@kaminos/webgpu-inference-kit

A composable browser-native WebGPU inference runtime for model ports that need direct control over execution, scheduling, tensors, buffers, shared devices, and memory residency.

Use this package when you are porting a model to browser WebGPU and you do not want to rebuild the same runtime shell again: device acquisition, shader and pipeline caching, typed tensors, buffer upload and readback, phase programs, background queues, multi-route scheduling, shared resource residency, progress, cancellation, and device-loss recovery boundaries.

Strict route and run identity travels with the runtime so composed pipelines can distinguish live model output from stale, partial, cached, or fallback results.

Install

npm install @kaminos/webgpu-inference-kit

Start Here When Porting A Model

import {
  WEBGPU_BUFFER_USAGE,
  WEBGPU_HOST_PHASE,
  createForegroundBudgetGovernor,
  createWebGpuCommandDutyObservationFromReport,
  createWebGpuCommandDutyDescriptor,
  createWebGpuCommandDutyObservation,
  createWebGpuInferenceRuntime,
  createWebGpuSchedulerApplication,
} from "@kaminos/webgpu-inference-kit";

const routeId = "sam3.segment-anything.webgpu-local.v0";
const runtime = await createWebGpuInferenceRuntime({
  routeId,
  runtimeLabel: "sam3-browser-webgpu",
  gpu: navigator.gpu,
  adapterOptions: { powerPreference: "high-performance" },
  kernel: {
    profile: "sam3-mask-decoder-v0",
    commit: import.meta.env?.VITE_GIT_COMMIT ?? null,
  },
  requiredStages: ["encode-image", "decode-mask", "readback-mask"],
  hostPhases: {
    runId: crypto.randomUUID(),
    clock: {
      clockId: crypto.randomUUID(),
      source: "performance.now",
      timeOriginEpochMs: performance.timeOrigin,
    },
  },
  commandDuties: {
    runId: crypto.randomUUID(),
    clock: {
      clockId: crypto.randomUUID(),
      source: "performance.now",
      timeOriginEpochMs: performance.timeOrigin,
    },
  },
  yieldMs: 0,
  waitForSubmittedWorkDone: true,
});

const weights = runtime.createBuffer({
  label: "sam3.mask-decoder.weights",
  size: weightsBytes.byteLength,
  usage: GPUBufferUsage.STORAGE | GPUBufferUsage.COPY_DST,
});
runtime.writeBuffer(weights, weightsBytes);

const imageEmbedding = runtime.createTensor({
  name: "sam3.image-embedding",
  shape: [1, 256, 64, 64],
  dtype: "f16",
  usage: WEBGPU_BUFFER_USAGE.storage |
    WEBGPU_BUFFER_USAGE.copyDst |
    WEBGPU_BUFFER_USAGE.copySrc,
});
runtime.uploadTensor(imageEmbedding, imageEmbeddingBytes);

const outputMask = runtime.createTensor({
  name: "sam3.output-mask",
  shape: [1, 1, 64, 64],
  dtype: "f32",
  usage: WEBGPU_BUFFER_USAGE.storage | WEBGPU_BUFFER_USAGE.copySrc,
});

const params = runtime.createUniformBuffer({
  label: "sam3.mask-decoder.params",
  schema: [
    { name: "width", type: "u32" },
    { name: "height", type: "u32" },
    { name: "threshold", type: "f32" },
  ],
  values: { width: 64, height: 64, threshold: 0.5 },
});

await runtime.runStage("encode-image", async stage => {
  const module = stage.getShaderModule("sam3.image-encoder", imageEncoderWgsl);
  const pipeline = stage.getComputePipeline("sam3.image-encoder", {
    layout: "auto",
    compute: { module, entryPoint: "main" },
  });

