ExprForge 🔢🔨

Brief

ExprForge authors a math formula once, as a small AST, and emits verified, identical-behavior implementations in JavaScript, TypeScript, Python, C#, Lua, QB64, C, Java, Go, Rust, Perl, PHP, Julia, Fortran, Zig, Scheme (Guile), and COBOL (GnuCOBOL) — plus a native in-process evaluator and a printer for its own readable syntax. No required dependencies.

▶ Try it live — write a formula in the browser and watch it emitted across every target language at once, no install required. Runs the real, current library (see playground/), not a frozen demo build.

Motivation

This grew out of a real, recurring problem in a larger multi-language system (internally: SSS) that needed the same math to be true in several independently-deployed pieces written in different languages at once — not "translate this code," but "prove these N implementations of one formula actually agree," which is a narrower, checkable claim. Codegen tools like SymPy already turn expressions into code for mainstream languages; this exists for the two things that leaves open:

• Targets like QB64/BASIC or COBOL that no general codegen project reaches at all.
• A conformance harness that actually proves the emitted targets agree numerically, compiled and run for real — not just that they compile.

Two shapes of real use this tends to fall into:

• Keeping concurrent codebases in sync. A client/server split (game client prediction + authoritative server, or any two independently deployed services) where both sides need to compute the same formula and disagree — desync, or a cheat signal — the moment they drift. One AST, not two hand-maintained implementations that quietly diverge.
• De-risking a migration. Replacing an older implementation (a COBOL batch job, a Fortran numerical kernel) with a new one doesn't require trusting a manual port — emit the same formula into both the legacy target and the new one, and let the conformance suite prove they agree before cutover, not after.

Intents

What it does: turns one small, pure-arithmetic AST into identical-behavior source text for 16 real target languages, a native evaluator, and its own readable printer — all from the same tree, walked once per target.

What it deliberately won't do — not gaps waiting on a future release, but a boundary held on purpose everywhere in this project:

• No control flow. No loops, no branches, no generated function calling another generated function at runtime. This is an expression AST, not a program AST. loadMacro/loadExpr (see below) let one definition reference another, but only by inline expansion at build time, resolved in declaration order — never a real call, never recursion (which would need a stack this library doesn't have), never a call graph.
• No RNG. Can't be made to produce identical output across languages, so it isn't offered as if it could.
• No arbitrary precision / complex numbers. float64 only, for now.

What it is not: a general transpiler ("translate my code for me"). It's narrower and more checkable than that — "prove two independent implementations of one formula actually match."

Trust only the layer you need. Everything below is genuinely layered, and the layers don't reach back into each other:

• The AST and its emitters are the whole value proposition, and the entire dependency graph. ast.js's builders (num, v, add, mul, letIn, select, outputs, ...) build a plain tree of plain objects; every emitters/<lang>.js file turns that tree into target-language source text. Every emitter requires only emitters/base.js and ast.js — nothing else in this repo. No parser, no custom syntax, no interpreter sits between your AST and the code it emits. The library worked exactly this way for its first two published releases, before anything below existed.
• expr/fn/macros — optional authoring sugar, all the way up to the flashiest multi-function syntax below. Every layer of sugar turns into exactly the same tree the raw builders would — checked by structural unit tests and a full print-reparse-evaluate round trip across every sample this project has (see "Testing"), not just asserted. It's genuinely optional: nothing in the AST/emitter layer calls into or imports any of it. Don't want a parser in your dependency graph, for a security review or otherwise? Don't call expr/fn/loadMacro — build the tree with the plain functions instead, and every emitter behaves identically either way.
• The native evaluator and the expr-syntax printer are additive conveniences that sit off to the side the same way — nothing else depends on them either.

If you only care about "does this correctly turn my AST into COBOL/Java/whatever" — ast.js and the one emitters/<lang>.js file you care about are the entire surface that matters. The rest of this README walks in from the flashiest end first, then works back down toward that same bottom layer, one step of sugar removed at a time — skip straight to whichever depth you actually plan to trust.

Install

npm install exprforge

Examples, flashiest first

The showcase feature: several function definitions in one buffer, a later one referencing an earlier one by name, with dot-field access into a multi-output result — all inline-expanded at parse time, never a real runtime call (see "Intents" above for why that distinction is load-bearing, and "Macros and externs" below for the full mechanism). This is exactly what the live playground's editor buffer accepts:

const { loadExprSource, evaluate, emit } = require("exprforge");

const defs = loadExprSource(`
macro cross3(ax, ay, az, bx, by, bz):
  let rx = ay * bz - az * by;
  let ry = az * bx - ax * bz;
  let rz = ax * by - ay * bx;
  return { rx, ry, rz };

fn crossLength(ax, ay, az, bx, by, bz):
  let c = cross3(ax, ay, az, bx, by, bz);
  return sqrt(c.rx^2 + c.ry^2 + c.rz^2);
`);

evaluate(defs.crossLength, [1, 0, 0, 0, 1, 0]); // 1
emit(defs.crossLength, "rust").source;          // a real fn crossLength(...) -- no trace of cross3 left

Every definition starts with fn or macro — never optional, never implied. fn means "hand this back to me": defs.crossLength exists because it's marked fn. macro means "inline this into whatever references it later in this same buffer, but don't hand it back on its own": cross3 is fully usable inside crossLength — that's the whole point — but defs.cross3 doesn't exist; Object.keys(defs) here is just ["crossLength"]. There's no default either way, on purpose: a helper you only ever meant as an internal step for something else can't accidentally end up looking like part of your file's real, callable output just because nothing said otherwise. Mark it fn instead if you do want cross3 usable standalone too — both marks register the definition identically for inlining purposes; the only difference is whether it also lands in what this call returns.

cross3 never appears in crossLength's emitted output, in any target — by the time loadExprSource returns, defs.crossLength is self-contained arithmetic, cross3's formula copied in and simplified away. This is also why calling cross3 from inside itself isn't just discouraged, it's structurally impossible: a definition only becomes referenceable by whatever's declared after it, never by itself — covered in full under "Macros and externs" below, including exactly what happens if you try.

