea,
    CropExportFileType,
    MosaicOutputFileType,
    ImageExportOptions,
    CropAspectRatioPreset,
    CropAspectRatio,
    CropModeOptions,
    ImageInfo,
    ImageEditorState,
    ImageEditorSelection,
    ImageEditorCallbackContext,
    ImageEditorOperation,
    ElementIdMap,
    FabricModule,
} from '@bensitu/image-editor';

License

MIT © Ben Situ.

Fabric.js is distributed under its own MIT license.