  // Encode commands, submit work, then yield at a real boundary if this phase is long.
  await stage.yieldToBrowser({ reason: "between-image-encoder-tiles" });
});

const maskProgram = runtime.defineProgram({
  name: "sam3.mask-program",
  tensors: { imageEmbedding, outputMask },
  uniforms: { params },
  kernels: {
    decodeMask: {
      code: maskDecoderWgsl,
      bindings: [
        { name: "imageEmbedding", resource: "tensor:imageEmbedding", access: "read-only-storage" },
        { name: "params", resource: "uniform:params", type: "uniform" },
        { name: "outputMask", resource: "tensor:outputMask", access: "storage" },
      ],
    },
  },
  phases: [
    {
      name: "decode-mask",
      kernel: "decodeMask",
      dispatch: [8, 8, 1],
      yieldAfter: true,
      commandDuty: {
        chunkControl: {
          controlId: "maskDecoderTiles",
          unit: "mask-decoder-tile",
          current: 8,
          bounds: { min: 1, max: 8, stepFactor: 2 },
        },
      },
    },
    { name: "readback-mask", readbacks: [{ name: "maskBytes", tensor: "outputMask" }] },
  ],
});
const programResult = await runtime.runProgram(maskProgram);
const maskBytes = programResult.outputs.maskBytes;

const profile = runtime.finishProfile({
  evidence: { mode: "live", source: "sam3-browser-webgpu-route" },
});
const hostPhaseReport = runtime.finishHostPhases();
const commandDutyReport = runtime.finishCommandDuties();

That profile is the runtime receipt substrate a route can attach to its outputs. It records the effective adapter/device identity, kernel profile, stage timings, required stages, and yield metadata for the run that actually happened.

Load And Share Model Weights

A shared inference session can verify one content-addressed weight bundle, upload its packed allocation ranges once, and give every registered route an independent lease over the same GPU buffers:

import {
  WEBGPU_BUFFER_USAGE,
  createWebGpuInferenceSession,
  defineWebGpuModelResourceManifest,
  prepareWebGpuModelResourceBundle,
} from "@kaminos/webgpu-inference-kit";

const manifest = defineWebGpuModelResourceManifest({
  modelId: "acme/vision-model",
  revision: "0123456789abcdef",
  bundle: {
    byteLength: weightBytes.byteLength,
    sha256: publishedWeightSha256,
  },
  allocations: [{
    allocationId: "decoder",
    byteOffset: 0,
    byteLength: weightBytes.byteLength,
    usage: WEBGPU_BUFFER_USAGE.storage | WEBGPU_BUFFER_USAGE.copyDst,
    tensors: [
      {
        name: "decoder.weight",
        dtype: "f16",
        shape: [256, 256],
        byteOffset: 0,
        byteLength: 256 * 256 * 2,
      },
      {
        name: "decoder.bias",
        dtype: "f16",
        shape: [256],
        byteOffset: 256 * 256 * 2,
        byteLength: 256 * 2,
      },
    ],
  }],
});

const session = await createWebGpuInferenceSession({
  sessionId: crypto.randomUUID(),
  gpu: navigator.gpu,
});
const sharp = await session.registerRoute({ routeId: "sharp.image-to-splat.webgpu-local.v0" });
const sf3d = await session.registerRoute({ routeId: "sf3d.image-to-mesh.webgpu-local.v0" });
const preparedWeights = await prepareWebGpuModelResourceBundle(
  manifest,
  weightBytes.buffer,
  { ownership: "transfer" },
);

const [sharpWeights, sf3dWeights] = await Promise.all([
  sharp.loadModelResources({ manifest, bundle: preparedWeights }),
  sf3d.loadModelResources({ manifest, bundle: preparedWeights }),
]);

sharpWeights.tensors["decoder.weight"].buffer ===
  sf3dWeights.tensors["decoder.weight"].buffer; // true

// Tensor views expose buffer, bufferOffset, byteLength, shape, strides, and dtype,
// so they can be bound directly by runtime kernels and phase programs.
const decoderWeight = sharpWeights.tensors["decoder.weight"];

sharpWeights.release();
sf3dWeights.release();
preparedWeights.release();

Resource sharing is semantic by default. Model id, revision, manifest metadata, allocation metadata, tensor layout and metadata, bundle bytes, range, and usage all participate in the authenticated allocation identity. Equal bytes under different model semantics therefore produce different resident buffers.

