Directus Extension - Masked Interface

This is a fork of directus-extension-masked-interface by Adrian Dimitrov, updated to support Directus 10 and 11.

Original work copyright (C) 2020 Adrian Dimitrov. Modifications copyright (C) 2026 Ribertec. Licensed under GPL-3.0.

Input text string by template.

Features

• Masked text input using template patterns, RegEx, or built-in presets
• Compatible with Directus 10 and 11
• Supports string and numeric field types
• Optional masked or unmasked value storage
• Case transformation (uppercase, lowercase, title case)
• Configurable placeholder, icons, and font

Installation

Via Directus Marketplace (recommended): search for "Masked Interface" in the Marketplace.

Via npm:

npm install @ribertec/directus-extension-masked-interface

Restart Directus after installation.

Setup

1. Create a standard field with string (or numeric) type
2. For interface select Masked Input and configure the options below

Options

| Option | Description | | ----------------- | -------------------------------------------------------------------------- | | Placeholder | Placeholder text shown inside the input | | Font | Font family: Sans-serif, Monospace, or Serif | | Icon Left | Material Design icon displayed on the left | | Icon Right | Material Design icon displayed on the right | | Save masked value | When enabled, stores the formatted (masked) value instead of the raw input | | Format value | Apply case transformation: none, uppercase, lowercase, or title case | | Type | Masking type — see below | | Template | Pattern string (only for Template and RegEx types) |

Masking types

• Template — simplified templating pattern (see legend below)
• RegEx — uses a regular expression to define the pattern
• Presets:
  • URL
  • Email
  • IP Address (IPv4)
  • MAC Address (: separators)
  • VIN
  • SSN

Template pattern legend

| Character | Meaning | | --------- | --------------------- | | 9 | Number | | a | Lowercase letter | | A | Uppercase letter | | * | Alphanumeric | | \ | Escape next character | | \| | Alternator | | [] | Optional group | | () | Grouping | | {n,[m]} | Repeater |

How it works

The extension uses InputMask by @RobinHerbots as the masking library.

Requirements

• Directus 10 or 11

License

GPL-3.0 — see LICENSE for details.