This is the top of the sugar. The rest of this README works back down from here, one layer at a time, showing the exact same formula — cross product magnitude — at each level of undress.

One layer down: fn + loadMacro, no file/buffer needed

Same result, without a multi-definition buffer: register cross3 once with loadMacro, then reference it from an ordinary fn template. loadExprSource above is sugar for exactly this loop, run once per definition in the buffer.

const { loadMacro, fn, evaluate } = require("exprforge");

loadMacro("cross3", fn`
    cross3(ax, ay, az, bx, by, bz):
    let rx = ay * bz - az * by;
    let ry = az * bx - ax * bz;
    let rz = ax * by - ay * bx;
    return { rx, ry, rz };
`);

const crossLength = fn`
    crossLength(ax, ay, az, bx, by, bz):
    let c = cross3(ax, ay, az, bx, by, bz);
    return sqrt(c.rx^2 + c.ry^2 + c.rz^2);
`;

evaluate(crossLength, [1, 0, 0, 0, 1, 0]); // 1

Another layer down: expr, hand-inlined, no macro at all

Drop the macro entirely and write the whole thing as one infix expression — cross3's formula copied in by hand, exactly what the macro layer above did for you automatically:

const { expr, evaluate } = require("exprforge");

const body = expr`sqrt((ay*bz - az*by)^2 + (az*bx - ax*bz)^2 + (ax*by - ay*bx)^2)`;
const crossLength = { name: "crossLength", params: ["ax", "ay", "az", "bx", "by", "bz"], body };

evaluate(crossLength, [1, 0, 0, 0, 1, 0]); // 1

The bottom: raw AST builders, no parser involved at all

The actual library API — no expr/fn/macros in the dependency graph whatsoever, just plain function calls building a plain tree of plain objects. Everything above compiles down to exactly this shape:

const { v, add, sub, mul, call, letChain, evaluate } = require("exprforge");

const rx = sub(mul(v("ay"), v("bz")), mul(v("az"), v("by")));
const ry = sub(mul(v("az"), v("bx")), mul(v("ax"), v("bz")));
const rz = sub(mul(v("ax"), v("by")), mul(v("ay"), v("bx")));

const crossLength = {
    name: "crossLength",
    params: ["ax", "ay", "az", "bx", "by", "bz"],
    body: letChain(
        [["rx", rx], ["ry", ry], ["rz", rz]],
        call("sqrt", add(mul(v("rx"), v("rx")), mul(v("ry"), v("ry")), mul(v("rz"), v("rz")))),
    ),
};

evaluate(crossLength, [1, 0, 0, 0, 1, 0]); // 1

If you're only willing to trust this layer — no parser, no macro expansion, nothing but ast.js and one emitters/<lang>.js file — this is the entire surface you need to read. Everything above it is sugar that provably lowers to this same shape (see "Testing"); nothing below it exists.

Usage

const { expr, emit, emitMany } = require("exprforge");

const fn = {
    name: "lerp",
    params: ["a", "b", "t"],
    body: expr`(b - a) * t + a`,
};

console.log(emit(fn, "rust").source);
console.log(emit(fn, "c").source);

// Need several targets at once? emitMany() runs each in isolation --
// one target's failure shows up as { source: null, error } for that
// target alone, not a thrown exception that blanks every other result.
const outputs = emitMany(fn, ["rust", "c", "python"]); // omit langs for every registered target
console.log(outputs.rust.source);

Samples

samples/ has worked, non-trivial examples (also exported from the package individually, or together as samples):

• samples/catmull-rom.js — uniform Catmull-Rom spline interpolation.
• samples/fibonacci.js — nth Fibonacci number via Binet's closed form. There's no loop/recursion version because exprforge has no control flow (see "Intents" above) — this is what "fibonacci" looks like as a pure expression.
• samples/spline-frame.js — Gram-Schmidt frame construction for spline paths (worldUp selection, tangent normalization with a safe-division fallback, roll). 4 suites exercising letIn/cmp/select/outputs on a real-world case — this is the actual motivating use case for those node types, not a toy. Used to be 19 separate functions, each independently re-deriving the same let-chain (including a sqrt) for one output; now each related group shares that work once per call.
• samples/kitchen-sink.js — not a worked example: a synthetic function that calls all 22 supported Math functions in one expression, existing purely as a conformance-test fixture. It's what caught Go's and Rust's sign() disagreeing with everyone else at exactly zero (see "Testing") — the other samples between them only ever exercised 5 of the 22.
• samples/math-demo.js — also not a worked example: a conformance-test fixture exercising every exprforge/math helper (see below) in one suite.
• samples/macro-demo.js — also not a worked example: a conformance-test fixture specifically for the loadMacro(name, fn`...`) AST-function tier, proving its internal gensym'd let-renaming produces valid identifiers on every real target, not just evaluate() (which can't see codegen at all — see "Macros and externs").

npm run build emits all of them, for every target language, into out/.

Supported Math functions

sqrt abs pow sin cos tan asin acos atan atan2 log log2 log10 exp floor ceil round trunc sign min max hypot

Add more by extending a target's calls table in emitters/<lang>.js. Requesting an unmapped function throws at build time, not silently. Each one takes exactly 1 argument (everything above pow) or 2 (pow onward) — calling one with the wrong count throws too, for every target including the expr printer: unlike an unmapped name (which expr prints through unchanged, having no fixed math library of its own to validate against), a wrong argument count is a structurally malformed call regardless of target, checked unconditionally at the same tier as checkUnboundVars — see primitives.js.

