Integration Mock Hub

OpenAPI-first mock server with deterministic scenario overrides and strict validation. Also supports proxy mode to intercept real backends.

Install

npm i -D @brentbroeckx/mock-hub

Run without installing:

npx mock-hub run --spec ./openapi.yaml --source ./scenarios

Global install:

npm i -g @brentbroeckx/mock-hub
mock-hub run --spec ./openapi.yaml --source ./scenarios

Quick start

1. Create an OpenAPI spec (example: openapi.yaml).
2. (optional) Create a scenarios directory (example: scenarios).
3. Run the server:

npx mock-hub run --spec ./openapi.yaml
or
npx mock-hub run --spec ./openapi.yaml --source ./scenarios

# Proxy mode (spec optional)
npx mock-hub run --proxy http://localhost:8080 --source ./scenarios

CLI usage

mock-hub run [--spec <path>] [--proxy <baseUrl>] [--source <dir>] [--scenario <name>] [--ui] [--logging] [--port <number>] [--verbose]

Help:

mock-hub run --help

CLI options

• --spec <path>: Path to OpenAPI spec (YAML or JSON). Required unless --proxy is used.
• --proxy <baseUrl>: Enable proxy mode. For unmatched requests, forward to the real backend. Spec is optional in proxy mode.
• --source <dir>: Directory containing .yaml scenario files. Optional; if omitted, happy-path responses are used.
• --scenario <name>: Default scenario name to apply when no header override is provided.
• --ui: Launch interactive scenario selector (Ink).
• --logging: Enable deterministic logs (pretty in CLI/UI, JSONL in CI).
• --port <number>: Port to run the mock server (default: 4010).

Examples

npx mock-hub run --spec ./openapi.yaml
npx mock-hub run --spec ./openapi.yaml --source ./scenarios
npx mock-hub run --spec ./openapi.yaml --source ./scenarios --scenario PartnerDown
npx mock-hub run --spec ./openapi.yaml --source ./scenarios --ui
npx mock-hub run --spec ./openapi.yaml --source ./scenarios --logging
npx mock-hub run --proxy http://localhost:8080 --source ./scenarios
npx mock-hub run --proxy http://localhost:8080 --source ./scenarios --scenario RateLimited

CI Usage

Use the mock server in CI to make integration points deterministic, fast, and isolated from external system availability.

Typical CI Flow

• Start the mock server on a known port with a fixed scenario and deterministic logging.
• Run your test suite against http://localhost:<port>.
• Let the pipeline cleanly shut down the server after tests complete.

Example: Backend Integration Tests

CI=1 npx mock-hub run --spec ./openapi.yaml --source ./scenarios --scenario PartnerDown --port 4010 --logging

BASE_URL=http://localhost:4010 npm test

# Force a single request via header (override for one call in your tests)
curl -s -H "X-MockHub-Scenario: PartnerDown" http://localhost:4010/contracts >/dev/null

Example: Frontend E2E Tests

CI=1 npx mock-hub run --spec ./openapi.yaml --source ./scenarios --scenario HappyPath --port 4010 --logging

BASE_URL=http://localhost:4010 npx playwright test

Example: Forcing Error Scenarios

CI=1 npx mock-hub run --spec ./openapi.yaml --source ./scenarios --scenario PartnerDown --port 4010 --logging

# Validate 503 handling
curl -i -H "X-MockHub-Scenario: PartnerDown" http://localhost:4010/contracts

# Validate 500 handling using another scenario
curl -i -H "X-MockHub-Scenario: PaymentFailed" http://localhost:4010/payments

Notes on Determinism

• Same input $\rightarrow$ same output.
• No random behavior or time‑dependent responses.
• Safe to run in parallel CI jobs when using unique ports per job.

What Not to Use in CI

• UI mode (--ui): requires interactive terminals and is non‑deterministic for automation.
• Interactive scenario switching: can introduce state drift across parallel jobs.

Proxy mode

Proxy mode lets Mock Hub act as a selective interception proxy. By default, requests are forwarded to the real backend. Scenario rules can override or transform responses without changing your client code. Use this to validate error handling, latency, or headers while still hitting the real service.

