@chat-adapter/gchat

Google Chat adapter for Chat SDK. Configure with service account authentication and optional Pub/Sub.

Installation

pnpm add @chat-adapter/gchat

Usage

The adapter auto-detects credentials from GOOGLE_CHAT_CREDENTIALS or GOOGLE_CHAT_USE_ADC environment variables:

import { Chat } from "chat";
import { createGoogleChatAdapter } from "@chat-adapter/gchat";

const bot = new Chat({
  userName: "mybot",
  adapters: {
    gchat: createGoogleChatAdapter(),
  },
});

bot.onNewMention(async (thread, message) => {
  await thread.post("Hello from Google Chat!");
});

Google Chat setup

1. Create a GCP project

1. Go to console.cloud.google.com
2. Click the project dropdown then New Project
3. Enter project name and click Create

2. Enable required APIs

Go to APIs & Services then Library and enable:

• Google Chat API
• Google Workspace Events API (for receiving all messages)
• Cloud Pub/Sub API (for receiving all messages)

3. Create a service account

1. Go to IAM & Admin then Service Accounts
2. Click Create Service Account
3. Enter name and description
4. Click Create and Continue
5. Skip the optional steps, click Done

4. Create service account key

1. Click on your service account
2. Go to Keys tab
3. Click Add Key then Create new key
4. Select JSON and click Create
5. Copy the entire JSON content as GOOGLE_CHAT_CREDENTIALS

Note: If your organization has the iam.disableServiceAccountKeyCreation constraint enabled, you need to relax it or add an exception for your project in IAM & Admin then Organization Policies.

5. Configure Google Chat app

1. Go to the Chat API configuration
2. Click Configuration and fill in:
   • App name: Your bot's display name
   • Avatar URL: URL to your bot's avatar
   • Description: What your bot does
   • Interactive features: Enable Receive 1:1 messages and Join spaces and group conversations
   • Connection settings: Select App URL
   • App URL: https://your-domain.com/api/webhooks/gchat
   • Visibility: Choose who can discover your app
3. Click Save

6. Add bot to a space

1. Open Google Chat
2. Create or open a Space
3. Click the space name then Manage apps & integrations
4. Click Add apps, search for your app, and click Add

Pub/Sub for all messages (optional)

By default, Google Chat only sends webhooks for @mentions. To receive all messages in a space, set up Workspace Events with Pub/Sub.

createGoogleChatAdapter({
  pubsubTopic: process.env.GOOGLE_CHAT_PUBSUB_TOPIC,
  impersonateUser: process.env.GOOGLE_CHAT_IMPERSONATE_USER,
});

GOOGLE_CHAT_PUBSUB_TOPIC and GOOGLE_CHAT_IMPERSONATE_USER are also auto-detected from env vars, so you can omit them from config if the env vars are set.

1. Create Pub/Sub topic

1. Go to Pub/Sub then Topics
2. Click Create Topic
3. Enter topic ID (e.g., chat-events)
4. Uncheck Add a default subscription
5. Click Create
6. Copy the full topic name as GOOGLE_CHAT_PUBSUB_TOPIC (format: projects/your-project-id/topics/chat-events)

2. Grant Chat service account access

1. Go to your Pub/Sub topic
2. Click Permissions tab
3. Click Add Principal
4. Enter [email protected]
5. Select role Pub/Sub Publisher
6. Click Save

3. Create push subscription

1. Go to Pub/Sub then Subscriptions
2. Click Create Subscription
3. Select your topic
4. Set Delivery type to Push
5. Set Endpoint URL to https://your-domain.com/api/webhooks/gchat
6. Click Create

4. Enable domain-wide delegation

Domain-wide delegation is required for creating Workspace Events subscriptions and initiating DMs.

Step 1 — Enable delegation on the service account:

1. Go to IAM & Admin then Service Accounts
2. Click on your service account
3. Check Enable Google Workspace Domain-wide Delegation and save
4. Copy the Client ID (a numeric ID, not the email)

Step 2 — Authorize in Google Admin Console:

1. Go to Google Admin Console
2. Go to Security then Access and data control then API controls
3. Click Manage Domain Wide Delegation then Add new
4. Enter the numeric Client ID from Step 1
5. Add OAuth scopes (comma-separated, on one line):

   https://www.googleapis.com/auth/chat.spaces.readonly,https://www.googleapis.com/auth/chat.messages.readonly,https://www.googleapis.com/auth/chat.spaces,https://www.googleapis.com/auth/chat.spaces.create

6. Click Authorize

Step 3 — Set environment variable:

Set GOOGLE_CHAT_IMPERSONATE_USER to an admin user email in your domain (e.g., [email protected]).

Configuration

All options are auto-detected from environment variables when not provided.

| Option | Required | Description | |--------|----------|-------------| | credentials | No* | Service account credentials JSON. Auto-detected from GOOGLE_CHAT_CREDENTIALS | | useApplicationDefaultCredentials | No | Use Application Default Credentials. Auto-detected from GOOGLE_CHAT_USE_ADC | | pubsubTopic | No | Pub/Sub topic for Workspace Events. Auto-detected from GOOGLE_CHAT_PUBSUB_TOPIC | | pubsubAudience | No | Expected JWT audience for Pub/Sub webhook verification. Auto-detected from GOOGLE_CHAT_PUBSUB_AUDIENCE | | googleChatProjectNumber | No | GCP project number for direct webhook JWT verification. Auto-detected from GOOGLE_CHAT_PROJECT_NUMBER | | impersonateUser | No | User email for domain-wide delegation. Auto-detected from GOOGLE_CHAT_IMPERSONATE_USER | | auth | No | Custom auth object (advanced) | | logger | No | Logger instance (defaults to ConsoleLogger("info")) |

*Either credentials, GOOGLE_CHAT_CREDENTIALS env var, useApplicationDefaultCredentials, or GOOGLE_CHAT_USE_ADC=true is required.