Math utilities (exprforge/math)

A separate, additive export — require("exprforge") is unchanged — of pre-built compositions of the core AST builders for common 3-D math patterns, so consumers stop re-implementing the same safe-math and vector code in every project (samples/spline-frame.js had local, hand-rolled versions of most of these before this module existed).

const { num, v } = require("exprforge");
const { safeDiv, dot3, len3, cross3, normalize3, clamp, EPS } = require("exprforge/math");

// Safe-normalize x component, falling back to 0 near zero length.
safeDiv(v("x"), len3(v("x"), v("y"), v("z")), num(0));

• safeDiv(numerator, denominatorExpr, fallback) — numerator / denominatorExpr when |denominatorExpr| > EPS, else fallback. Clamps the denominator before dividing rather than guarding the division directly, since select() always evaluates both branches (see below).
• dot3(ax, ay, az, bx, by, bz) — ax*bx + ay*by + az*bz.
• len3(x, y, z) — sqrt(x² + y² + z²).
• cross3(ax, ay, az, bx, by, bz) — 3-D cross product. Returns a plain JS object { x, y, z } of AST nodes (not a Node itself), for destructuring into your own letIn chain.
• normalize3(x, y, z, fx?, fy?, fz?) — safe-normalize; same { x, y, z } shape as cross3. Falls back to (fx, fy, fz) (default (0, 1, 0)) below EPS length. Computes the length once and shares it across all three divisions.
• clamp(val, lo, hi) — clamps to [lo, hi] via nested select/cmp; no runtime intrinsic.
• EPS — num(0.000001), the epsilon every guard above uses; exported for callers who want the same threshold in their own cmp() calls.

What deliberately stays out (project-specific conventions, not general math): a "near-vertical" world-up check, baked-in-PI degree/radian conversion, Rodrigues rotation, and a full Gram-Schmidt frame — see samples/spline-frame.js for those, and docs/v0.2.0-math-utilities.md for the full design rationale.

require("exprforge/math") also registers every one of these (except clamp) as macros, so they're usable directly inside fn/expr template text, not just from JS-authoring — see the next section.

Macros and externs (loadMacro / loadExtern)

The 22 Math functions above are fixed and built in — call them primitives. loadMacro/loadExtern register additional names usable the same way, inside fn/expr template text (and in .expr files, see loadExpr below) — this is the mechanism behind every example in "Examples, flashiest first" above, with very different guarantees depending on which one you reach for:

const { loadMacro, fn, evaluate } = require("exprforge");
require("exprforge/math"); // registers dot3/len3/cross3/normalize3/safeDiv as macros

const rodrigues = fn`
    rodrigues(t0x, t0y, t0z, t1x, t1y, t1z):
    let b = cross3(t0x, t0y, t0z, t1x, t1y, t1z);
    let bLen = sqrt(b.x^2 + b.y^2 + b.z^2);
    return bLen;
`;

• loadMacro(name, def) — def is a plain JS function (...argNodes) => Node or (...argNodes) => { field: Node, ... }, built entirely from existing ast.js primitives/other macros (exprforge/math's own dot3/len3/cross3/normalize3/safeDiv are registered exactly this way — see math/index.js). Inline-expanded into the caller's AST at build time, never emitted as a real call in any target: the emitted output is self-contained arithmetic, identical in spirit to writing the expansion out by hand. Safe by construction — if def returns real ast.js Nodes, the result is exactly as trustworthy as anything else this library emits. def can also be an AST function definition directly (e.g. straight out of fn`...`: loadMacro("foo", fn`foo(x): return x * 2;`)), sugar for the same thing — this is exactly how "Examples, flashiest first" above registers cross3.

  A macro returning multiple named values (like cross3's {x, y, z}) must be bound with let before its fields are readable — let b = cross3(...); b.x — using it bare inside a larger expression throws a clear error rather than guessing which field you meant.

  Gotcha: the let name itself never becomes a real value. let b = cross3(...); doesn't bind b to anything you can reference bare — b is consumed entirely as a naming prefix for b's flattened fields (internally, something like b__x/b__y/b__z). Referencing b on its own — including accidentally, via fn's own return { b }; shorthand — throws immediately, naming the fields that actually exist: "b" is bound to a multi-output macro result (fields: x, y, z) -- reference a field directly (e.g. "b.x"), not the bare name. This is easy to trip over precisely because the shorthand return syntax (see "Full-program syntax" below) makes { b } look like it should mean "the whole thing," the way it would for an ordinary scalar let.

  The classic macro trade-off still applies: expansion is pure substitution, so if a macro's body references one of its own parameters more than once, the caller's argument expression gets duplicated in the output everywhere that parameter appears — not shared, not auto-let-bound (safeDiv's own doc comment above already flags exactly this for its twice-referenced denominatorExpr; it's general to every macro now, not one helper). Pass an already-let-bound v(name) as the argument instead of a raw expensive expression if that duplication matters to you.

• loadExtern(name, def) — def is a plain per-target mapping object instead of a function, e.g. { evaluate: (x) => ..., js: ([x]) => `myLib.f(${x})`, zig: ([x]) => `mylib.f(${x})` }. A real native call, same mechanism as the 22 built-in primitives — just supplied by you instead of shipped here. Only the targets you provide a key for resolve; every other target still throws "no mapping" for that name, same as an unmapped primitive. ExprForge can't verify the named symbol actually exists in a given target, or that it behaves identically across every target you register a mapping for — that's entirely on you, the same way linking an unfamiliar library is in any other compiled language. Reach for this only when the math genuinely can't be expressed by composing existing macros/primitives; prefer a macro whenever it can.

Names are a single shared namespace with the 22 built-in primitives and with each other — loadMacro/loadExtern throw on a collision rather than silently shadowing anything.

What this doesn't buy you: no recursion, no loops, no mutable state

Now that one definition can reference another by name, it's a natural guess that a definition could call itself, or that two definitions could call each other back and forth. Neither works, on purpose — try it with the cross3/crossLength example above and have cross3 reference itself, and here's exactly what happens:

• A macro can't call itself, directly or through a cycle. This is enforced two different ways depending on how the macro was defined, and it's worth knowing which one applies: a macro defined as an AST function (straight fn`...` text, or every function in a .expr file/buffer) is resolved and inline-expanded once, at registration/load time, against whatever's registered so far — a definition only becomes referenceable after it's fully registered, so a self/forward reference simply survives as an ordinary, unmapped call node, failing later with the same "no mapping for Math function" error an unrelated typo would (even once that name eventually DOES get registered elsewhere) — no recursion detection needed, the ordering alone rules it out. A macro defined as a plain JS function (loadMacro(name, someFn)) runs fresh on every use instead, so it legitimately CAN reference other real macros each time — which means a genuine self/cyclic reference there needs an explicit runtime check instead of relying on ordering, and gets one: "<name>" can't call itself, directly or through a cycle, not a crash.
• No loops. A macro's body is built from the exact same primitives every other ExprForge expression is — select/cmp for a conditional value, nothing that iterates.
• No mutable state. AST nodes are values, not locations — there's nothing to assign to.
• Emitted output isn't a call, it's a copy. Every use of a macro expands its full arithmetic in place again — unlike a real function, there's no shared implementation at the call site, so a macro used many times in one formula makes the emitted source (correspondingly) larger each time, not smaller. This is a size/readability trade-off to know about, not a correctness concern.