Cross-semantic physical deduplication is available only as an explicit manifest policy:

const sharedPhysicalManifest = defineWebGpuModelResourceManifest({
  ...manifestInput,
  resourceSharing: { policy: "content-addressed-physical-dedupe" },
});

That policy selects the content-addressed physicalResourceId for residency while retaining a distinct semanticResourceId and semanticLeaseId on every returned allocation and tensor view. Callers can inspect both identities instead of treating byte equality as semantic authorization.

Raw bundle input uses an owned byte snapshot, then hashes those exact bytes with Web Crypto before any GPU allocation. prepareWebGpuModelResourceBundle() makes ownership explicit: copy preserves mutable caller input, while transfer accepts a full ArrayBuffer, detaches it, and verifies/uploads the transferred storage without the loader allocating its own second full-size byte array. Transfer is ownership-consuming even when digest verification later fails; use copy when the caller must retain retry bytes. Prepared handles are module-authenticated, bound to the complete normalized manifest, do not expose mutable bytes, and reject reuse after release. Bundle length or digest mismatch fails before upload. Concurrent loads single-flight each policy-selected allocation identity, while cancellation and partial failure release every model lease already acquired. Released GPU buffers remain visible in session residency as explicit eviction candidates until caller policy evicts them; they are not reported as an active model.

What The Kit Gives A Port

• createWebGpuInferenceRuntime(input): acquire or wrap a browser WebGPU device, preserve backend identity, expose runtime helpers, time named stages, and finish a runtime profile.
• createWebGpuResourceCaches(device): cache shader modules and compute pipelines by label plus descriptor so repeated stage invocations do not rebuild obvious resources.
• createCooperativeYield(input): standardize cooperative browser yields, optionally waiting for queue.onSubmittedWorkDone() before yielding to the event loop.
• createForegroundBudgetGovernor(input): adapt cooperative yield time or named phase chunk sizes from attributed foreground frame pressure while failing closed when route, host, and GPU duty evidence is incomplete or ambiguous.
• createWebGpuSchedulerApplication(input): bind adaptive decisions to one route and one declared control set, preserve submitted work as non-preemptible, and let active invocations consume newer exact revisions only at explicit pre-encoding boundaries.
• createWebGpuCommandDutyDescriptor(input) and createWebGpuCommandDutyObservation(input): describe non-preemptible submitted command work, preserve uncapped measured duty, and bind reusable chunk controls to effective route/run/clock identity.
• createWebGpuCommandDutyRecorder(input) and createWebGpuCommandDutyObservationFromReport(report, input): capture runtime-owned submissions automatically, preserve honest host-submit timing authority, and join a complete external measurement set into governor-ready duty observations.
• createWebGpuHostPhaseRecorder(input): record uncapped, route/run/clock-bound CPU preprocessing, command encoding, queue submission, readback, presentation, and custom host intervals while preserving failed phases and the last trustworthy interval.
• runtime.createBuffer(descriptor), runtime.writeBuffer(buffer, data, ...), and runtime.readBuffer(buffer, options): small buffer helpers for model weights, activations, and readback paths.
• runtime.createTensor(input), runtime.uploadTensor(tensor, data), and runtime.readTensor(tensor): create GPU-backed tensors with dtype, shape, strides, byte-length validation, and upload/readback helpers.
• packUniforms(schema, values) and runtime.createUniformBuffer(input): pack small scalar/vector parameter blocks into WGSL-compatible uniform buffers and update them without hand-rolling offsets.
• runtime.defineComputeKernel(input) and runtime.runKernel(kernel, options): build bind group layouts, bind groups, pipeline layouts, compute pipelines, command encoders, compute passes, dispatches, submits, and stage profile entries from one kernel descriptor.
• runtime.defineProgram(input) and runtime.runProgram(program): declare a small phase program above single-kernel dispatch, resolving named tensors/uniforms/buffers into kernel bindings, executing kernel phases, running readback phases, preserving staged profile metadata, and applying yield boundaries at phase edges.
• runtime.runInvocation(input, fn), runtime.applySchedulerDecision(decision), and runtime.schedulerSnapshot(): run arbitrary adapter code against a boundary-refreshable scheduler handle, apply guarded revisions while work is active, and inspect uncapped per-duty uptake history without claiming submitted-work preemption.
• runtime.createInferenceQueue(options): retain an uncapped FIFO of background jobs, run one route invocation at a time, record uncapped progress and terminal outcomes, cancel pending work, and preserve explicit between-job decision barriers for queued control changes.
• createWebGpuInferenceCoordinator(input): admit eligible heads from multiple route queues through one uncapped global FIFO, preserving route-local barriers, pending cancellation, and honest non-preemption boundaries.
• createWebGpuInferenceSession(input): own one browser WebGPU device, backend identity, and coordinator across explicitly registered route runtimes, with device-loss and idle-close lifecycle truth.
• createWebGpuResourceResidency(input): account for caller-declared GPU allocations once across routes, issue explicit route leases, retain released allocations as eviction candidates, and invalidate the whole ledger on device loss without claiming access to browser-global VRAM.
• createWebGpuResourceFactory(input): collapse concurrent asynchronous creation or weight-upload requests for one absent resource into a single abortable flight, then issue independent route leases over the one resulting object.
• defineWebGpuModelResourceManifest(input): freeze an exact model revision, bundle SHA-256, packed allocation ranges, and typed tensor views into a validated loading contract.
• verifyWebGpuModelResourceBundle(manifest, bundle): hash the effective bytes with Web Crypto and reject length or identity mismatch before GPU work.
• prepareWebGpuModelResourceBundle(manifest, bundle, options): establish a releasable, manifest-bound verified byte-custody handle using safe-copy or zero-copy ArrayBuffer transfer ownership.
• loadWebGpuModelResources(input) and route.loadModelResources(input): upload each content-derived allocation through shared single-flight residency and return one independently releasable model lease whose tensor views plug into kernels and phase programs.
• runtime.runStage(name, fn, metadata): wrap major model phases such as ViT encoder blocks, diffusion steps, triplane decode, mask decode, readback, or mesh/splat finalization.
• runtime.finishProfile(options): emit a kaminos.webgpu-runtime-profile.v0 profile that downstream routes and schedulers can consume.
• defineTensorManifest(input): normalize model tensor metadata, dtype sizes, byte lengths, offsets, and shapes for browser-loaded weight bundles.
• requestBrowserWebGpuDevice(gpu, options): request a device using adapter-reported limits without silently imposing smaller caps.

