catmd

cat for markdown. Output is your file, verbatim — except where catmd can render something better in the terminal.

Feature #1: mermaid. ```mermaid fences become actual diagram images inline, in place of the fence source.

npm install -g @verano-20/cat-md

catmd DESIGN.md

(The npm package is scoped — catmd was squatted years ago — but the command it installs is plain catmd.)

Why

Terminal markdown renderers (glow, mdcat) print mermaid fences as code blocks — mermaid needs a browser engine to lay out. Browser previews take you out of the terminal. catmd renders each fence headlessly (via mermaid-cli) and paints the result straight into the terminal with the kitty graphics protocol.

• Uniform, readable text: every diagram is displayed so mermaid's base font matches your terminal's text height — computed live from your terminal's actual cell size — regardless of how big the diagram is.
• Zoom: each diagram gets a dim ⌕ zoom caption; cmd/ctrl+click opens the full-resolution PNG in your image viewer.
• Fast after the first look: renders are cached in ~/.cache/catmd. One browser instance renders every diagram in a doc; fully-cached docs never launch a browser at all.
• Safe in pipes: when stdout isn't a supported TTY, output is byte-identical to the input — it degrades to plain cat, so catmd x.md | grep … just works.
• Terminal-limit aware: kitty/Ghostty silently drop images over 10000px a side or over the image storage budget; catmd caps renders under both with a quality-preserving vector re-render.

Usage

catmd [options] [file]         # reads stdin when no file is given

--theme <name>       mermaid theme: default, dark, forest, neutral
--text-size <n>      diagram text height in terminal rows (default 1.0)
--force              emit images even when stdout is not a supported TTY

Invalid mermaid prints a warning to stderr and passes the original fence through; the rest of the document still renders.

Requirements

• Node >= 22.12. Installing pulls in puppeteer, which downloads a headless Chromium (mermaid rendering needs a browser engine — there is no lighter way).
• A terminal that speaks the kitty graphics protocol: Ghostty or kitty are detected automatically. Other terminals degrade to plain cat with a hint on stderr. WezTerm can work if you've set enable_kitty_graphics = true — run with --force (it's not auto-detected because that support is off by default).

Roadmap

Candidate features, in the same spirit — verbatim output except where the terminal can do better:

• LaTeX/KaTeX blocks as rendered images
• Linked/embedded raster images inline
• Opt-in prose styling (headers, emphasis) that stays pipe-safe

Alternatives

• glow / mdcat — beautiful markdown, but mermaid fences stay source code.
• presenterm — renders mermaid inline, but it's a slide presenter and wants slide-structured input.
• mmdc + an image viewer — works, but per-invocation browser launches and no document flow.

Development

npm test                    # unit suite (fast, no browser)
npm run test:integration    # real renders through headless Chromium
npm run typecheck
npm run build
node scripts/make-demo.mjs  # regenerate demo/demo.gif from demo/demo.md

MIT.
