@bitmacro/relay-agent

→ Web UI: relay-panel.bitmacro.io
→ BitMacro Ecosystem: bitmacro.io

Manage your Nostr relay without touching the terminal.

relay-agent is a REST API agent that runs on your relay server and translates HTTP requests into strfry CLI commands. It is part of the BitMacro Relay Manager ecosystem.

| Project | Description | License | |---------|-------------|---------| | relay-agent | This repo — REST API for strfry | MIT | | @bitmacro/relay-connect | BitMacro Connect SDK (NIP-46 / NIP-07) | MIT | | relay-connect-web | Connect UI + /signer proxy (Next.js) | MIT | | relay-api | Central hub (Supabase, proxy) | Private | | relay-panel | Relay management UI | BSL 1.1 |

Quick Start

Via npx

npx @bitmacro/relay-agent --port 7800 --token your-secret-token

Use --version or --help to check version or CLI options.

Via Docker

Multi-arch image (amd64, arm64) at ghcr.io/bitmacro/relay-agent. Includes strfry binary. Mount your strfry data volume:

docker pull ghcr.io/bitmacro/relay-agent:latest
docker run -p 7800:7800 \
  -e RELAY_AGENT_TOKEN=your-secret-token \
  -v /path/to/strfry-db:/app/strfry-db \
  -v /path/to/whitelist.txt:/app/whitelist.txt \
  ghcr.io/bitmacro/relay-agent:latest

Or build locally: docker build -t relay-agent .

Multiple relays (v0.2): One agent, N relays via RELAY_INSTANCES. Use docker-compose.relay-agent.yml (fragment) or docker-compose.yml (standalone).

Server deployment (v0.2 multi-relay)

# 1. Clone relay-agent into a subdir next to your docker-compose.yml
git clone https://github.com/bitmacro/relay-agent.git relay-agent

# 2. Configure .env (single token for all relays)
echo "RELAY_AGENT_TOKEN=your-secret-token" >> .env

# 3. Build and start (requires relay_private, relay_public, relay_paid, network bitmacro in parent compose)
docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml build relay-agent
docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml up -d relay-agent

Prerequisites: nostr/{public,private,paid}/ must have strfry.conf, whitelist.txt, data/.

Operational Commands

v0.2 multi-relay

# Build and start
docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml up -d --build relay-agent

# View logs
docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml logs -f relay-agent

# Stop
docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml stop relay-agent

Standalone (from relay-agent dir)

cd relay-agent && docker compose up -d

Smoke Test

# v0.2: health lists relay IDs and version
curl http://localhost:7810/health
# {"status":"ok","version":"0.2.7","relayIds":["public","private","paid"],...}
# Per-relay: GET /:relayId/health includes the same package version field.

# v0.2: stats for a specific relay (replace TOKEN and relay id)
curl -H "Authorization: Bearer TOKEN" http://localhost:7810/private/stats

REST API Endpoints

v0.2 multi-relay (RELAY_INSTANCES set)

| Method | Path | Description | Auth | |--------|------|-------------|------| | GET | /health | List active relay IDs | no | | GET | /:relayId/health | Health for relay | no | | GET | /:relayId/stats | Relay statistics | Bearer | | GET | /:relayId/events | List events | Bearer | | DELETE | /:relayId/events/:id | Delete event | Bearer | | GET | /:relayId/policy | Policy entries | Bearer | | GET | /:relayId/policy/blocked | List blocked pubkeys (! lines in whitelist) | Bearer | | POST | /:relayId/policy/block | Block pubkey | Bearer | | POST | /:relayId/policy/allow | Allow pubkey ({ "pubkey", "label"? }) | Bearer | | DELETE | /:relayId/policy/allow/:pubkey | Remove pubkey from allow list (plain line) | Bearer | | DELETE | /:relayId/policy/block/:pubkey | Remove !pubkey block line | Bearer | | GET | /:relayId/users | List pubkeys | Bearer |

relayId = logical ID from RELAY_INSTANCES (e.g. public, private, paid). Must match agent_relay_id in relay_configs.

v0.1 single-relay (no RELAY_INSTANCES)

| Method | Path | Description | |--------|------|-------------| | GET | /health | Health check | | GET | /stats, /events, /policy, /policy/blocked, /users | Same as above, no prefix | | DELETE | /policy/allow/:pubkey, /policy/block/:pubkey | Remove allow / block line (same whitelist file) |

Query parameters for GET /events

| Param | Type | Description | |-------|------|-------------| | kinds | comma-separated | e.g. 1,3 | | authors | comma-separated | pubkeys | | since | unix timestamp | | | until | unix timestamp | | | limit | number | max events to return |

Authentication

All endpoints except /health require:

Authorization: Bearer <your-token>

API Roadmap

Alta prioridade (esta PR)

• [x] DELETE /:relayId/policy/allow/:pubkey
• [x] DELETE /:relayId/policy/block/:pubkey
• [x] GET /:relayId/policy/blocked

Média prioridade

• [ ] DELETE /:relayId/events — apagar eventos por filtro { kinds?, authors?, since?, until? }
• [ ] GET /:relayId/events/count — contagem sem payload completo
• [ ] POST /:relayId/policy/allow/batch — body { pubkeys: string[] }, máx. 100

v1.0 Lightning

• [ ] GET /:relayId/subscribers — lista pubkeys com expiração de acesso pago
• [ ] POST /:relayId/invoice — gerar invoice LNbits para nova subscrição

