React Native Painting Scanner

Live painting detection library. Returns either a URI or a base64 encoded string of the captured image, allowing you to easily store it or use it as you wish !

Features :

• Live detection
• Perspective correction and crop of the image
• Color preservation (no grayscale conversion)
• Live camera filters (brightness, saturation, contrast)
• Flash
• Easy to use base64 image

Can be easily plugged with react-native-perspective-image-cropper

Both Platform

Use version >=1.4.1 if you are using react-native 0.48+

$ npm install @faizan2002-npm/react-native-painting-scanner

$ react-native link @faizan2002-npm/react-native-painting-scanner

Edit the info.plist file in XCode and add the following permission : NSCameraUsageDescription

Remember, this library uses your device camera, you can't run it on a simulator.

Android Only

If you do not have it already in your project, you must link openCV in your settings.gradle file

include ':openCVLibrary310'
project(':openCVLibrary310').projectDir = new File(rootProject.projectDir,'../node_modules/@faizan2002-npm/react-native-painting-scanner/android/openCVLibrary310')

In android/app/src/main/AndroidManifest.xml

Change manifest header to avoid "Manifest merger error". After you add xmlns:tools="http://schemas.android.com/tools" should look like this:

<manifest xmlns:android="http://schemas.android.com/apk/res/android" package="com.<yourAppName>" xmlns:tools="http://schemas.android.com/tools">

Add tools:replace="android:allowBackup" in <application tag. It should look like this:

<application tools:replace="android:allowBackup" android:name=".MainApplication" android:label="@string/app_name" android:icon="@mipmap/ic_launcher" android:allowBackup="false" android:theme="@style/AppTheme">

Add Camera permissions request:

<uses-permission android:name="android.permission.CAMERA" />

Usage

import React, { Component } from "react";
import { View, Image } from "react-native";

import DocumentScanner, { PerspectiveCrop } from "@faizan2002-npm/react-native-painting-scanner";

class YourComponent extends Component {
  render() {
    return (
      <View>
        <DocumentScanner
          useBase64
          saveInAppDocument={false}
          onPictureTaken={data =>
            this.setState({
              image: data.croppedImage,
              initialImage: data.initialImage,
              rectangleCoordinates: data.rectangleCoordinates
            })
          }
          overlayColor="rgba(255,130,0, 0.7)"
          enableTorch={false}
          brightness={0.3}
          saturation={1}
          contrast={1.1}
          quality={0.5}
          onRectangleDetect={({ stableCounter, lastDetectionType }) =>
            this.setState({ stableCounter, lastDetectionType })
          }
          detectionCountBeforeCapture={5}
          detectionRefreshRateInMS={50}
          onPermissionsDenied={() => console.log("Permissions Denied")}
        />
        <Image
          resizeMode="contain"
        />
      </View>
    );
  }
}

Perspective Cropping

The library now includes a native component for manual perspective correction, complete with a magnifier for precision.

import { PerspectiveCrop } from "@faizan2002-npm/react-native-painting-scanner";

// ...

<PerspectiveCrop
  style={{ width: '100%', height: 400 }}
  imagePath={this.state.initialImage}
  rectangleCoordinates={this.state.rectangleCoordinates}
  ref={ref => this.cropView = ref}
/>

// To crop:
import { NativeModules, findNodeHandle } from 'react-native';

const crop = async () => {
    const handle = findNodeHandle(this.cropView);
    const croppedImage = await NativeModules.RNPerspectiveCropViewManager.crop(handle);
    console.log("Cropped Base64:", croppedImage);
};

Properties

| Prop | Platform | Default | Type | Description | | :-------------------------- | :------: | :-----: | :-------: | :---------------------------------------------------------------- | | overlayColor | Both | none | string | Color of the detected rectangle : rgba recommended | | detectionCountBeforeCapture | Both | 5 | integer | Number of correct rectangle to detect before capture | | detectionRefreshRateInMS | iOS | 50 | integer | Time between two rectangle detection attempt | | enableTorch | Both | false | bool | Allows to active or deactivate flash during painting detection | | useFrontCam | iOS | false | bool | Allows you to switch between front and back camera | | brightness | iOS | 0 | float | Increase or decrease camera brightness. Normal as default. | | saturation | iOS | 1 | float | Increase or decrease camera saturation. Set 0 for black & white | | contrast | iOS | 1 | float | Increase or decrease camera contrast. Normal as default | | quality | iOS | 0.8 | float | Image compression. Reduces both image size and quality | | useBase64 | iOS | false | bool | If base64 representation should be passed instead of image uri's | | saveInAppDocument | iOS | false | bool | If should save in app document in case of not using base 64 | | captureMultiple | iOS | false | bool | Keeps the scanner on after a successful capture | | onPermissionsDenied | android | null | func | Function to call when the Android permissions are denied |

Manual capture

• First get component ref

<DocumentScanner ref={ref => (this.scanner = ref)} />

• Then call :

this.scanner.capture();

Each rectangle detection (iOS only)

| Props | Params | Type | Description | | ----------------- | -------------------------------------- | -------- | ----------- | | onRectangleDetect | { stableCounter, lastDetectionType } | object | See below |

The returned object includes the following keys :

• stableCounter

Number of correctly formatted rectangle found (this number triggers capture once it goes above detectionCountBeforeCapture)

• lastDetectionType

Enum (0, 1 or 2) corresponding to the type of rectangle found

0. Correctly formatted rectangle
1. Wrong perspective, bad angle
2. Too far

Returned image

| Prop | Params | Type | Description | | :------------- | :----: | :------: | :------------------------------------------------------------------------------------------------------------------------------------------------------------------------ | | onPictureTaken | data | object | Returns the captured image in an object { croppedImage: ('URI or BASE64 string'), initialImage: 'URI or BASE64 string', rectangleCoordinates: 'object of coordinates' } |

Save in app document

If you want to use saveInAppDocument options, then don't forget to add those raws in .plist :

<key>LSSupportsOpeningDocumentsInPlace</key>
<true/>