This isn't a launch-day limitation waiting on a future release — it's the same "expression AST, not a program AST" boundary declared under "Intents" above, applied to this feature specifically because it's the one place someone's most likely to assume otherwise.

Sessions (createSession)

Every loadMacro/loadExtern/evaluate/emit/emitMany/loadExpr/ loadExprSource above registers into (or resolves against) one process-wide registry by default — fine for a single program registering its own fixed set of macros once, at startup. createSession() gives you an independent, additively-scoped registry instead, for whenever more than one is genuinely needed at once — e.g. a service evaluating math defined by several different users/tenants, where one user's loadMacro("helper", ...) must never resolve inside another user's expression just because they happened to pick the same name:

const { createSession, num, v, mul, call } = require("exprforge");

const session = createSession();
session.loadMacro("double", (x) => mul(x, num(2)));

const doubled = { name: "f", params: ["x"], body: call("double", v("x")) };
session.evaluate(doubled, [21]); // 42

// The global loadMacro/evaluate never see "double" at all -- it exists
// only inside this one session's own registry.

• Purely additive: the process-wide default registry (what every bare loadMacro/loadExtern/evaluate/emit call above already uses) is completely unaffected by a session's existence, and vice versa — nothing here changes what any existing call site does.
• Every session-bound method mirrors its global counterpart 1:1: session.loadMacro, session.loadExtern, session.evaluate, session.emit, session.emitMany, session.loadExpr, session.loadExprSource, session.expandMacros — same signatures, scoped to that session's own registry instead of the default one.
• Two sessions never see each other's registrations, even when both register the same name — registering "helper" in session A never collides with, or shadows, an unrelated "helper" in session B.
• Built-in primitives (sqrt, pow, ...) work identically everywhere — they're fixed and not registry-backed at all, so a session doesn't need, and can't be given, its own copy of them.
• No removal API. A session's registry is a plain object, garbage-collected normally once you drop your reference to it — rebuild a fresh createSession() instead of trying to unregister one macro/extern out of an existing one.

Adding a language

Write emitters/<lang>.js exporting an Emitter instance (see any existing file as a template), then add one line to emitters/registry.js. Nothing else changes — proven by the TypeScript emitter, added with no changes to base.js, build.js, or index.js. Emitter is a real class (not just a factory function), so a target that needs to intercept how expressions themselves get rendered — not just calls/emitSelect/formatFunction, all ordinary config — can subclass it instead: Perl/PHP override emitExpr's "var" case to add the $ sigil every reference needs, Scheme overrides the "bin" case for prefix notation. See emitters/scheme.js and emitters/perl.js.

Reserved-word collisions

Several emitters (QB64, Fortran, Zig, Scheme, COBOL) guard against a generated variable/parameter/function name colliding with that language's own reserved words or builtins — a <LANG>_RESERVED set checked at emission time, throwing a clear error instead of producing code that fails to compile somewhere downstream with no context (see e.g. QB64_RESERVED in emitters/qb64.js). These lists are not, and can't practically be, exhaustive — each covers the collisions that came up in this project's own samples plus the obvious/common ones for that language, not every reserved word in every language's full grammar. If you're naming your own functions/params/letIn bindings, especially ones you know will target a specific language, it's still on you to know that language's reserved words — Perl/PHP mostly sidestep this (every variable is $-sigiled, so it can't collide with a bareword keyword), but the sigil-free languages above genuinely can't be fully guarded against in advance.

COBOL is a partial exception: a parameter colliding with one of its narrow, syntax-specific quirks (e.g. a bare c, which breaks GnuCOBOL's CALL ... USING clause specifically) gets silently renamed internally (EFLF_c) rather than thrown at you — safe because every target here calls positionally, so a parameter's declared name is never visible to a caller in any of them. The function's own name and any outputs() field names are not covered by this — both remain part of the actual calling contract (a suite's field names are genuinely consumer-visible in every other target's return shape), so those still throw, same as before. See renameConflictingParams in emitters/cobol.js.

Named subexpressions and conditional values

Beyond num/v/bin/call, two more node types stay inside the expression model without introducing control flow:

• letIn(name, value, body) — name a subexpression to avoid recomputing it (e.g. sqrt(x²+y²+z²) once, then divide three components by it). Every let in a function gets lifted into an ordered list of local declarations ahead of the return statement/expression, in every target.

  Chaining several is normally hand-nested letIn calls, one inside the next, closing parens piling up at the end with no real hierarchy behind them — just bookkeeping to get everything hoisted before it's used. letChain(bindings, body) is that same nesting, built for you from a flat, ordered list instead — exactly what "The bottom: raw AST builders" above uses for crossLength's rx/ry/rz:

  const { v, num, mul, add, letChain, outputs } = require("exprforge");

  letChain(
      [
          ["t2", mul(v("t"), v("t"))],
          ["t3", mul(v("t2"), v("t"))],
      ],
      outputs({ t2: v("t2"), t3: v("t3") }),
  );
  // same tree as letIn("t2", ..., letIn("t3", ..., outputs({...})))

  bindings is an ordered array of [name, valueNode] pairs, not a {name: valueNode} object like outputs() takes — order is load-bearing here (a later binding's value can reference an earlier one's name), and that's clearer as an explicit sequence than resting on an object's key order. Pure authoring sugar: builds the identical let node structure letIn would, so it needs no emitter changes and round-trips through collectLets the same way.

