@widgetkit/scheduler-react

A fast, accessible timeline scheduler component for React. Supports drag-and-drop, resize, multi-row layouts, zoom, and full keyboard navigation — with zero dependencies beyond React itself.

Documentation & live demo →

Installation

npm install @widgetkit/scheduler-react
# or
pnpm add @widgetkit/scheduler-react
# or
yarn add @widgetkit/scheduler-react

Usage

Import the component and its stylesheet, then pass resources and items:

import { TimelineScheduler } from "@widgetkit/scheduler-react";
import "@widgetkit/scheduler-react/styles.css";

const resources = [
  { id: "alice", name: "Alice" },
  { id: "bob", name: "Bob" },
];

const items = [
  {
    id: "1",
    resourceId: "alice",
    name: "Team meeting",
    color: "#6366f1",
    start: new Date("2024-06-10T09:00"),
    end: new Date("2024-06-10T10:30"),
  },
];

export default function App() {
  const [date, setDate] = useState(new Date());
  const [currentItems, setItems] = useState(items);

  return (
    <TimelineScheduler
      resources={resources}
      items={currentItems}
      date={date}
      draggable
      resizable
      creatable
      onItemsChange={setItems}
      onDateChange={setDate}
    />
  );
}

Custom item renderer

<TimelineScheduler
  resources={resources}
  items={items}
  date={date}
  renderItem={(item) => <span style={{ fontWeight: "bold" }}>{item.name}</span>}
/>

Props

Data

| Prop | Type | Required | Description | | ----------- | ---------------- | -------- | ------------------------------------------- | | resources | Resource[] | Yes | Rows in the scheduler. See types. | | items | TimelineItem[] | Yes | Events to display. See types. | | date | Date | Yes | The day currently shown. |

Time range

| Prop | Type | Default | Description | | ------------- | -------- | ------- | ------------------------------------- | | startHour | number | 0 | First visible hour (0–23). | | endHour | number | 24 | Last visible hour (1–24). | | snapMinutes | number | 15 | Snap interval when dragging/creating. |

Interaction

| Prop | Type | Default | Description | | -------------------- | --------- | ------- | ---------------------------------------------------------------------- | | draggable | boolean | true | Allow items to be dragged to a new time or resource. | | resizable | boolean | false | Allow items to be resized by dragging their edges. | | creatable | boolean | false | Allow new items to be created by clicking and holding on an empty row. | | editable | boolean | true | Show an edit modal on double-click. | | readonly | boolean | false | Disable all interactions (drag, resize, create, edit, keyboard). Tooltips and hover events still work. | | minDurationMinutes | number | 0 | Minimum item duration in minutes. 0 means no limit. | | maxDurationMinutes | number | 0 | Maximum item duration in minutes. 0 means no limit. |

Display

| Prop | Type | Default | Description | | ------------------ | ------------- | ------- | ----------------------------------------------------------- | | zoom | 1 \| 2 \| 4 | 1 | Horizontal zoom level. 2 = double width, 4 = quadruple. | | showNav | boolean | false | Show previous/next day buttons. | | showDateNav | boolean | true | Show the date header with navigation. | | showZoomControls | boolean | true | Show zoom in/out buttons. | | showTime | boolean | true | Show start and end time on each item. | | showAvatar | boolean | true | Show resource avatar in the row header. | | showEventCount | boolean | true | Show the number of events per resource. | | showTooltip | boolean | true | Show a tooltip with item details on hover. | | showNowLine | boolean | true | Show a line indicating the current time. |

Custom renderer

| Prop | Type | Description | | ------------ | ----------------------------------- | -------------------------------------------------------- | | renderItem | (item: TimelineItem) => ReactNode | Replace the default item content with a custom renderer. |

Events

| Prop | Signature | Description | | ------------------- | ----------------------------------------- | ------------------------------------------------------------------------------ | | onItemsChange | (items: TimelineItem[]) => void | Fired after a drag or resize completes. Receives the full updated items array. | | onDateChange | (date: Date) => void | Fired when the user navigates to a different day. | | onZoomChange | (zoom: 1 \| 2 \| 4) => void | Fired when the zoom level changes. | | onItemCreate | (detail: ItemCreateDetail) => void | Fired when a new item is created via click-and-hold. | | onItemClick | (detail: ItemClickDetail) => void | Fired on single click. | | onItemDblClick | (detail: ItemDblClickDetail) => void | Fired on double-click. | | onItemHover | (detail: ItemHoverDetail) => void | Fired on pointer enter/leave. | | onItemContextMenu | (detail: ItemContextMenuDetail) => void | Fired on right-click. | | onItemDragStart | (detail: ItemDragStartDetail) => void | Fired when a drag begins. | | onItemDragEnd | (detail: ItemDragEndDetail) => void | Fired when a drag ends. | | onItemResizeStart | (detail: ItemResizeStartDetail) => void | Fired when a resize begins. | | onItemResizeEnd | (detail: ItemResizeEndDetail) => void | Fired when a resize ends. |

Types

interface Resource {
  id: string;
  name: string;
  avatar?: string; // URL to an image shown in the row header
}

interface TimelineItem {
  id: string;
  resourceId: string; // Must match a Resource id
  name: string;
  color: string; // CSS color string
  start: Date;
  end: Date;
  description?: string;
}