Host Phases And Foreground Coexistence

When hostPhases is configured, the runtime automatically records command encoding, queue submission, and mapped/staged readback around the operations it owns. A model adapter can record work outside those helpers with the same route, run, and clock identity:

const inputTensor = await runtime.runHostPhase(
  WEBGPU_HOST_PHASE.cpuPreprocess,
  () => preprocessImage(sourceImage),
  { detail: { width: sourceImage.width, height: sourceImage.height } },
);

await runtime.runHostPhase(
  WEBGPU_HOST_PHASE.presentation,
  () => presentProgressiveResult(partialResult),
  { detail: { iteration } },
);

runtime.finishHostPhases() returns every completed interval with effective route, run, monotonic clock, epoch projection, outcome, and failure identity. projectWebGpuHostPhaseEvents(report, expectations) converts a complete snapshot into foreground-correlation events only when the caller's expected route, run, and clock all match. This lets a scheduler distinguish host work from submitted GPU duty without joining unrelated pages or stale runs on timestamps alone.

Submitted WebGPU command buffers cannot be preempted after queue.submit(). Ports expose the useful control boundary before submission with a command-duty descriptor:

const descriptor = createWebGpuCommandDutyDescriptor({
  routeId,
  runId,
  clockId,
  dutyId: `${runId}:attention:12`,
  phase: "triplane-attention",
  kind: "compute",
  chunkControl: {
    controlId: "attentionTiles",
    unit: "attention-tile",
    current: scheduler.phaseChunkSize.attentionTiles,
    bounds: { min: 1, max: 16, stepFactor: 2 },
  },
});

const commandDutyObservation = createWebGpuCommandDutyObservation({
  routeId,
  runId,
  clockId,
  firingId,
  duties: [{
    descriptor,
    observedDurationMs: 24.8,
    foregroundOverlapDurationMs: 19.2,
  }],
});

Observations retain every duty and reject capped, stale, duplicate, identity-mismatched, or incoherent input. The foreground governor can consume commandDutyObservation directly and reduce its declared controlId without a model-specific phase map. Descriptors without a chunk control remain useful attribution and cause the governor to donate yield time instead of inventing a split point.