• select(cond, then, else) + cmp(left, op, right) — conditional value selection. Every target has a genuinely different way to spell this: a native ternary where one exists (C, Java, C#), if-as-expression in Rust, a if cond else b in Python, cond and a or b in Lua (safe there specifically because only nil/false are falsy in Lua — a number is always truthy, so this never mis-selects at zero), an immediately-invoked function in Go (which has neither ternary nor an if-expression), and the equivalent arithmetic expression in QB64 (which has no conditional expression syntax whatsoever).

  select is not a branch — every target evaluates both then and else. Don't use it to guard division by zero or anything else undefined; clamp the operand itself with its own select first (see safeDiv in samples/spline-frame.js), or keep a real guard as hand-written code around the generated function.

See docs/planned-additions.md for the full design rationale, including why the naive "guard division with select" pattern is wrong.

Infix expression syntax (expr` `)

add(mul(v("a"), v("b")), num(1)) is exactly what gets built, but it's not what a human reads at a glance. expr is a tagged template literal that parses ordinary infix math syntax into that same tree — same nodes, different spelling, no new capability. See "Another layer down" above for a full worked example (crossLength, hand-inlined, no macro).

const { v, expr } = require("exprforge");

expr`a * b + 1`
// identical tree to add(mul(v("a"), v("b")), num(1))

expr`(-b + sqrt(b^2 - 4*a*c)) / (2*a)`
// the quadratic formula, readable as the quadratic formula

| Syntax | Lowers to | |---|---| | + - * / | add/sub/mul/div — standard precedence, left-associative | | ^ | call("pow", base, exponent) — not a bin node (there is no "^" operator in the AST; every emitter's calls table keys pow by name, even targets whose own syntax has a native ^/**). Right-associative and binds tighter than unary minus, standard math convention: -2^2 is -4, 2^3^2 is 512. | | -x | neg(x) | | name(args...) | call("name", ...args) — not checked against the 22 known functions at parse time, same deferred-to-emission-time error every hand-built call() already gets | | bare name | v("name") | | name.field | field(v("name"), "field") — only meaningful when name is bound to a multi-output macro result (see "Macros and externs"); binds tighter than ^, chainable (a.b.c) | | cond ? then : else | select(cmp(left, op, right), then, else) — the only place a comparison (> < >= <= == !=) is valid, matching cmp()'s own documented constraint that it's never a general boolean expression. A bare a > b with no ? is a parse-time error, not a deferred one. Chains naturally: a>0 ? 1 : b>0 ? 2 : 3. | | ${...} | Splices in an existing AST node as-is, or a plain JS number (auto-wrapped via num()). Anything else throws immediately. Plain strings aren't interpolatable — a bare identifier in the template text already means "variable", with no ${} needed. | | # ... | An end-of-line comment — runs to the next newline, produces no tokens. Works across ${...} interpolation boundaries too: a value interpolated inside an open comment is silently dropped, never validated (not even for what would otherwise be an invalid interpolation). |

Deliberately not in the grammar: let/outputs blocks (it's a pure expression grammar, same "expression AST, not a program AST" boundary declared under "Intents" — wrap the result in letIn/letChain/outputs, or reach for fn below, which adds exactly that) and &&/|| (the AST has no boolean-combinator node to lower them to).

// Named subexpressions still go around expr(), not inside it:
letIn("mag", expr`sqrt(x^2 + y^2)`, expr`x / mag`)

Full-program syntax (fn`...`)

expr covers one expression; fn covers a whole function body — let bindings plus a return, on top of the exact same expression grammar (every expression inside a fn template is parsed by the same engine expr uses). Lowers to real letChain/outputs calls, same "same nodes, different spelling" guarantee as expr itself. See "One layer down" above for a full worked example (cross3/crossLength, via loadMacro).

const { fn } = require("exprforge");

const body = fn`
    let mag = sqrt(x^2 + y^2);
    return { nx: x / mag, ny: y / mag };
`;
// identical tree to:
//   letIn("mag", call("sqrt", ...), outputs({ nx: div(v("x"), v("mag")), ny: ... }))

const normalize2 = { name: "normalize2", params: ["x", "y"], body };

| Syntax | Lowers to | |---|---| | let name = expr; | one [name, valueNode] pair, in order — a later let can reference an earlier one's name | | return expr; | the chain's final expression | | return { name: expr, ... }; | outputs({ name: node, ... }) as the chain's final expression | | return { name, ... }; | shorthand for return { name: name, ... }; — same convention JS object literals use for a property whose value is a same-named variable. Freely mixes with the explicit form: return { rx, ry: ry * 2, rz }; |

Duplicate let names aren't rejected by the parser itself — same deferred-to-collectLets behavior every hand-built letIn/letChain already has. A fn body with no let statements at all is just return expr;, equivalent to a bare expr call.

Optional signature line

Writing name/params separately, next to the body, is fine for a one-off — but fn can carry them too, with a leading name(params): line:

const { fn, emit, evaluate } = require("exprforge");

const normalize2 = fn`
    normalize2(x, y):
      let mag = sqrt(x^2 + y^2);
      return { nx: x / mag, ny: y / mag };
`;
// normalize2 is now the full {name, params, body} shape directly --
// no wrapping object needed.

evaluate(normalize2, [3, 4]);        // { nx: 0.6, ny: 0.8 }
emit(normalize2, "rust").source;     // ready to use immediately

This changes fn's return type based on what you wrote, deliberately: no signature → a bare Node, exactly as above and fully backward compatible; a signature present → the full {name, params, body} object. let/return still can't be used as a function name — a signature is told apart from a statement by the same rule that tells let/return apart from any other identifier, so naming a function let just parses as (and fails as) a let statement instead.