Environment variables

GOOGLE_CHAT_CREDENTIALS={"type":"service_account",...}

# Optional: for receiving all messages
GOOGLE_CHAT_PUBSUB_TOPIC=projects/your-project/topics/chat-events
[email protected]

# Optional: webhook verification (recommended for production)
GOOGLE_CHAT_PROJECT_NUMBER=123456789          # For direct webhook JWT verification
GOOGLE_CHAT_PUBSUB_AUDIENCE=https://your-domain.com/api/webhooks/gchat  # For Pub/Sub JWT verification

Webhook verification

The adapter supports JWT verification for both webhook types. When configured, the adapter validates the Authorization: Bearer <JWT> header on incoming requests using Google's public keys. Requests with missing or invalid tokens are rejected with HTTP 401.

Verification is opt-in — when the config options are not set, webhooks are accepted without signature checks (for backward compatibility and development).

Direct webhooks (Google Chat API)

Google Chat sends a signed JWT with every webhook request. The JWT audience (aud claim) is your GCP project number.

createGoogleChatAdapter({
  googleChatProjectNumber: "123456789",
});

Find your project number in the GCP Console dashboard (it's different from the project ID).

Pub/Sub push messages

Google Cloud Pub/Sub sends a signed OIDC JWT with push deliveries. The JWT audience is whatever you configured on the push subscription.

createGoogleChatAdapter({
  pubsubAudience: "https://your-domain.com/api/webhooks/gchat",
});

To enable authenticated push on your Pub/Sub subscription:

1. Go to Pub/Sub then Subscriptions
2. Edit your push subscription
3. Enable Authentication
4. Select a service account with the Service Account Token Creator role
5. Set the Audience to your webhook URL
6. Use the same URL as GOOGLE_CHAT_PUBSUB_AUDIENCE

Features

Messaging

| Feature | Supported | |---------|-----------| | Post message | Yes | | Edit message | Yes | | Delete message | Yes | | File uploads | No | | Streaming | Post+Edit fallback |

Rich content

| Feature | Supported | |---------|-----------| | Card format | Google Chat Cards | | Buttons | Yes | | Link buttons | Yes | | Select menus | Yes | | Tables | ASCII | | Fields | Yes | | Images in cards | Yes | | Modals | No |

Conversations

| Feature | Supported | |---------|-----------| | Slash commands | No | | Mentions | Yes | | Add reactions | Yes (via Workspace Events) | | Remove reactions | Yes (via Workspace Events) | | Typing indicator | No | | DMs | Yes (requires delegation) | | Ephemeral messages | Yes (native) |

Message history

| Feature | Supported | |---------|-----------| | Fetch messages | Yes | | Fetch single message | No | | Fetch thread info | Yes | | Fetch channel messages | Yes | | List threads | Yes | | Fetch channel info | Yes | | Post channel message | Yes |

Limitations

• Typing indicators: Not supported by Google Chat API. startTyping() is a no-op.
• Adding reactions: The Google Chat API doesn't support service account (app) authentication for adding reactions. To use addReaction() or removeReaction(), you need domain-wide delegation with impersonateUser configured — but the reaction appears as coming from the impersonated user, not the bot.

Message history (fetchMessages)

Fetching message history requires domain-wide delegation with the impersonateUser config option set. The impersonated user must have access to the spaces you want to read from. See the Pub/Sub setup above for configuring delegation and OAuth scopes.

Troubleshooting

401 Unauthorized on webhooks

• For direct webhooks: verify GOOGLE_CHAT_PROJECT_NUMBER matches your GCP project number (not project ID)
• For Pub/Sub: verify GOOGLE_CHAT_PUBSUB_AUDIENCE matches the audience configured on your push subscription
• Check that authentication is enabled on your Pub/Sub push subscription
• Ensure the service account used for push authentication has the Service Account Token Creator role

No webhook received

• Verify the App URL is correct in Google Chat configuration
• Check that the Chat API is enabled
• Ensure the service account has the necessary permissions

Pub/Sub not working

• Verify [email protected] has Pub/Sub Publisher role
• Check that the push subscription URL is correct
• Verify domain-wide delegation is configured with correct scopes
• Check GOOGLE_CHAT_IMPERSONATE_USER is a valid admin email

"Permission denied" for Workspace Events

• Ensure domain-wide delegation is configured
• Verify the OAuth scopes are exactly as specified
• Check that the impersonated user has access to the spaces

"Insufficient Permission" for DMs

• DMs require domain-wide delegation with chat.spaces and chat.spaces.create scopes
• Scope changes can take up to 24 hours to propagate

Button clicks not received

• Verify Interactive features is enabled in the Google Chat app configuration
• Check that the App URL is correctly set and accessible
• Button clicks go to the same webhook URL as messages

License

MIT