When commandDuties is configured on the inference runtime, runKernel() records every submitted compute command and staged tensor readbacks record copy commands automatically. runtime.finishCommandDuties() returns the uncapped report. Its timestamps describe the host call to queue.submit() only; they do not claim GPU completion or isolated execution duration. Join the report with complete measured duty rows before asking the governor to act:

const commandDutyObservation = createWebGpuCommandDutyObservationFromReport(
  commandDutyReport,
  {
    firingId,
    expectedRouteId: routeId,
    expectedRunId: commandDutyReport.runId,
    expectedClockId: commandDutyReport.clock.clockId,
    measurements: measuredDuties,
  },
);

Projection fails on recording prefixes, failed submissions, stale identity, capped or partial reports, corrupt submission timing, and missing, duplicate, or foreign measurements. Recorder failures remain visible in the report but cannot turn an already successful queue submission into an inference failure.

Route Composition Layer

The runtime helpers are the lowest useful layer. Route helpers sit above them so model ports can compose inside Kaminos without every repo inventing its own envelope:

• defineWebGpuRoute(input), createWebGpuRouteRegistry(routes), createRouteInvocationRequest(route, input), createRouteWorkerResult(route, input), and validators define worker-executable browser-local inference routes.
• createMogeDepthNormalRouteDefinition(input) and createMogeDepthNormalRouteReceipt(input) define the MoGE source-image to depth/normal/pointmap route.
• createSharpImageToSplatRouteDefinition(input) and createSharpImageToSplatRouteReceipt(input) define the SHARP source-image to splat candidate/depth/metadata route.
• createKimodoTextToMotionRouteDefinition(input) and createKimodoTextToMotionRouteReceipt(input) define the Kimodo text-prompt to SOMA77 joints/motion-clip route.
• createSf3dImageToMeshRouteDefinition(input) and createSf3dImageToMeshRouteReceipt(input) define the Stable Fast 3D source-image to mesh/albedo/normal route.

These route definitions are not meant to trap future ports into MoGE/SHARP/Kimodo/SF3D. They are examples of the current shared grammar: route id, input roles, output roles, backend kind, model identity, kernel/stage identity, scheduler posture, and output artifacts.

Scheduler And Breathability Layer

Long browser WebGPU routes need to say how they behave under contention. The package exposes:

• createWebGpuRouteSchedulerProfile(input) and validateWebGpuRouteSchedulerProfile(profile) for requested versus effective scheduling, phase chunk sizes, yield cadence, submitted-work waits, breathability spans, checkpoints, and unsupported fields.
• createSchedulerVerificationReceipt(input) and classifySchedulerVerificationReceipt(receipt) for observation-bound scheduler proof. A route is not verified just because a config asked it to yield; observed events and boundary assertions must agree.
• createWebGpuRouteBackpressureProfile(input) and validateWebGpuRouteBackpressureProfile(profile) for visible-wait/furnace pressure, warm/cache posture, memory-sharing posture, and frame-tail impact.
• createWebGpuCommandDutyDescriptor(input) and createWebGpuCommandDutyObservation(input) for portable command-boundary attribution and adaptive chunk-control selection across model ports.
• createWebGpuCommandDutyRecorder(input) and createWebGpuCommandDutyObservationFromReport(report, input) for automatic runtime submission capture and strict measured-duty projection.
• createForegroundBudgetGovernor(input) for a long-lived adaptive control loop. The caller supplies scheduler bounds, attribution policy, hysteresis, and an episodeEpochId; each observation carries the same epoch plus a unique episode/firing identity. Exact replays cannot vote twice. forgetEpisode() and clearDecisionHistory() discard cached decisions while preserving replay protection, and beginEpisodeEpoch(nextId) is the explicit boundary that reclaims those identities and resets hysteresis while preserving the tuned scheduler.
• createWebGpuSchedulerApplication(input) for guarded application of governor decisions. It rejects foreign routes, skipped/stale/replayed revisions, undeclared controls, bounds mismatches, capped boundary retention, duplicate boundaries, and refresh attempts anywhere except an explicit before-encode boundary. Applying a revision while an invocation is active changes future invocations immediately but changes that active invocation only when it reaches its next boundary.
• validateSharpBreathingRoomComparisonEvidence(comparison) and classifySharpBreathingRoomComparisonEvidence(comparison) for the current SHARP default-vs-cooperative comparison contract.