Resolution order in proxy mode:

1. Scenario match → scenario logic applies
2. No match → forward to --proxy <baseUrl>

Notes:

• If a scenario rule defines body or bodyFile, the response is fully mocked (no proxy).
• If a rule defines only overrides (status/headers/delay/timeout), the response is proxied and then transformed. The body of the original request is kept when present.
• Happy-path OpenAPI mocks are disabled in proxy mode.

Proxy examples are available in scenarios/examples/proxy/scenarios.

Scenario file example

Save as scenarios/examples/default/scenarios/partner-down.yaml:

scenario: PartnerDown
version: 1.0.0
description: Simulate partner API being unavailable
rules:
  - id: partner-down-get
    match:
      path: /contracts/*
      method: GET
      headers:
        X-User-Type: premium
    respond:
      status: 503
      bodyFile: responses/partner_down.json
      delayMs: 500
      headers:
        Retry-After: "30"
  - id: dryrun-validation
    match:
      path: /contracts
      method: POST
      query:
        dryRun: "true"
    respond:
      status: 400
      body:
        error: "Dry-run validation failed"
        code: "VALIDATION_ERROR"

For more examples take a look at: Mock-hub Scenario examples:

Header override

Per-request override using X-MockHub-Scenario:

X-MockHub-Scenario: PartnerDown

Configuration locations

• OpenAPI spec: --spec <path> (YAML or JSON).
• Scenarios directory: --source <dir> containing .yaml files and optional responses/ files.

Response templating (scenario responses only)

Templating is supported only inside respond.body and respond.bodyFile (including nested objects/arrays) for scenario-defined responses. Templates are string-only and resolved per response generation.

Allowed helpers

• {{uuid}} RFC 4122 v4 UUID (new value per response)
• {{now}} ISO-8601 timestamp (evaluated at response time)
• {{increment}} In-memory counter (increments per response, resets on process restart)

No arguments, no nesting, no conditionals, no loops.

Escaping

Use \\{{...}} to output a literal {{...}}.

Example: inline body templating

respond:
  status: 201
  body:
    id: "{{uuid}}"
    createdAt: "{{now}}"
    sequence: "{{increment}}"
    note: "Literal: \\{{not-a-template}}"

Example: bodyFile templating

Scenario:

respond:
  status: 201
  bodyFile: responses/templated_body.json

Response file (templates allowed inside JSON string values):

{
  "id": "{{uuid}}",
  "createdAt": "{{now}}",
  "sequence": "{{increment}}"
}

Validation rules

• Templates are only allowed in respond.body and respond.bodyFile string values (including nested objects/arrays).
• Templates are not allowed in status codes, headers, match rules, delays/timeouts, or paths/methods.
• Unknown helpers, arguments, nesting, malformed syntax, or templates in non-string values fail validation before startup.

Validation behavior (strict)

Validation happens before any scenario execution. Invalid files fail fast with precise errors.

YAML-level

• Syntax errors are rejected with file and line/column.
• Duplicate keys are rejected.
• Only known root keys are allowed.

Schema-level

• No additional properties allowed.
• Required fields must exist.
• Arrays like rules must be non-empty.
• Rule id values must be unique within a file.

Semantic checks

• HTTP status must be $100$–$599$.
• HTTP method must be valid (GET, POST, PUT, DELETE, PATCH, OPTIONS, HEAD).
• path must start with / and may include at most one * wildcard.
• body and bodyFile are mutually exclusive.
• delayMs/timeout must be non-negative.
• version must match x.y.z.

Cross-scenario checks

• Scenario names must be unique.
• Reserved scenario names (prefix auto-gen-) are rejected.

Error output example

ERROR scenarios/auth.yaml:12:4
 ○ payment-failure: rules[0].match.method
   → "FETCH" is not a valid HTTP method

Project structure (recommended)

.
├── src
│   ├── cli
│   ├── openapi
│   ├── responses
│   ├── rules
│   ├── scenarios
│   ├── server
│   ├── state
│   ├── ui
│   └── ...
├── dist
├── scenarios
└── openapi.yaml
