generative-mui

Let the LLM build the UI — not you.

Write a sentence — get real, working Material UI, in your own theme.

A renderer that maps Google's A2UI (v0.9.1) protocol onto Material UI. The agent emits A2UI — not a nested DOM, but a flat list of components referenced by id plus a separate data model bound by JSON-Pointer. The library turns it into real components inside your app's existing MUI theme.

None of the interfaces above were hand-written — the model was prompted, emitted A2UI, and the library rendered it as MUI.

⭐ If the idea grabs you, drop the repo a star — it's the biggest boost for a project that takes generative UI seriously.

At a glance

Chatbots return text; but a chart, a table, or a validated form often says more than a sentence. Until now the options were weak: either hand-write a component for every scenario, or trust the model's raw HTML and accept XSS and theme drift.

generative-mui opens a third path. The model emits data, not code: A2UI, a flat, schema-validated, id-referenced UI description. The library takes that description and turns it into real MUI components inside the host's <ThemeProvider>. No unregistered type is ever rendered; sx/style/className from the agent never reach MUI.

Describe → the LLM emits A2UI → deterministic store → real Material UI.

What does A2UI look like? (a concrete example)

The model emits server→client messages streamed as JSON Lines. Here's a small, two-way-bound, validated form:

{"createSurface":{"surfaceId":"s1"}}
{"updateComponents":{"surfaceId":"s1","components":[
  {"id":"root","component":"Column","children":["title","name","submit"]},
  {"id":"title","component":"Text","text":"Reservation","variant":"h4"},
  {"id":"name","component":"TextField","label":"Full name","value":{"path":"/name"}},
  {"id":"submitLabel","component":"Text","text":"Confirm"},
  {"id":"submit","component":"Button","child":"submitLabel",
    "action":{"event":{"name":"confirm"}},
    "checks":[{"condition":{"call":"required","args":{"value":{"path":"/name"}}},
               "message":"Name is required"}]}
]}}
{"updateDataModel":{"surfaceId":"s1","path":"/name","value":""}}

Things to notice:

• Adjacency list, not a tree. root references its children by id. To update one component you don't resend the whole tree — you just put that id back through updateComponents (merge-by-id).
• UI and data are separate. TextField.value isn't a literal, it's a {"path":"/name"} binding. As the user types, the store's data model updates; the required inside Button.checks reads that path and disables the button while it's empty.
• No colors/CSS. The model only states semantics (variant:"h4"); pixels and palette come from the host theme.

How it works — the internals

The pipeline runs through four pure layers; the first three know nothing about React/MUI:

JSONL ─parse─▶ messages ─reduce─▶ SurfaceStore ─resolve─▶ React/MUI tree
             (Zod safeParse)     (deterministic)         (registry + skeleton)

1 · Message protocol — 4 types. createSurface · updateComponents (add/replace by id) · updateDataModel (set/delete a JSON-Pointer path) · deleteSurface. Components are stored loosely ({id, component, ...passthrough}); full per-prop validation happens lazily at render — so a truncated stream or an unknown custom component degrades to a fallback instead of rejecting the whole batch.

2 · Deterministic reducer. The core reduce(state, message) → state is a pure function: it never mutates its input and silently ignores invalid/unknown messages (streaming tolerance). The same message sequence always yields the same state — testable, and it runs on SSR/edge.

3 · SurfaceStore — live, subscribable. Holds immutable state and is built for React's useSyncExternalStore: getState() returns a stable reference until the next change (no needless renders). Key methods:

• apply(msg | msg[] | jsonl) — feed the stream; skips invalid lines.
• writeLocal(surfaceId, pointer, value) — updates the data model without a server round-trip when an input changes; this is the engine of two-way binding.
• compact(surfaceId) — garbage-collects components unreachable from root via BFS (merge-by-id never deletes, so ids accumulate). It's a no-op while the root hasn't arrived yet, so it can't drop not-yet-attached components.

4 · Value resolution. Every catalog prop is one of three things: a literal, a {path} binding, or a FunctionCall. resolveValue collapses all three against the data model in one place; a FunctionCall has its args resolved recursively then runs against local functions (required, regex). The same mechanism powers both dynamic props and Button checks: a check whose condition is falsy disables the button and surfaces the first error message as helper text.

Streaming, resilience, and security

Agent output is untrusted and may arrive half-formed — the library is built for exactly that:

• 🌊 Incremental render. Components arrive piece by piece; not-yet-received children show a Skeleton. For string sources there's append-only delta detection: a growing stream never clobbers the user's local edits.
• 🧱 Graph resilience. An empty or root-less surface renders nothing; a cycle or a chain past MAX_RENDER_DEPTH degrades to a quiet placeholder instead of overflowing the stack; a per-node error boundary means one throwing renderer never unmounts the whole surface.
• 🔒 ReDoS guard. regex is local and both the pattern and the input have length caps (1000 / 10,000), because both the pattern and the tested text come from the untrusted agent and JS has no synchronous regex timeout — the cap shrinks the ReDoS blast radius without a Worker. Over-long inputs count as a non-match.
• 🛡️ Safe by construction. A type not in the registry never runs arbitrary code — it falls back safely; fields like sx/style/className never reach MUI even if the agent emits them.

