breaklint

breaklint is a command-line layout check for people who generate PDFs from HTML: it reports widows, orphans, blocks too tall to keep together and hyphenation across page breaks, each with the measured value and the threshold it failed.

The image links to the project page, which carries the 39-second film about breaklint.

npx breaklint --demo

That command needs no browser and no configuration. It ends with exit 1, because the demo fixture contains findings on purpose — a demo that ends 0 never shows you what a finding looks like. Below is one of its five findings, plus the closing counters, copied from that command's output:

error svg/text-overflows-viewport  page 5
  measured   72 px; threshold 0 px (uncalibrated)
  detail     This text extends 72.00 px beyond the SVG viewport and is not drawn. Coordinates are normalised through getScreenCTM().
  remedy     Text rendered inside an SVG extends outside the SVG viewport bounds and is clipped. Enlarge the SVG 'viewBox' or its width/height, or adjust the <text> coordinates ('x', 'y', 'text-anchor'). 'overflow: visible' on the container also clears the finding, but it does not move the text: the viewport then no longer clips, the target becomes non-applicable and this rule stops measuring it. Use that only where the overflow is intended.
             untested: no trigger/remedied pair in this package shows this advice removing this finding
  source     unknown (node produced by the paginator)
  render     unknown (no evidence produced)

inputs found: 1 · pages analysed: 5 · rules run: 12 · rules that measured something: 10 · not measured: 1 · verdict: findings · mode: demo · fail-on: error · gate triggered by: error

Two figure and two table checks are opt-in warnings. Figures require a source-bound body and caption inventory; supported bodies include a single image, inline SVG or source-matched table, measured separately from the wrapper. Table captions use their authored before/after order and the first/last actual cell-box body page, including bodies spanning pages. Local figure/table links resolve authored IDs and legacy <a name> targets, with IDs taking precedence. Table continuations require exact source row/cell membership and concrete cell boxes. Unsupported structures and ambiguous references remain explicit declines. Free-text numbering, printed page references and pagination cause are outside these checks. The hand-written demo has no original HTML to inventory: default --demo still exits 1; --profile strict --demo now exits 4 because those requested figure checks cannot establish their source measurements.

Every finding carries what was measured, what the threshold was, and the word uncalibrated — because no threshold in this project has been calibrated against real documents, and a number that hides that is worse than no number.

One thing about that output, since the demo invites the assumption: the rule and reporter chain running there is the real one, but the page it judges is a hand-written snapshot, built so to demonstrate findings from the existing checks in a command that needs no browser. No HTML document stands behind it: the snapshot names examples/demo.html as its document path, but that file does not exist and never did, which is why the demo's findings carry no source location. The run says which kind of fixture it used in its own source field rather than leaving you to guess. Point the tool at your own HTML and the same chain measures a real page.

Install

This documentation describes version 0.10.0. The npm command below installs the registry's current latest; check the installed version with npx breaklint --version. Publication and verification records are in status, and the release procedure is in releasing. The bounded human example evaluation records what the selected real examples establish and what remains unknown.

npm i -D breaklint

That is enough for --demo and for reading the docs. A run over your own HTML additionally needs a browser and the paginator; see Requirements.

Source-bound findings and existing web pages

The installed package now exposes checkProducedDocuments, checkPage, compareReports, createContextPack, renderReport and writeReportBundle. Live document reports use Report 5, and the report readers accept Report 4 and 5; the screen profile has a separate contract and checks visible geometry without pagination.

import { checkPage, writeReportBundle } from 'breaklint';

// `page` is your existing, authenticated Playwright page after scenario setup.
const { report } = await checkPage(page, {
  trust: 'host-controlled-page',
  networkPolicy: 'host-owned',
  scenario: 'account-overview',
  output: { dir: './layout-evidence', screenshot: 'viewport' },
});
await writeReportBundle(report, {
  outDir: './layout-report', evidenceDir: './layout-evidence',
});

The adapter keeps navigation, authentication and page ownership with the caller. It records unsupported paint and missing coverage explicitly. Source selectors alone do not prove a component position. A host build receipt can verify a component container; producer-bound documents can carry exact original byte ranges. Both the offline human view and bounded AI context derive from the same canonical JSON. See the source and consumer contract, reporting and repair comparison. An agent reading a report should start at the agent contract: which fields are stable, what each exit code obliges it to do, and which advice this package has not verified.