Grammar reference

Everything above, as one formal grammar instead of two separate tables — copied verbatim from expr.js's/fn.js's own header comments, not a paraphrase, so it can't drift out of sync with what the parser actually does:

program        := signature? stmt* returnStmt
signature      := IDENT "(" (IDENT ("," IDENT)*)? ")" ":"
stmt           := "let" IDENT "=" expression ";"
returnStmt     := "return" expression ";"
                | "return" "{" field ("," field)* "}" ";"
field          := IDENT (":" expression)?

expression     := ternary
ternary        := additive ( compOp additive "?" expression ":" expression )?
compOp         := ">" | "<" | ">=" | "<=" | "==" | "!="
additive       := multiplicative ( ("+"|"-") multiplicative )*
multiplicative := unary ( ("*"|"/") unary )*
unary          := "-" unary | power
power          := postfix ( "^" unary )?
postfix        := primary ( "." IDENT )*
primary        := NUMBER | IDENT ("(" args ")")? | "(" expression ")" | HOLE
args           := expression ("," expression)*

expr`...` is exactly expression on its own — one formula, no let/return. fn`...` is program — expression's entire grammar embedded unchanged inside every let's value and every return, parsed by the exact same Parser class both tags share (not a reimplementation — fn literally imports expr.js's tokenizer and parser rather than forking either).

Not shown above (lexical, not grammar): # ... end-of-line comments (run to the next newline, produce no tokens); ${...} interpolation, which splices an existing Node or a plain number in directly (see "Infix expression syntax" above) and becomes a HOLE token in the grammar above; and that let/return are ordinary identifiers everywhere except statement-start position — expr`let * 2` still means v("let") * 2, not a syntax error, since expr's own grammar has no stmt/signature rules to make either one special.

loadExprSource/loadExpr (below) parse the exact same program grammar, repeatedly, over one shared buffer — with one deliberate difference: signature is no longer optional, and gains a mandatory leading keyword:

signature := ("fn" | "macro") IDENT "(" (IDENT ("," IDENT)*)? ")" ":"

fn/macro are contextual the same way let/return already are — special only in this exact position, ordinary identifiers everywhere else (a parameter, or even a signature name, genuinely called fn still works: fn`fn(x): return x * 2;` parses as a function named fn, unaffected, since a single fn`...` call never runs in this stricter mode at all — see "Loading a .expr file" below for what the two keywords mean and why the keyword is mandatory there specifically.

Printing an AST back out, and a native evaluator

Two things that fall out of fn existing: emitters.expr is a real, registered target that prints any AST back out as fn/expr source text (the reverse of parsing it). And evaluate(fn, args) (also exported from the main package) is a native tree-walking interpreter over the same AST, computing a result directly in JS with no codegen or compile step — the same node types every emitter already handles, backed by the real Math.* functions.

const { emit, evaluate } = require("exprforge");

emit(normalize2, "expr").source;
// "fn normalize2(x, y):\n  let mag = sqrt(((x^2) + (y^2)));\n  return { nx: (x / mag), ny: (y / mag) };\n"

evaluate(normalize2, [3, 4]);
// { nx: 0.6, ny: 0.8 }

Read this output for what it actually is, not as a pretty-printer of whatever you originally typed: expandMacros() runs before every emitter, "expr" included (same as Rust's/COBOL's/etc. own crossLength never mentions cross3 either — see "Examples, flashiest first" above) — so a macro-free formula like normalize2 above prints back out genuinely readable, but a formula built from several composed macros/helpers prints its fully-reduced canonical form instead: gensym'd internal let names, multi-output fields flattened to name__field, all of it. That's not a readability regression to fix — it's the same "converges on the true, expanded form" property every other target already has, just visible here because "expr" is the one target whose reduced output happens to also be valid input to itself again. What that buys you is real, just not "pretty debug output": a concrete, load-bearing way to confirm a composed formula actually reduces to what you expect (test/conformance.test.js's own round-trip check — print, reparse, re-evaluate, compare — is exactly this, run against every sample this project has).

Loading a .expr file (loadExpr)

loadExpr(path) goes the other direction from emit(fn, "expr") above: reads a .expr file (that same round-trip text format) and parses it as zero or more fn name(params): let ...; return ...; / macro name(params): let ...; return ...; definitions, each fn-marked one usable directly with evaluate()/emit()/emitMany() — this is the file-backed sibling of loadExprSource in "Examples, flashiest first" above:

const { loadExpr, evaluate } = require("exprforge");

const defs = loadExpr("./formulas/vectors.expr"); // "fn hyp(a, b): return sqrt(a^2 + b^2);"
evaluate(defs.hyp, [3, 4]); // 5

A function defined earlier in the file is available to a function defined later in the same file — as an inline macro, the exact same "expanded, not called" model loadMacro itself uses above (see that section for why) — regardless of whether it's marked fn or macro. The keyword only decides what's in the object this call actually returns: fn means "hand this back to me too," macro means "inline-only, never returned on its own" (see "Examples, flashiest first" above for the full cross3/crossLength walkthrough — cross3 is macro, crossLength is fn, and only defs.crossLength exists). Neither keyword is optional — every definition states one explicitly; a bare name(params): with neither throws, naming both keywords and what each means. A .expr file can also reference globally loaded macros, not just earlier definitions in the same file — the two sources merge.

loadExpr(path) is a thin fs.readFileSync wrapper around loadExprSource(text, label?) — the same parser, given source text directly. Use that one wherever the text isn't coming from a real file on disk (a browser text buffer, an HTTP response, ...) — the playground's editor uses it exactly this way to let one buffer hold several definitions. label (default "loadExprSource()") identifies the source in error messages, the way a file path does for loadExpr.

Multiple named outputs

outputs({ name: Node, ... }) computes several named values from ONE shared letIn chain, instead of one function per value each re-deriving the whole chain from scratch:

const { num, v, add, sub, letIn, outputs } = require("exprforge");

const sumAndDiff = {
    name: "sumAndDiff",
    params: ["a", "b"],
    body: letIn("total", add(v("a"), v("b")),
          letIn("delta", sub(v("a"), v("b")),
              outputs({ sum: v("total"), diff: v("delta") })
          )),
};