This is the layer that should help SHARP, SF3D, Kimodo, image generators, and future long routes become breathable enough to coexist with rendering or other inference work in the same browser GPU process.

const scheduler = {
  mode: "cooperative",
  yieldMs: 4,
  waitForSubmittedWorkDone: true,
  phaseChunkSize: { attentionTiles: 16 },
};
const bounds = {
  yieldMs: { min: 0, max: 16, step: 2 },
  phaseChunkSize: {
    attentionTiles: { min: 1, max: 16, stepFactor: 2 },
  },
};
const schedulerApplication = createWebGpuSchedulerApplication({
  routeId,
  revision: 0,
  scheduler,
  bounds,
});
const runtime = await createWebGpuInferenceRuntime({
  routeId,
  gpu: navigator.gpu,
  kernel,
  schedulerApplication,
});
const governor = createForegroundBudgetGovernor({
  routeId,
  episodeEpochId: crypto.randomUUID(),
  targetFrameGapMs: 50,
  failureWindowsBeforeAdjust: 2,
  successWindowsBeforeRelax: 3,
  scheduler,
  bounds,
  attributionPolicy: {
    minimumCoveredFraction: 0.8,
    maximumSharedFraction: 0.25,
  },
});

const result = await runtime.runInvocation(
  { invocationId: crypto.randomUUID() },
  async invocation => {
    const tileCount = invocation.getControl("attentionTiles");
    return runAttentionInTiles({ tileCount, yieldToBrowser: invocation.yieldToBrowser });
  },
);

const decision = governor.observe({
  episodeEpochId: governor.snapshot().episodeEpochId,
  episodeId: routeRunId,
  firingId: routeRunId,
  frameTail,
  hostEventCorrelation,
  sharpDutyCorrelation: gpuDutyCorrelation,
  executionIdentity: { routeId, runId, clockId },
  commandDutyObservation,
});
if (decision.schedulerChanged) runtime.applySchedulerDecision(decision);

runProgram() opens and closes one invocation automatically. Before every compute or staged-readback command is encoded, the runtime refreshes that invocation to the newest valid scheduler revision, resolves any matching commandDuty.chunkControl, and later stores the exact boundary receipt in the submitted duty descriptor. Boundary rows begin as pending-encode-validation, settle to encoded, or fail as failed-before-encode with an exact phase; ending an invocation with an unsettled boundary fails it explicitly. Pending and encoded boundaries say submission is not-claimed; only a pre-encoding failure says not-submitted. The uncapped application snapshot proves boundary uptake and encoding outcome, while the command-duty report separately proves which encoded duties reached queue.submit(). Together they name requested and effective revision, yield delay, phase controls, route, invocation, phase, duty, and failure without relabeling old work. Custom raw-queue adapters call invocation.refreshAtBoundary({ boundaryId, dutyId, phase, position: "before-encode" }), consume invocation.getControl(controlId) to choose the next bounded duty, and call invocation.settleBoundary({ boundaryId, status: "encoded" }) only after encoding succeeds; failures settle with status: "failed-before-encode", phase, and error. runtime.runKernel() and staged readback perform that lifecycle automatically. Nothing here pretends an already submitted command buffer can be split or preempted.