Environment Variables

v0.2 multi-relay

| Variable | Default | Description | |----------|---------|-------------| | RELAY_INSTANCES | — | JSON array of {id, token, strfryConfig, strfryDb, whitelistPath?} — see strfry.conf vs relay-agent | | RELAY_AGENT_TOKEN | — | Not used when RELAY_INSTANCES is set | | STRFRY_BIN | strfry | Path to strfry binary | | PORT | 7800 | HTTP server port | | ALLOWED_ORIGINS | — | Comma-separated extra CORS origins |

strfry.conf vs relay-agent (v0.2)

The agent runs strfry with cwd = dirname(strfryDb). The db = … line in strfry.conf is resolved relative to that directory.

• In each relay’s strfry.conf, use:

  db = "./data/"

• In RELAY_INSTANCES, set strfryDb to the LMDB directory inside the agent container, e.g.:

  "/app/nostr/<relayId>/data"

  where <relayId> matches your logical id (public, private, paid). Mount the host folder to that path (see docker-compose.relay-agent.yml).

Then ./data/ resolves to /app/nostr/<relayId>/data — the same files the relay uses if the host nostr/<relayId>/data is mounted consistently.

Relay containers (strfry relay) often use working_dir: /app and mount the same host data/ at /app/data, still with db = "./data/". That is a different in-container path but the same host directory as the agent mount.

Breaking change: Older setups used db = "./strfry-db/" and strfryDb ending in strfry-db. Migrate to db = "./data/" and strfryDb ending in /data, and align Docker volume targets on both the agent and relay services.

v0.1 single-relay

| Variable | Default | Description | |----------|---------|-------------| | RELAY_AGENT_TOKEN | — | Required. Bearer token for API auth | | STRFRY_BIN | strfry | Path to strfry binary | | STRFRY_DB_PATH | ./strfry-db | Path to strfry database directory | | STRFRY_CONFIG | — | Path to strfry config file | | WHITELIST_PATH | /etc/strfry/whitelist.txt | Path to whitelist file | | PORT | 7800 | HTTP server port | | ALLOWED_ORIGINS | — | Comma-separated extra CORS origins |

Compatibility

| relay-agent | strfry | Mode | |-------------|--------|------| | 0.1.x | 1.0.x | Single-relay | | 0.2.x | 1.0.x | Multi-relay (RELAY_INSTANCES) |

Architecture

relay-panel
    │  HTTP + JWT
    ▼
relay-api (Vercel)
    │  HTTP REST + Bearer JWT
    ▼
relay-agent (this repo)
    │  child_process spawn()
    ▼
strfry (local C++ process / LMDB)

The relay-agent is stateless — it has no database. State lives in Supabase, managed by relay-api. The relay-agent only translates HTTP calls into strfry CLI commands.

Troubleshooting

503 "relay unavailable"

1. Capture the error — run logs in one terminal, then curl in another:

   # v0.2
   docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml logs -f relay-agent
   curl -H "Authorization: Bearer TOKEN" "http://localhost:7810/private/events?limit=3"

   The strfry stderr will appear in the logs.

2. LMDB "Resource temporarily unavailable" — relay and relay-agent share the same db. Increase maxreaders in your relay's strfry.conf (e.g. ./nostr/private/strfry.conf):

   dbParams {
     maxreaders = 512
   }

   Then restart the relay: docker restart relay_private Stale reader slots (after crashes / SIGABRT) can still wedge the relay until cleared. Stop every container that mounts that LMDB directory (relay_* + relay-agent), then on the host (path = host dir that contains data.mdb):

   # Debian/Ubuntu: lmdb-utils provides mdb_stat — not mdb_reader_check
   sudo mdb_stat -e -rr /home/server/nostr/public/data

   Double -r checks the reader table and removes stale entries. Then start the relay container(s), then relay-agent.

3. Verify db path — relay-agent mounts ./nostr/private/data:/app/nostr/private/data so it matches production strfry.conf with db="./data/" (same layout as relay_private). If you see mdb_env_open: No such file or directory, the mount path or db= in strfry.conf does not match. Check your main docker-compose.yml:

   grep -A5 relay_private docker-compose.yml

4. Test strfry inside container (v0.2):

   docker compose -f docker-compose.yml -f relay-agent/docker-compose.relay-agent.yml run --rm relay-agent sh -c 'ls -la /app/nostr/private/data && /app/strfry --config /app/nostr/private/strfry.conf scan "{}" | head -3'

   If data.mdb is missing or strfry fails, fix the volume path.

Security

• Run on a private network. The relay-agent should run on the operator's server and never be exposed directly to the internet.
• Access is controlled by the relay-api, which proxies requests with a shared Bearer token.
• Use a strong, random token in production. Rotate it if compromised.

Contributing

See CONTRIBUTING.md for setup and PR guidelines.
Issues and PRs are welcome — bug fixes, UI improvements, and new relay-agent integrations.

This project is maintained by BitMacro.

Contributors

License

MIT. See LICENSE.