Only valid as a function's top-level body (wrap it in letIns, don't nest it inside bin/call/select). Each target renders it as whatever multi-value idiom it has, since none of them agree:

| Target | Shape | |---|---| | JS | object literal | | Go, Lua, Scheme | native multiple return values ((values ...) in Scheme) | | C#, Julia | a native named value tuple / named tuple | | C / Rust / Zig | a small ...Result struct, returned by value | | Java, Python | a nested/local Result class | | QB64, Fortran | a SUB/subroutine with the outputs as trailing by-reference (intent(out)) parameters | | Perl | a hash ref ({ rx => ..., ry => ... }) | | PHP | an associative array (['rx' => ..., 'ry' => ...]) | | COBOL | a callable PROGRAM-ID, every output as a trailing BY REFERENCE parameter, invoked via CALL "name" USING ... — COBOL's scalar case uses this same shape too, not a FUNCTION-style return (see Testing below) |

Go specifically does not use named return values ((rx, ry float64)) even though Go supports them and it reads nicer: those are sugar for pre-declared locals in the function's own scope, and that collides — for real, on the first suite this feature was built for — whenever an output name matches an internal letIn name. Plain unnamed return types side-step the whole collision class regardless of naming; a leading comment documents the order instead (same reason Lua's return, also positional, gets one). C#'s tuple has no such risk — a tuple literal's element names aren't pre-declared locals the way Go's named returns are.

Security considerations

"Trust only the layer you need" (see "Intents" above) is a claim, not just a description — the raw AST layer specifically has to be safe to build from untrusted input, since it's the one this README recommends reaching for when you want the least amount of magic between your formula and the code it emits. A few concrete guarantees that follow from that:

• The raw builders validate their own inputs. num/v/bin/call/ letIn/cmp/outputs/field all reject anything that isn't a safe value — an identifier must match the exact same rule expr/fn's own tokenizer already enforces on text it parses (start with a letter/_, then letters/digits/_ only), an operator must be one of the fixed +/-/*// (or, for cmp, >/</>=/<=/==/!=) set, and a number must actually be finite. Without this, the raw builder layer would have been the least safe one to build from untrusted input, not the most — fn/expr's own tokenizer never produces anything but a safe identifier to begin with, so this was the one place a malformed or malicious name (e.g. v("x); process.exit(1); //")) could otherwise reach emitted output completely unescaped, verbatim, in every one of 16 targets at once.
• expr/fn cap how deeply an expression can nest. Parens, function-call arguments, and ternary branches can nest up to 100 levels deep (MAX_EXPRESSION_DEPTH in expr.js) before parsing fails with one clear, controlled error — comfortably below where a pathologically nested input ("((((...))))" or "f(f(f(...)))" thousands deep, plausible if this ever parses genuinely untrusted, unbounded-size text) would otherwise blow the real JS call stack with a raw "Maximum call stack size exceeded". A wide-but-shallow expression (many terms, no real nesting) is unaffected regardless of length — only genuine nesting depth is bounded.
• createSession() isolates macro/extern registrations between independent users/tenants sharing one process — see "Sessions" above.
• A caller-supplied macro/extern throwing reports which one. A macro function, or an extern's own evaluate/per-target template, is code you (or whoever registered it) supplied — if it has a bug, the error it throws is wrapped with context naming the macro/extern/target responsible, rather than propagating bare with no indication of where it came from.

What this doesn't cover, deliberately: loadExtern's per-target templates are real native code you supply — ExprForge can't verify the named symbol actually exists in a given target, or that it behaves identically across every target you provide a mapping for (see "Macros and externs" above). That risk is inherent to what an extern is, not something a validation layer could close without also closing off the feature itself.

Testing

npm test

Runs node --test. For each sample, that's three kinds of check:

• Emitted JS vs. an independently hand-written reference implementation (catches a wrong formula in the AST itself).
• Every other emitted target vs. that same JS, compiled (and, for TypeScript, also type-checked under --strict) and run, with the sample inputs as arguments (catches an emitter bug).
• The expr-syntax printer (emitters/exprsyntax.js) vs. fn's own parser: every sample AST in this suite is printed back out as fn/ expr source text, reparsed, and evaluated (via evaluate()) to confirm the round trip behaves identically to the original. This is a stronger claim than either piece being separately unit-tested — the printer and the parser are two independent pieces of code that have to agree with each other across every real formula this project has, not just cases either one's own author thought to hand-write a test for. It's also not hypothetical: this exact check caught a real bug during development (a ternary printed without enough parens, so crossX / (rLen > eps ? rLen : 1) reparsed with the wrong grouping) that every other check here — including full cross-language conformance — had no way to catch, since it's specific to the printer/parser pair and nothing else in the pipeline touches that code path.

The compiled/interpreted-language checks need their toolchain on PATH and skip (not fail) when it's missing, so npm test degrades gracefully on any one machine. Every one of tsc/qb64pe/dotnet/python3/lua/ perl/php/julia/gfortran/zig/guile3.0/cobc is treated exactly like gcc/go/rustc/javac: looked up on PATH, never a project dependency — exprforge only ever generates source text for these, it doesn't execute or type-check any of it itself. package.json has zero dependencies of any kind, matching this.

CI is one workflow file per target language (.github/workflows/test-*.yml), run in parallel — they have nothing to do with each other, so there's no reason to serialize installing sixteen different toolchains (QB64-PE alone, built from source and cached by version, takes several minutes) into one job, and splitting by file rather than by job within one file is also what gets each language its own real status badge above, not just one combined "did everything pass" badge. Each workflow installs only its own toolchain and runs EXPRFORGE_TEST_TARGETS=<Label> npm test; that environment variable (read once in test/conformance.test.js) filters the target lists down to just that one language, plus the toolchain- independent JS/reference checks, which every workflow repeats — cheap, and a redundant sanity check each time. Unset locally, so a plain npm test still runs everything your own machine's installed toolchains allow.

Coverage: npm run test:coverage runs the same suite through Node's own built-in instrumentation (--experimental-test-coverage — no external dependency), honoring whatever toolchains are on your machine, with no threshold enforced. CI's own "Test Coverage" workflow (badge above) is deliberately narrower and stricter: it runs only the toolchain-free Interpreter slice (EXPRFORGE_TEST_TARGETS=Interpreter, same filter every test-*.yml workflow already uses), gated on a fixed threshold, since that's the one environment where the number means the same thing on every run — installing zero, one, or a different subset of the 17 per-language toolchains would make an aggregate threshold either flaky or meaningless. Core logic (ast.js/evaluate.js/expr.js/ fn.js/index.js/load-expr.js/macros.js/math//primitives.js/ samples//util.js) sits at 95-100% in every environment, toolchains or not; per-target emitter coverage is intentionally excluded from that mental model — code that only really runs inside a real compiled/ interpreted program can't be exercised without that target's own toolchain, and that verification already happens for real, by actually compiling and running the output, in the 17 other workflows — a lower coverage percentage there isn't itself a problem this gate is positioned to catch.