Architecture & boundaries

Two packages, a one-way dependency — and that's not a convention, it's a compile-time rule:

| Package | Role | | ------- | ---- | | @yessglory/generative-mui-core | Framework-neutral A2UI v0.9.1: Zod schemas, JSONL parser, JSON-Pointer (get/set/remove), the deterministic SurfaceStore, value resolution, and the agent tool schema. Imports no React/MUI. | | @yessglory/generative-mui-react | The MUI adapter: A2UI Basic Catalog → Material UI, in a single public component: <A2uiSurface>. |

• The direction core ← react is one-way and enforced by eslint-plugin-boundaries — core leaking into React/MUI is a lint error. This lets the parser, store, resolution, and tool schema run everywhere (server, edge, RSC, tests).
• Zod schemas are the single source of truth. The Basic Catalog is a discriminated union on the component field; a drift test keeps these schemas locked to the vendored catalog.json (every component has a member, and no member names one the catalog doesn't define).

Making an agent speak A2UI

core ships provider-agnostic (just data + schema) agent glue:

import { a2uiTools, a2uiExtendedTools, extractJson } from '@yessglory/generative-mui-core'

// An AI-SDK-shaped tool whose parameters ARE the A2UI adjacency list (a Zod schema).
// The model produces a render-ready surface in one shot.
const tools = a2uiExtendedTools()               // Basic + charts/table/display/input
// const { jsonSchema } = a2uiToolDefinition({ catalog: 'extended' })  // raw jsonSchema7

// If the model replied in plain prose, pull the JSON out (tolerates ``` fences / prose):
const surface = extractJson(modelReplyText)

Also, describeCatalog() / A2UI_SHAPE_RULES / A2UI_BEHAVIOR_RULES give you a prompt block derived from the schemas — to embed the catalog into your system message.

Install & use

pnpm add @yessglory/generative-mui-react
# core comes with react

import { A2uiSurface, SurfaceStore, extendedRegistry } from '@yessglory/generative-mui-react'

const store = new SurfaceStore()
store.apply(a2uiJsonlFromYourAgent)   // JSONL / message array / single message

function Chat() {
  return (
    <A2uiSurface
      source={store}                    // live store → streaming + two-way binding
      registry={extendedRegistry}       // enable charts too (optional; @mui/x-charts)
      onAction={(a) => sendToAgent(a)}  // action.event goes back to the agent
    />
  )
}

• Two-way binding: inputs bound to {"path":"/field"} read/write the data model.
• Actions: action.event → onAction({ surfaceId, name, context }); action.functionCall (e.g. openUrl) runs locally.
• Host-overridable: registry={{ MyType: MyRenderer }} extends or replaces any mapping.
• Theme: it has no theme of its own; it inherits the host palette/typography — switch the theme and the UI re-skins top to bottom.

Catalog → MUI

All 18 Basic-Catalog components map one-to-one:

| A2UI | MUI | A2UI | MUI | | ---- | --- | ---- | --- | | Text | Typography | Button | Button (+ checks→disabled) | | Image | Box img | TextField | TextField | | Row/Column | Stack | CheckBox | Checkbox | | List | List | ChoicePicker | RadioGroup / checkbox group | | Card | Card | Slider | Slider | | Tabs | Tabs | DateTimeInput | TextField[type=date] | | Divider | Divider | Modal | Dialog |

Extended Catalog (opt-in, extendedRegistry): LineChart · BarChart · PieChart · ScatterChart · SparkLineChart · Gauge · Table · Alert · Chip · Badge · Accordion · Progress · Stepper · Switch · Rating · Autocomplete. The schemas live in the React-free core (so validation works everywhere); only the renderers are opt-in, so the @mui/x-charts dependency stays optional. Use a2uiExtendedTools() to have the agent emit these too.

Add your own component

Overriding an existing type just needs registry. For a genuinely new type, registerComponent gives you schema + renderer in one call — without editing the core:

import { A2uiSurface, registerComponent, useResolved } from '@yessglory/generative-mui-react'
import { z } from 'zod'

// A brand-new "StarBar" type that shows a score with ★
const StarBar = registerComponent(
  'StarBar',
  { value: z.union([z.number(), z.object({ path: z.string() })]), max: z.number().optional() },
  ({ node }) => {
    const value = Number(useResolved(node.value)) || 0     // literal or {path} binding
    return <span>{'★'.repeat(value).padEnd(node.max ?? 5, '☆')}</span>
  },
)

<A2uiSurface source={store} components={[StarBar]} />

The schema is enforced before the renderer runs, so a custom type is as safe as a built-in one (invalid props → skeleton, never a throw). For more — overriding renderers, adding permanently to the core catalog, and advertising the type to the agent's tool schema → docs/ (overriding renderers · new types).

Examples

The same generative-UI chatbot, in two frameworks:

| Example | Stack | Gemini call | | ------- | ----- | ----------- | | examples/gemini-chat | Vite + React SPA | in the browser (demo) | | examples/gemini-chat-next | Next.js App Router | in a server Route Handler (the key never ships to the client) |

pnpm --filter @yessglory/example-gemini-chat dev        # Vite
pnpm --filter @yessglory/example-gemini-chat-next dev   # Next.js

Both run out of the box in demo mode, no API key needed.

Development

pnpm install
pnpm test        # vitest (all packages)
pnpm typecheck   # tsc --noEmit per package
pnpm build       # tsup per package
pnpm lint        # eslint + boundaries

Test surface — core: JSON-Pointer round-trip (property-tested), SurfaceStore determinism + incremental/JSONL replay, drift against catalog.json, and the agent tool schema. react: render, two-way binding, required-check disabling, action dispatch, streaming skeletons, and zero axe violations.

Like it?

generative-mui takes seriously that LLMs shouldn't just talk — they should build validated, safe, themed UI. If you like the idea ⭐ star it, watch it, try it — your feedback steers where it goes.

built by yessGlory17