Background Inference Queue

Long routes such as SHARP and SF3D are often better product citizens as a continuous background queue than as a modal wait. A runtime-bound queue serializes full invocations while allowing the product to submit many jobs immediately:

const inferenceQueue = runtime.createInferenceQueue();

const job = inferenceQueue.enqueue({
  jobId: crypto.randomUUID(),
  metadata: { sourceImageName: file.name },
  async execute(invocation) {
    return runSharpInference({
      sourceImage,
      spnFusionOutputItems: invocation.getControl("spnFusionOutputItems"),
      yieldToBrowser: invocation.yieldToBrowser,
      onProgress(progress) {
        invocation.reportProgress(progress);
      },
    });
  },
});

const completion = await job.completion;
if (completion.status === "succeeded") showAsset(completion.output);

job.cancel(reason) cancels only a pending job. Once its invocation has started, the handle returns not-cancelled-active; it never implies that submitted WebGPU work was preempted. completion always resolves to a terminal record (succeeded, failed, or cancelled-before-start) with route/job identity, scheduler revision, uncapped progress, and explicit output/failure presence.

Adaptive decisions enter the queue as control barriers:

const applicationReceipt = await inferenceQueue.scheduleSchedulerDecision(decision);

A queued decision waits for the active invocation to finish and applies before the next pending job. The queue owns an immutable copy of the decision, records applied and failed control attempts, and continues processing after job or decision failure. snapshot() exposes every retained job and decision without a hidden cap; forgetJob(jobId) is the explicit reclamation boundary, and drain() resolves once no job, decision, or active invocation remains.

Multi-Route Admission

SHARP, SF3D, Kimodo, and other long routes can share one admission coordinator while keeping separate route runtimes and queues:

const coordinator = createWebGpuInferenceCoordinator();
const sharpRuntime = await createWebGpuInferenceRuntime({
  routeId: SHARP_IMAGE_TO_SPLAT_ROUTE_ID,
  device,
  adapterName,
  admissionCoordinator: coordinator,
});
const sf3dRuntime = await createWebGpuInferenceRuntime({
  routeId: SF3D_IMAGE_TO_MESH_ROUTE_ID,
  device,
  adapterName,
  admissionCoordinator: coordinator,
});

const sharpQueue = sharpRuntime.createInferenceQueue();
const sf3dQueue = sf3dRuntime.createInferenceQueue();

Each queue offers only its locally eligible head job after scheduler barriers have applied. The coordinator grants those heads in global FIFO order, so one route cannot reserve the browser GPU with its entire backlog. Pending jobs can cancel while awaiting admission; active invocations remain explicitly non-preemptible. Coordinator snapshots retain every admission until forgetAdmission(sequence), and drain() resolves only when no admission is active, pending, or scheduled.

Shared Inference Session

Use a session when several routes should share the same physical WebGPU device and admission coordinator:

const session = await createWebGpuInferenceSession({
  sessionId: crypto.randomUUID(),
  gpu: navigator.gpu,
  adapterName: "browser-primary-adapter",
});

const sharp = await session.registerRoute({
  routeId: SHARP_IMAGE_TO_SPLAT_ROUTE_ID,
  runtimeOptions: { schedulerApplication: sharpScheduler },
});
const sf3d = await session.registerRoute({
  routeId: SF3D_IMAGE_TO_MESH_ROUTE_ID,
});

const sharpWeightLease = sharp.acquireResource({
  resourceId: "dinov2.vitl14.weights.f16",
  declaredBytes: sharpWeightBuffer.size,
  kind: "model-weight",
  metadata: { precision: "f16" },
  resource: sharpWeightBuffer,
});
const sf3dWeightLease = sf3d.acquireResource({
  resourceId: "dinov2.vitl14.weights.f16",
  declaredBytes: sharpWeightBuffer.size,
  kind: "model-weight",
  metadata: { precision: "f16" },
});

const sharpJob = sharp.enqueue({
  jobId: crypto.randomUUID(),
  execute: invocation => runSharpInference(sharp.runtime, invocation),
});

await sharpJob.completion;
sharpWeightLease.release();
sf3dWeightLease.release();

const candidate = session.residency.snapshot().evictionCandidates.find(
  resource => resource.resourceId === "dinov2.vitl14.weights.f16",
);
if (candidate) {
  session.residency.evict(candidate.resourceId);
  sharpWeightBuffer.destroy();
}

The session retains route registrations until unregisterRoute(routeId). Route handles share one residency runtime and acquire resources under their own route identity. The first acquisition supplies the live WebGPU object; later routes acquiring a matching descriptor receive that identical object from their lease. One global declared-byte allocation then serves every active route lease. Conflicting descriptors or different live objects for the same identity fail loud.