A few of these needed real debugging to get right, all found by actually compiling/running against a real toolchain rather than assumed to work:

• QB64: Dim x# AS DOUBLE (sigil and an AS clause together) is a syntax error; has to be Dim x AS DOUBLE. Its own exponential notation uses D, not E (1D-9, not 1e-9#) — including when reading its PRINT output back, not just in literals. A chunk of QB64/BASIC builtins (len, val, pos, log, ... — see QB64_RESERVED in emitters/qb64.js) silently conflict with a same-named variable; the emitter throws a clear error at emission time instead of failing to compile later with no context. The test harness runs compiled binaries headless via the $CONSOLE:ONLY metacommand, so no display (real or virtual) is needed — no xvfb-run required for these console-only test programs, unlike a typical QB64 build.
• C#: forbids a member sharing its enclosing type's exact name (CS0542) — every SpEf-prefixed sample name here is already capitalized, so the obvious capitalize(fn.name) wrapper-class name collided with the method name outright; see wrapperClassName in emitters/csharp.js. Bare integer-valued literals are int by default, and int / int is integer division — every literal is suffixed d unconditionally to rule that out, not just the cases that would otherwise break.
• Python: math.floor/math.ceil/math.trunc/round all return int, not float — wrapped with float(...) to stay float64 throughout, matching every other target.
• Lua: 5.3+ removed math.pow (use the ^ operator) and math.atan2 (use two-argument math.atan(y, x)); there's no math.round or math.trunc or math.sign at any version (manual floor(x+0.5), math.modf(x), and an and/or chain respectively).
• Perl / PHP: every variable reference needs a $ sigil, which base.js's shared emitExpr doesn't produce for anything — both subclass Emitter to override just the "var" case (see "Adding a language" above) rather than needing a new hook every other emitter would have to ignore. Perl has no log2()/trunc()/hypot() in core (POSIX supplies trunc/hypot, log2 is derived); PHP has no trunc() at all (floor/ceil picked by sign instead, not an (int) cast, which would misbehave outside PHP's platform integer range).
• Julia: round() defaults to ties-to-even (banker's rounding), not ties-away-from-zero like every other target here — round(x, RoundNearestTiesAway) used explicitly to actually match, not just avoid the untested case. sign(-0.0) returns -0.0, which is numerically equal to 0.0 for the tolerance-based comparisons this project uses, so it isn't a real divergence.
• Fortran: a literal without the D0 exponent marker is parsed as single-precision first, then widened — silently losing precision before it reaches a real(8) variable, unlike every other target's literals — so every literal gets it, not just ones already in scientific notation. FLOOR/CEILING return the default INTEGER kind, not REAL, wrapped back with REAL(..., 8). No ternary, but MERGE(then, else, mask) is a genuine expression-level conditional — confirmed to evaluate both branches regardless of mask, matching select()'s own contract exactly. The native 2-argument SIGN(A, B) ("magnitude of A, sign of B") is not this project's sign(x) — SIGN(1.0, 0.0) returns 1.0, not 0.0 — built from MERGE instead. Every gensym'd identifier this library ever introduces internally (e.g. a macro's own alpha-renamed let, see "Macros and externs") starts with a letter, never _ — Fortran is the one target that rejects a leading underscore outright, confirmed against a real compiler ("Invalid character in name").
• Zig: std.debug.print writes to stderr by design, not stdout — the conformance harness has to use std.io.getStdOut().writer() instead, or every result silently comes back empty. A fully-literal expression with no runtime operand (e.g. sqrt(2.0) alone) gets evaluated at Zig's extended comptime_float precision instead of truncated to an actual IEEE double, unless explicitly @as(f64, ...)-cast — every literal gets that cast, not just ones that would otherwise hit this.
• Scheme (Guile): a bare integer literal like 2 is exact in Scheme's reader syntax, and exact arithmetic that never touches an inexact (float) operand stays exact — (/ 1 3) prints as the fraction 1/3, not 0.333.... Every literal gets .0 appended unless it already has a decimal point or exponent, forcing inexactness by literal syntax alone rather than relying on some other operand in the same expression happening to already be a float.
• COBOL (GnuCOBOL): has no expression-level conditional at all — no ternary, no MERGE-equivalent. select() is built from six small helper FUNCTION-ID modules (one per comparator), but confirmed against a real compile+run that a user-defined FUNCTION call silently miscomputes — no error, just a wrong number — when given a complex argument (one containing its own nested call); every argument to a helper gets spilled into its own COMPUTEd temp first, always, not just when an argument "looks complex." BY VALUE parameter passing is explicitly flagged "unfinished" by the compiler — every function uses BY REFERENCE (the default) instead, which is also why COBOL is the one target where even a scalar function's return value is a trailing by-reference parameter (see the outputs table above), not a FUNCTION-style return: calling a user FUNCTION by name breaks if that name contains an underscore (confirmed against a real compiler), while CALL "name" takes it as a plain string literal, immune to that. Source lines have a real ~512-byte cap — long expressions (e.g. samples/kitchen-sink.js's summed call to all 22 functions) get wrapped at word boundaries. The native FUNCTION SIGN is 1-argument (SIGN(x)), unlike Fortran's identically-named 2-argument intrinsic — and unlike Fortran's, is genuinely zero-safe.

One test (normalizeX) is deliberately excluded from the QB64 check only: it exists specifically to demonstrate the "don't guard division with select" pitfall from "Named subexpressions and conditional values" above, and QB64 is the one target where that pitfall actually produces NaN (every other target, including Lua's and/or, genuinely short-circuits around it) — that's the AST being correctly unsafe on purpose, not an emitter bug.

License

MIT — see LICENSE.
