🧠 Avatoon

Avatoon is a lightweight React Three Fiber component for rendering animated 3D avatars with real-time viseme-driven lip-sync. It supports lifelike head movements, morph target control, and optional goal-based gestures (e.g., flexing, sleeping), making it ideal for voice assistants, interactive characters, or storytelling apps.

⚛️ Works on both React (web) and React Native (Expo). The same <Avatoon> API runs in the browser (DOM <canvas> + HTMLAudioElement) and on mobile via @react-three/fiber/native + expo-av — selected automatically, so you import { Avatoon } from 'avatoon' on both. See React Native (Expo).

🎮 Try the live demo →

demo video

✨ Features

• 🎤 Real-time lip-sync using phoneme-viseme mapping
• 🧍 Subtle head motion animation while talking
• 👁️ Automatic eye-blinking (when the model exposes blink morph targets)
• 🎛️ Imperative play() / stop() control via a ref
• 🌐 GLTF model support via useGLTF
• ⚛️ Plug-and-play with React Three Fiber + Drei
• 📱 Cross-platform: one API for React (web) and React Native (Expo)
• 🎯 Goal-based gestures like "Muscle" or "Sleep"

📦 Installation

npm install avatoon

Requirements (peer dependencies)

Avatoon builds on React and the React Three Fiber ecosystem. Install these alongside it if your project doesn't already have them:

npm install react react-dom three @react-three/fiber @react-three/drei

| Peer dependency | Supported version | | --------------------- | ----------------- | | react / react-dom | >=18 | | three | >=0.153.0 | | @react-three/fiber | >=8.0.0 | | @react-three/drei | >=9.0.0 |

Runs in any browser with WebGL support. Written in TypeScript — type definitions ship with the package.

🚀 Usage

Avatoon — full avatar with audio-synced lip-sync

import { Avatoon } from "avatoon";

const visemeJson = {
  visemes: [
    { time: 0, viseme: "X" },
    { time: 1.3, viseme: "A" },
    { time: 1.367, viseme: "C" },
  ],
  audio_base64: "", // base64-encoded WAV (optional)
};

export default function App() {
  return (
    <div style={{ width: "100%", height: 400 }}>
      <Avatoon
        glbUrl="https://raw.githubusercontent.com/khaledalam/avatoon/main/test/assets/placeholder-avatar.glb"
        goal="Normal"
        visemeJson={visemeJson}
        showPlayVoiceButton
        onRenderComplete={() => console.log("Render Completed!")}
      />
    </div>
  );
}

LipSyncAvatoon — standalone lip-sync (no audio required)

A self-contained component with a built-in Start/Stop button that animates procedural mouth movement. Great for quick demos or "talking head" idle states.

import { LipSyncAvatoon } from "avatoon";

export default function App() {
  return (
    <div style={{ width: "100%", height: 400 }}>
      <LipSyncAvatoon glbUrl="/avatar.glb" />
    </div>
  );
}

Imperative control (ref)

Drive playback from your own UI instead of the built-in button by passing a ref — it exposes play(), stop(), and toggle():

import { useRef } from "react";
import { Avatoon, type AvatoonHandle } from "avatoon";

function App() {
  const avatar = useRef<AvatoonHandle>(null);

  return (
    <>
      <button onClick={() => avatar.current?.play()}>Speak</button>
      <button onClick={() => avatar.current?.stop()}>Stop</button>
      <div style={{ width: "100%", height: 400 }}>
        <Avatoon ref={avatar} glbUrl="/avatar.glb" visemeJson={visemeJson} />
      </div>
    </>
  );
}

To run the example app locally:

npm run example

📱 React Native (Expo)

Avatoon runs on React Native too. The same <Avatoon> component renders through @react-three/fiber/native (via expo-gl) and plays audio through expo-av — selected automatically by the package's react-native export condition, so you import from 'avatoon' exactly as on web.

npx expo install expo-gl expo-av expo-asset expo-file-system \
  @react-three/fiber @react-three/drei three
npm install avatoon

import { useRef } from 'react';
import { View, Pressable, Text } from 'react-native';
import { Avatoon, type AvatoonHandle } from 'avatoon';

export default function App() {
  const avatar = useRef<AvatoonHandle>(null);
  return (
    <View style={{ flex: 1 }}>
      <Avatoon ref={avatar} glbUrl="https://.../model.glb" visemeJson={visemeJson} />
      <Pressable onPress={() => avatar.current?.toggle()}>
        <Text>Talk</Text>
      </Pressable>
    </View>
  );
}

Platform differences

| | Web | React Native | |---|---|---| | Renderer | @react-three/fiber (DOM <canvas>) | @react-three/fiber/native (expo-gl) | | Audio | HTMLAudioElement | expo-av (base64 WAV written to a temp file) | | Play control | showPlayVoiceButton or ref | ref only (the built-in button is DOM) |

A full runnable example lives in examples/native. Note: HDR environmentPreset lighting is more limited under @react-three/drei/native, and R3F's native entry is most battle-tested on the v8 line (React 18 / Expo 51).