Why this exists

Prose linters never see a page. Typesetting systems see the page but do not know German typographic convention. For documents generated from HTML to PDF, neither exists.

The reason for measuring the rendered page rather than the source is a case that source-level checking did not catch: a chart passed an XML validity check and a geometry check, and still came out of the renderer with colliding labels. Whether a page works is decided after pagination — in the renderer, with the fonts that were actually available.

Prior art, and what it does well: veraPDF and pdfcpu check whether a PDF conforms to the standard. BackstopJS and pdf-visual-diff compare a build against a previous one. typopo corrects German punctuation in plain text, and does it well. fmitex-widows-and-orphans checks widows and orphans in LaTeX, and TeX has reported Overfull \hbox for decades. All of these are useful. None of them judges the layout of an HTML→PDF page on the first build, where there is no previous version to compare to.

What is checked

Seventeen rules are registered in 0.10.0. Twelve run by default: two can fail a build; ten more are advisory unless you request --fail-on warn. Five are off by default: the two figure checks, the two table continuation checks and experimental layout/half-empty-page. Strict mode enables all seventeen. Half-empty-page never gates, even with --fail-on warn. It now checks remaining space against twice a recorded line height, accepts low coverage at a natural document ending, and declines low coverage at an observed forced ending when there is no late start. A late start can still warn. These guards do not establish author intent or the cause of an avoidable gap. Net fill remains glyph/visual-band coverage rather than line-box occupancy.

That split is not caution, it is the burden of proof: only two rules compare directly measured quantities against a structural boundary.

| rule | what it measures | default | |---|---|---| | layout/widow | lines in the opening fragment against the element's own widows | warn | | layout/orphan | lines in the closing fragment against its own orphans | warn | | layout/unbreakable-block-too-tall | height of a break-inside: avoid block against the page | error | | layout/heading-at-page-bottom | space under a heading, in its own line heights | warn | | layout/half-empty-page | summed height of semantic bands over the content box | warn, experimental, off by default | | layout/orphaned-continuation-page | a page holding only the tail of an earlier block | warn | | layout/hyphen-across-page | the paginator's hyphenation class at a page boundary | warn | | svg/text-overflows-viewport | CTM-normalised text box against the viewport | error | | type/spaced-hyphen | a hyphen between spaces where a dash belongs | warn | | type/straight-quotes | typewriter quotes in typeset prose | warn | | type/short-last-line | width of a paragraph's closing line | warn | | type/excessive-word-spacing | word gaps against the natural space | warn | | artifact/local-uri | file: URIs and build-machine paths left in the artefact | warn | | figure/caption-separated | a measured image/SVG or source-matched table body separated from its caption | warn, off by default | | figure/dangling-reference | local figure/table links with missing authored IDs or legacy named anchors | warn, off by default | | layout/table-header-not-repeated | an existing header absent from a continuation with visible data | warn, off by default | | layout/table-column-drift | continuation cell edges against the first visible header's tracks | warn, off by default |

No threshold in this project is calibrated. calibrated: false appears in the type, in every finding and on every rule page. There is no corpus of real documents with human-checked truth behind any of these numbers, and saying so is more useful than a number that looks authoritative.

What it does not do

• PDF standard conformity — use veraPDF or pdfcpu.
• Comparison against a previous build — use BackstopJS or pdf-visual-diff. This tool judges the first build, where there is nothing to compare to.
• Grammar, spelling and wording — use vale. The four type/ rules here judge typographic characters and measured line geometry on the rendered page, not the prose.
• Accessibility auditing — use pa11y.
• PDF as input. PDF is produced and rasterised here to make evidence, never read as input.

Limits

PNG output is evidence, never a comparison basis. Byte-identical rendering across machines is not achievable — browser rendering varies with the host OS, version, settings, hardware and headless mode. The report records an input identity so that reproducibility can eventually be stated over more than the HTML file alone, but that is an intention rather than a determinism guarantee today. L-07 remains open: system-font identifiers and the canonical treatment of dynamically loaded resources are not complete. No check compares output file hashes.

