@phyrex/ascii-canvas

Drop-in Web Component that turns any image, video, or canvas into live ASCII art.

   +------------------+        +-----------------------+
   |   <img>          |        |                       |
   |   <video>        |  --->  |   <ascii-canvas>      |
   |   <canvas>       |        |                       |
   +------------------+        +-----------------------+
       any source                   ASCII output

Live demo → · Live2D variant →

• ~2.3 KB gzipped, ESM only
• Zero deps — no React, Vue, three.js, or pixi
• Works in any framework via Custom Elements
• Auto-pauses when scrolled offscreen, respects prefers-reduced-motion

Quick start

CDN

<ascii-canvas id="ac" style="width: 320px; aspect-ratio: 1/1;"></ascii-canvas>
<script type="module">
  import "https://esm.sh/@phyrex/ascii-canvas";

  const img = new Image();
  img.crossOrigin = "anonymous";
  img.src = "https://example.com/cat.jpg";
  img.onload = () => { document.getElementById("ac").source = img; };
</script>

npm

npm install @phyrex/ascii-canvas

import "@phyrex/ascii-canvas";

const ac = document.querySelector("ascii-canvas");
ac.source = someCanvasOrVideoOrImage;

The element registers itself as <ascii-canvas> on import. Set its CSS size; the grid is computed from width / cell-w × height / cell-h.

API

Attributes

| Attribute | Default | Description | |---|---|---| | ramp | " .:-=+*#%@" | Character set ordered dark→bright | | cell-w | 8 | Grid cell width in CSS pixels | | cell-h | 14 | Grid cell height in CSS pixels | | font-px | 12 | Output font size | | alpha-threshold | 16 | Skip cells whose source alpha is below this (0–255) | | paused | (absent) | When present, freezes rendering |

All attributes reflect to #opts via attributeChangedCallback. Changing cell-w / cell-h recomputes the grid.

Properties

| Property | Type | Description | |---|---|---| | source | HTMLImageElement \| HTMLVideoElement \| HTMLCanvasElement \| null | The drawable source. Setting null clears the output and stops the rAF loop. |

Methods

| Method | Description | |---|---| | pause() | Equivalent to setAttribute("paused", "") | | resume() | Equivalent to removeAttribute("paused") |

There is no getText(), no theming API, and no per-frame events. By design — see tasks.md D8/D9.

Lifecycle

The element automatically:

• Recomputes the grid via ResizeObserver when its container changes size
• Pauses the rAF loop when scrolled out of view (IntersectionObserver)
• Renders only one frame when prefers-reduced-motion: reduce
• Handles DPI: output canvas pixel dimensions are scaled by devicePixelRatio so text stays sharp on retina displays

How it works

  source                sample canvas              ascii ctx
  +------+   drawImage  +------+    getImageData   +-----+
  | img  |  ---------> | gridW |  ----------->    | drawAscii |
  | vid  |  (downscale) | gridH |   (RGBA bytes)   | (47 LOC)  |
  | cnv  |              +------+                   +-----+
  +------+                                              |
                                                        v
                                                output <ascii-canvas>

The 47-line core is a pure function: takes an ImageData already at grid resolution, picks a ramp character per cell by luminance, and fillTexts it onto the output canvas. Everything else is the wrapper — ResizeObserver, IntersectionObserver, prefers-reduced-motion, attribute reflection, DPR, source race handling.

Caveats

CORS

<img> from a different origin will not throw on drawImage, but getImageData (which the lib uses internally) will throw SecurityError: Tainted canvases may not be exported.

Fix: add crossorigin="anonymous" to the <img> and ensure the server returns proper CORS headers.

<img src="https://example.com/cat.jpg" crossorigin="anonymous">

SSR

Custom Elements need a DOM. In server-side rendering frameworks:

• Astro: import in a <script> tag or use client:load directive
• Next.js: import inside a useEffect or use next/dynamic with { ssr: false }
• Nuxt / SvelteKit: defer to client-only context

The element does nothing until connectedCallback fires in a browser.

Comparison

| Project | Status (May 2026) | Framework lock-in | Live source | |---|---|---|---| | drei <AsciiRenderer> | Active | three.js + react-three-fiber | Three.js scene only | | aalib.js | Last commit 2018 | None | Image / video | | textmode.js | Active | None | Image only, no Custom Element | | ts-ascii-engine | Young (<1yr) | None | Canvas | | ascii-image | Dead | None | Image only | | @phyrex/ascii-canvas | This | None | Image / video / canvas, Web Component |

Development

git clone https://github.com/phyrextsai/ascii-canvas
cd ascii-canvas
npm install
npm test                          # build + types + size + visual
npm run update-baseline           # regenerate Playwright snapshot locally
node assets/gen-banner.mjs > assets/banner.svg   # regenerate the README banner

CI runs all tests on Linux. The Playwright baseline is therefore Linux-only; macOS / Windows baselines are gitignored. To regenerate the Linux baseline without a Linux machine, trigger the update-baseline workflow in GitHub Actions.

License

MIT © 2026 Phyrex Tsai