Releasing the last lease makes an allocation eligible for eviction. Borrowed resources remain caller-owned, so the caller explicitly evicts the record and disposes the WebGPU object. A resource acquired with ownership: "managed" and dispose(resource) instead transfers disposal to the residency runtime; explicit eviction or orderly session close invokes its disposer exactly once. Device loss clears references without claiming a redundant destroy of already-invalid GPU objects.

Residency snapshots expose exact caller-declared bytes, not browser-global VRAM usage. They retain every resource until explicit forget(resourceId), preserve zero-byte route participation after release, and never impose a hidden memory cap. unregisterRoute() and close() reject active resource leases so ownership cannot disappear silently.

When several routes may request the same absent allocation concurrently, create it through the route-scoped factory instead of racing independent uploads:

const lease = await sharp.residency.acquireOrCreate({
  resourceId: "dinov2.vitl14.weights.f16",
  declaredBytes: weightsBytes.byteLength,
  kind: "model-weight",
  metadata: { precision: "f16" },
  signal: abortController.signal,
  async create({ signal }) {
    const buffer = sharp.runtime.createBuffer({
      label: "dinov2.vitl14.weights.f16",
      size: weightsBytes.byteLength,
      usage: GPUBufferUsage.STORAGE | GPUBufferUsage.COPY_DST,
    });
    if (signal.aborted) throw signal.reason;
    sharp.runtime.writeBuffer(buffer, weightsBytes);
    return buffer;
  },
  dispose(buffer) { buffer.destroy(); },
});

Every concurrent matching requester joins one creator and receives the same lease.resource. Cancellation removes only that waiter while others remain; cancelling every waiter aborts the creator. Failed flights remain visible and a later request starts a new generation. Created resources are managed because a runtime-created GPU object without owned disposal is a leak. Flight history is uncapped until explicit forgetFlight(flightId).

Managed route handles also gate enqueue and scheduler changes after device loss while still exposing each runtime for adapter kernels and buffers. If device.lost resolves, the session preserves the opaque browser reason/message, cancels pending jobs, rejects new managed work, invalidates all residency accounting, and leaves active work to complete or fail without claiming preemption. Recovery requires a new session and rebuilt device resources.

close() requires every route queue to be idle. It destroys a device requested by the session and leaves a borrowed device untouched. session.deviceLost remains the exact asynchronous loss record, including intentional destroyed loss after an owned session closes.

Receipt And Evidence Layer

Receipts answer: did this output actually come from the route, backend, model, and kernel the consumer thinks it did?

• createWebGpuLocalRouteReceipt(input), createWebGpuRouteReceiptFromArtifacts(input), createRouteReceiptArtifacts(input), finishAndValidateRouteProfile(input), validateRouteReceipt(receipt), and assertAuthoritativeRouteReceipt(receipt) construct and validate route receipts.
• classifyWebGpuRouteReceiptEvidence(receipt) and classifyWebGpuRouteWorkerResultEvidence(result) distinguish authoritative live WebGPU output from fallback, cached, partial, stale, invalid, and route-mismatched output.
• createWebGpuRouteSchemaContract(input) gives route repos a compact conformance object for tests.

This layer matters because composition without identity is how a browser pipeline lies to itself. It should protect runtime work, not replace it.

Current Direction

1. Make this package the first import a new browser WebGPU model port reaches for.
2. Keep extracting runtime chores only when at least two real routes need them or one port exposes a clearly reusable primitive.
3. Keep route receipts and scheduler verification strict enough that downstream systems can compose outputs without false authority.
4. Use MoGE, SHARP, Kimodo, SF3D, and SAM-style segmentation/image-generation ports to discover the next runtime primitives: bind-group layout helpers, uniform packing, tensor views, buffer pools, command submission patterns, tiled attention, and cooperative phase splitting.
5. Expand model and graph coverage where browser-native control over scheduling, memory, kernels, or composition produces a measured advantage.