Findings depend on font availability. A missing @font-face changes metrics, line breaks and page breaks, and turns a correct page into a phantom half-empty-page finding. The run waits for document.fonts.ready and stops with a non-zero exit if a declared font resource fails, rather than reporting findings it cannot stand behind.

Missing image content is never treated as present. A failed image decode remains fatal unless the source supplies positive width and height attributes and Chrome measures a box exactly equal to both values. Only that fixed-layout case continues with the non-fatal image-content-unavailable diagnostic; replacement text, missing dimensions or authored CSS that changes the box is not accepted as stable geometry. Reports retain a resource index and dimensions, never the failed file URL or remote query string.

A successful live document retains a non-fatal geometry-cross-check-passed event with candidate, eligible, checked and required box counts, every semantic exclusion and the maximum delta against the 0.05 px tolerance. This is positive evidence from Chrome's CDP layout tree, not a second read from the in-page collector; a zero or truncated required sample is fatal.

SVG clipping and ink collision are not released rules. The research modules svg/text-clipped and svg/text-ink-collision need isolated, stable pixel passes that production acquisition does not yet collect. Version 0.3.1 therefore removes them from the CLI registry, configuration schema, SARIF catalogue and demo instead of counting two rules that answer nothing. Their real-renderer lab remains explicitly research-only. svg/text-overflows-viewport needs only geometry and measures ordinary solid-fill text. When getBBox() cannot prove painted bounds (for example <use>, stroke, clip/mask/filter or a paint server), or CSS on the SVG or an ancestor makes its axis-aligned border box differ from the clipping viewport, the target declines coverage-relevantly and the error rule fails closed with exit 4 rather than guessing.

Their validation foundation is real-renderer, not real-corpus. M3-0 exercises the ink rules' known construction and boundary cases in Chrome/Paged.js; it does not establish population performance or calibrate a threshold. It can validate the integrity and bindings of separately supplied capture-evidence bytes, but it does not ship an externally governed attestor trust root. No M3-0 path establishes a calibrated claim; that trust boundary belongs to later real-corpus work.

There is no released SVG pixel-collision or clip/mask-ink check. A prior implementation took its truth from the same API it was testing and was removed. The replacement lab uses independent pixel counterfactuals, but production integration still needs an isolated page, a device-scale contract, bounded target counts and rule-specific completeness checks before either rule can return.

Paged.js is pinned to exactly 0.4.3. The break cause is read from attributes the paginator writes into the tree and does not guarantee as an interface. Any other resolved version stops the run with exit 3, and no flag overrides that: a report produced on an unmeasured paginator states things nobody measured.

Windows is not supported. Process termination here rests on POSIX process groups. The termination and profile-cleanup path is measured on macOS; equivalent Linux behaviour has not yet been established empirically. Windows job objects are neither designed for nor measured.

The M2/M2d live render path is built. A live run loads the document through an owned loopback origin, paginates it, assembles and validates the snapshot, runs the rules, and binds evidence to the report. checker-crashed remains a real exit-3 path for injected driver failures, apparatus interference and process-boundary faults; it is not a placeholder for an unbuilt live path. M3-0's SVG validation and calibration foundation exists in the repository, but empirical threshold calibration and a representative human-labelled real corpus remain unfinished. The ten selected human-reviewed examples establish a narrower evaluation. Packaging and the first npm release are complete; the post-release trust work and remaining validation boundaries are tracked in docs/status.md.

Exit codes

| code | meaning | |---|---| | 0 | checked, coverage met, nothing reached the threshold | | 1 | at least one non-experimental finding reached the threshold | | 2 | invalid invocation: unknown option, bad config, no input, or an input path that does not exist, is not a regular file or is not .html/.htm; no report is written | | 3 | infrastructure: no renderer, font failed, pagination aborted, checker crashed, or the output could not be written completely (for example, the stdout reader closed early; with --out, a lost confirmation line keeps the verdict's code) | | 4 | nothing or too little was judged |

Exit code 4 exists because of a measured case. A multi-column document with the widow rule active produced 6 pages analysed, 1 rule run, 5 candidates, 0 measured, 0 findings — and exit 0. The single-column control produced 5 measured, coverage 1.0, and also exit 0. From outside the two runs were identical. Every report therefore carries inputsFound, pagesAnalysed, rulesRun, measuredRules and the sum of unmeasured candidates, in every output format.