🧩 API

Avatoon(props)

| Prop | Type | Default | Description | | --------------------- | ------------ | ------------ | ------------------------------------------------------ | | glbUrl | string | (required) | URL to the .glb avatar file (T1 or T2) | | goal | AvatoonGoal| "Normal" | Motion preset: "Normal", "Muscle", or "Sleep" | | onRenderComplete | () => void | undefined | Callback fired when avatar finishes rendering | | onError | (error: Error) => void | undefined | Fired if the model fails to load (bad glbUrl) instead of crashing | | visemeJson | VisemeData | undefined | JSON structure for syncing visemes with audio playback | | showPlayVoiceButton | boolean | false | If true, renders a play/stop voice button in the scene | | fov | number | 24 | Camera vertical field-of-view | | cameraPosition | [number, number, number] | [0, 1.45, 2.3] | Camera position [x, y, z] | | cameraTarget | [number, number, number] | [0, 1.35, 0] | OrbitControls look-at target [x, y, z] | | environmentPreset | EnvironmentPreset | "sunset" | drei lighting preset (city, dawn, night, …) | | environmentFiles | string \| string[] | undefined | Custom HDR/EXR file(s); overrides the preset | | environmentBackground | boolean | false | Render the environment as the scene background |

Tune fov / cameraPosition / cameraTarget to frame your own avatar model. You can also drive playback imperatively via a ref.

LipSyncAvatoon(props)

A lightweight, self-contained variant that drives procedural mouth movement (no visemeJson or audio needed) and renders its own Start/Stop button.

| Prop | Type | Default | Description | | ---------------- | -------- | -------------- | ------------------------------------ | | glbUrl | string | "/avatar.glb" | URL to the .glb avatar file (T2) | | fov | number | 24 | Camera vertical field-of-view | | cameraPosition | [number, number, number] | [0, 1.45, 2.3] | Camera position [x, y, z] | | cameraTarget | [number, number, number] | [0, 1.35, 0] | OrbitControls look-at target | | onError | (error: Error) => void | undefined | Fired if the model fails to load | | environmentPreset / environmentFiles / environmentBackground | — | — | Same environment options as Avatoon |

Exposed building blocks

For advanced composition you can also import the lower-level pieces: AvatoonModel, CameraFovAnimator, SceneEnvironment, and AvatoonErrorBoundary.

👤 Avatar Types

• T1 (Static Face - Realistic)
  • Most photorealistic
  • No facial morphing
  • Lightweight
• T2 (Blendshape Face - Expressive)
  • Separate eyeballs and mouth
  • Supports morph targets / ARKit visemes
  • Slightly less realistic but animatable

📘 Types

interface VisemeData {
  visemes: Array<{ time: number; viseme: string | null }>;
  audio_base64?: string;
}

🎚️ Generating viseme data

visemeJson is what drives the mouth animation. Each entry pairs a time (in seconds, from the start of the audio) with a single-letter viseme code. Codes are mapped onto the model's morph targets; unknown or silent codes simply rest the mouth.

| Code | Mouth shape / example sound | | ---------- | ----------------------------- | | A | open — "a" as in apple | | B | lips together — p, b, m | | C | ch, sh, j | | D | d, t, th | | E | "eh", "ae" | | F | f, v | | G | g, k | | I | "ee" | | J | r, l, y | | K | "oo", "u" | | H / X | silence / rest |

The standard Oculus / Ready Player Me viseme names are also accepted as codes directly — sil, PP, FF, TH, DD, kk, CH, SS, nn, RR, aa, E, I, O, U — which is what the converter helpers below emit.

Entries must be ordered by ascending time. Optionally provide the spoken audio as a base64-encoded WAV via audio_base64 to play it in sync (used when showPlayVoiceButton is enabled).

{
  "visemes": [
    { "time": 0.00, "viseme": "X" },
    { "time": 0.12, "viseme": "B" },
    { "time": 0.20, "viseme": "A" },
    { "time": 0.35, "viseme": "I" }
  ],
  "audio_base64": "UklGR... (optional WAV)"
}

From a speech engine

Rather than hand-authoring the timeline, generate it from a TTS/lip-sync engine. Avatoon ships converters for the most common sources:

import {
  Avatoon,
  fromAzureVisemes,   // Azure Speech SDK viseme events
  fromPollySpeechMarks, // AWS Polly speech marks
  fromRhubarb,        // Rhubarb Lip Sync JSON
} from "avatoon";

// Azure: collect events from the Speech SDK's `visemeReceived` callback
const visemeJson = fromAzureVisemes(azureEvents); // [{ visemeId, audioOffset }]

// AWS Polly: pass the `viseme` speech marks
const visemeJson = fromPollySpeechMarks(pollyMarks); // [{ time, value, type }]

// Rhubarb: pass its JSON output (or just the mouthCues array)
const visemeJson = fromRhubarb(rhubarbOutput); // { mouthCues: [{ start, end, value }] }

Each returns a VisemeData object ready to hand to <Avatoon visemeJson={...} />. Times are normalized to seconds. Add audio_base64 yourself if you want synced playback.

Model requirement (T2): audio-synced lip-sync needs a .glb whose mesh exposes viseme_* morph targets (ARKit / Oculus / Ready Player Me naming — e.g. viseme_aa, viseme_PP, viseme_CH). T1 models have no morph targets, so use LipSyncAvatoon or head-motion only.

🤝 Contribution

Pull requests are welcome! See CONTRIBUTING.md for local setup and development workflow, and please review our Code of Conduct. To report a security issue, see SECURITY.md.

💖 Support

If Avatoon is useful to you, consider supporting its development — it helps a lot and keeps the project maintained:

• ⭐ Star the repo — the easiest way to help
• 💛 Sponsor on GitHub
• ☕ Buy Me a Coffee
• 💵 PayPal

📄 License

MIT © Khaled Alam