Usage

breaklint docs/**/*.html                 # the shell does the globbing, not the tool
breaklint --format json --out report.json chapter-*.html
breaklint --fail-on warn manual.html     # gate on the heuristics too, deliberately
breaklint --profile strict manual.html   # warnings gate; every rule requires full coverage
breaklint --only layout/widow,layout/orphan book.html
breaklint --only layout/half-empty-page report.html   # experimental whitespace review
breaklint --only figure/caption-separated,figure/dangling-reference manual.html
breaklint --only layout/table-header-not-repeated,layout/table-column-drift --fail-on warn \
  --format json --out table-report.json manual.html
breaklint --disable layout/hyphen-across-page report.html
breaklint --out-dir build/evidence book.html   # where the page PNGs and the checked PDF go

A live run writes its evidence — one PNG per page and the PDF it checked — into ./breaklint-report in the working directory unless --out-dir <dir> names another; the report's evidence[].path entries are relative to that directory. --demo writes none.

A rule you disagree with can be switched off for the whole run — --disable <rule,...>, or {"rules": {"layout/hyphen-across-page": false}} in the config file; the same two switches turn an off-by-default rule on, with true. There is deliberately no way to silence a rule at ONE place in a document: an inline suppression comment would be a claim about a page that nothing checks, and this tool exists because such claims were wrong.

In GitHub Actions, the composite Action at the root of this repository (uses: godarg/breaklint@<ref>) runs the check as a gate: one run over the HTML paths or bash globs you give it, a step that fails on breaklint's own exit code (1 to 4 by default; only 1 may be left ungated), and SARIF for code scanning, JUnit and a Markdown step summary, all rendered from the one canonical JSON report. It installs the npm release named in that ref's package.json, not the ref's code: a tag works once its npm publish has succeeded, and a branch ref runs the last release, or fails with exit 3 after a version bump that is not yet published. Path expansion requires Bash 4 or newer with globstar; macOS /bin/bash 3.2 does not provide it. docs/ci-recipe.md has a workflow to copy, the permissions it needs and what each exit code does to the job.

There is no directory recursion and no glob expansion inside the tool. The shell has done this correctly for fifty years, including symlink cycles.

Input is HTML only (.html or .htm), and the name decides: a standalone .svg, PDF or Markdown file is rejected by its extension, and anything that is not a regular file — a directory called chapter.html included — is rejected too, each with exit 2 before Chrome starts. The content of a .html file is not sniffed. Inline SVG inside HTML is supported by the released SVG geometry rule; treating a standalone SVG asset as a paged HTML document would require a separate MIME, page-size and embedding contract that this version does not claim.

Configuration is fail-closed JSON in breaklint.config.json. Unknown fields, rules and options end with exit 2 before the input is opened. Values resolve as defaults < profile < config < CLI; the JSON report records the effective value, its origin and a deterministic configuration fingerprint. Coverage floors can be raised, never lowered, and the two structural error thresholds cannot be overridden. The complete contract, profiles, examples and generated schema are in docs/configuration.md. JavaScript configuration would mean executing code from a foreign repository inside CI, so it is intentionally unsupported.

Coverage totals count rule-candidate evaluations, not unique pages, elements or defects. The same table can be evaluated by both continuation checks. Applicable unmeasured evaluations are separated from not-applicable targets and unavailable tool capabilities outside the coverage denominator. Each finding remains separate unless evidence establishes a shared cause; a shared rule ID does not establish one. Repair advice is marked tested or untested.

The HTML reporter is a self-contained evidence view, not a second source of truth. Its header distinguishes clean, findings, checker failure and insufficient coverage in words; findings reflow without a horizontal table on mobile; print uses an A4 layout. What CI verifies about these surfaces is technical — test:report-surfaces:technical checks every current screen and print cell for decoded pixels, contrast, accessibility and fragmentation. A human review counts only as a passing round by a rostered reviewer in the review ledger, bound to the current inputs; see its latest round and docs/releasing.md.

For 0.10.0 the current record is round 8: four fresh Claude Opus reviews, actual model claude-opus-5-5, passed all 32 cells under the Founder's release-specific AI delegation of 2026-10-07. Native receipts bind 263 image reads: 24 full screens, 212 desktop/tablet/mobile tiles and 27 A4 page rasters. The four PDF cells were judged through all matching rasters. Round 7 remains recorded as FAIL: contradictory handwritten fixture counts and missing desktop tiles were corrected with actual red/green tests and independently measured physical inventory. This is delegated AI sight evidence. Four medium and 27 low findings have explicit accepted-risk or follow-up dispositions; unitless secondary stats, decline-base labels, finding-gate wording, synthetic evidence context, identifier wrapping and paper navigation remain presentation limits. Fine-text judgment rests on native viewport tiles and A4 rasters. The local sight review does not establish human or Ubuntu visual review. Independent Mac and Linux technical inventories agree on 212 tiles and 3/8/8/8 printed pages. JSON remains canonical. The information contract and the reproducible 32-cell screen/print review are documented in docs/reporting.md.

Requirements

Node 22.13 or newer, on macOS or Linux. The floor is exact because [email protected] requires Node 22.13 or Node 24, and the release gate installs the packed package on both Node 22.13 and 24. A live run additionally needs a Chromium-based browser, puppeteer-core at >=25.8.0 <26 (the declared peer range) and [email protected]. pdfjs-dist is what rasterises the produced PDF to bind evidence to findings; a run without it still measures and still reports, but the findings carry no evidence and the report says so rather than pretending otherwise. Poppler's pdftoppm is not used by the tool at all: the live test suite uses it as an independent rasteriser, so that Chrome is not both the producer and the sole judge of every PDF. It is never shipped and never called at check time.

npm i -D puppeteer-core@^25.8.0 [email protected] [email protected]

Running foreign HTML

This tool executes foreign HTML including its scripts. It uses a fresh browser profile per run, never asks for the sandbox to be off and has no flag that does, and by default lets no page request through except to its own loopback origin. That protects against mistakes and badly built documents. It is not an egress control and not protection against someone deliberately attacking the browser:

• The request policy does not cover WebSocket, WebTransport or WebRTC connections a document opens, nor the browser's own secure DNS and component updater traffic. Measured on 0.7.0 in the default offline mode: a document's WebSocket to another loopback port was delivered and a WebRTC STUN request was sent, and the run came back clean.
• breaklint refuses PUPPETEER_DANGEROUS_NO_SANDBOX and PUPPETEER_TEST_EXPERIMENTAL_CHROME_FEATURES before launch and strips CHROME_EXTRA_FLAGS from Chrome's child environment. Other browser or wrapper variables are not proven safe; isolate untrusted documents at the operating-system boundary.

For untrusted third-party HTML, use a container or network namespace with no egress. Details are in SECURITY.md.

How this was made

Parts of this repository were written with the help of large language models: the initial implementation of several rules, most of the test fixtures, and the first draft of this documentation. The rule definitions document their thresholds and sources; new checks may be implemented and reviewed with AI assistance. Every rule that cites the German orthography ruleset was checked against the published text of that ruleset, not against a model's summary of it.

breaklint itself uses no model at check time. It performs no inference and contains no API client — see package.json, whose only runtime dependency is a HTML parser, and the offline network default in src/config/resolve.ts.

This notice is voluntary.

Help test it

The useful report is the page where human judgement and the checker disagree. Anyone can run the public, unpaid community test; there is no application or selection. Use only material you may publish. Security findings still go through SECURITY.md, never a public issue. Community reports are additional QA, not blind annotations or calibration evidence, and all fifteen released rules remain calibrated: false.

License

MIT — free for commercial use.

Dependencies are restricted to permissive licences: MIT, ISC, BSD-2-Clause, BSD-3-Clause, Apache-2.0, 0BSD, Unlicense and CC0-1.0. The check walks the whole installed tree, so runtime and development dependencies are both covered, and a package with no licence field fails it. It runs in CI on every push to main and on every pull request.
