homebridge-blinds

v3.0.1

Published

15 days ago

Homebridge plugin to control HTTP, REST, MQTT, shell-script and CLI-driven blinds, shades, awnings, shutters, and roller curtains in Apple HomeKit.

homebridge-blinds

Bring blinds, shades, awnings, shutters, and roller curtains into Apple HomeKit via Homebridge. If your blind exposes any kind of network or scriptable interface, this plugin can drive it.

HTTP / REST — up / down / stop / setPosition endpoints with custom methods, headers, bodies, retries, and per-URL timeouts.
Shell commands — prefix any URL with file:// to run a script, an MQTT publish (mosquitto_pub), a serial bridge, or anything else you can invoke from a shell.
Webhooks — optional HTTP listener (Basic Auth and TLS supported) so external automations or physical remotes can push position updates back into HomeKit.
Polled position feedback with JSONata extraction for nested JSON payloads.
Resilient by default — per-URL retry budgets, exponential backoff, command repeats for unreliable RF, slider debouncing, and last-known position persisted across Homebridge restarts.

Tested with Tasmota, Bond Bridge, Louvolite Neo Smart Blinds, and many DIY firmware variants. Written in TypeScript, verified by Homebridge, runs on Homebridge 1.8+ and 2.x.

Install

New to Homebridge? Start with the Homebridge docs. On a Raspberry Pi, see this guide.

The easiest path is the Homebridge UI: search for homebridge-blinds and click Install. Or, from a terminal:

sudo npm install -g homebridge-blinds

Quick start

You only need three things to get going:

One or more URLs the plugin will hit to drive the blind (up_url, down_url, stop_url).
motion_time — milliseconds your motor takes to move from fully open to fully closed.
A name that will show up in the Home app.

Drop this into the accessories array of your Homebridge config.json:

{
    "accessory": "BlindsHTTP",
    "name": "Window",
    "up_url": "http://1.2.3.4/window/up",
    "down_url": "http://1.2.3.4/window/down",
    "stop_url": "http://1.2.3.4/window/stop",
    "motion_time": 10000
}

Restart Homebridge. The blind appears as a Window Covering tile in the Home app — drag the slider, the plugin issues the up/down/stop requests on your behalf. Method defaults to GET; status 200 counts as success.

Tip: if you use the Homebridge UI, every option below is also available as a form field — you don't need to hand-edit JSON.

Common scenarios

Pick the closest match and copy the matching example. Each one is a complete, working config you can paste in and tweak.

| If your blind… | Use this example | | -------------------------------------------------------------- | ---------------------------------------------------------------------- | | Has separate up / down / stop endpoints (most common) | examples/basic.json | | Accepts an exact target position (e.g. Tasmota Shutter) | examples/tasmota.json | | Is a Bond Bridge–controlled motor | examples/bond-bridge.json | | Is a Louvolite Neo Smart Blind | examples/louvolite-neo.json | | Is an awning or shade where "closed" means physically extended | examples/awning-inverted.json | | Reports its real position back via a polled URL | examples/position-feedback.json | | Pushes position updates via webhook (e.g. external automation) | examples/webhook-push.json | | Has different up vs. down speeds, or non-linear motion | examples/non-linear-motion.json | | Is RF-driven and sometimes misses commands | examples/unreliable-rf.json | | Is driven by an MQTT publish or a custom shell script | examples/shell-script.json | | You want to expose multiple blinds at once | examples/multiple-blinds.json |

A community-maintained list of working setups lives on the Wiki.

Configuration reference

Every option is documented below. Only name, the URLs you want to use, and motion_time are required — everything else has a sensible default. A fully populated example sits at the bottom of this section.

URLs (`up_url`, `down_url`, `stop_url`, `pos_url`)

A URL can be a plain string (just the URL) or an object with these keys:

| Key | Default | Description | | ------------- | -------------------- | ------------------------------------------------------------------------------------------- | | url | required | The HTTP URL, or a file:// shell command (see below). | | method | GET | GET, POST, PUT, PATCH, or DELETE. | | headers | — | Object of header name → value. | | body | — | String or JSON-serializable object. Sent for non-GET methods. | | maxAttempts | 5 | Retry budget for this URL only. | | retryDelay | 2000 | Base delay (ms) between retries; grows exponentially per attempt. | | timeout | request_timeout_ms | Per-attempt timeout in ms. Falls back to the global request_timeout_ms (default 10000). |

Any URL can be omitted — the plugin simply won't issue that command.

// Compact: just the URL string
"up_url": "http://1.2.3.4/window/up"

// Full: every override available
"up_url": {
    "url": "http://1.2.3.4/window/up",
    "method": "POST",
    "headers": { "API-Token": "abc" },
    "body": "{}",
    "timeout": 5000
}

Position placeholders

You can target an exact position by embedding placeholders in the URL, body, or any header value:

%%POS%% — replaced with the integer target 0–100 (treated as plain text; safe to drop inside a JSON string).
"%%POSINT%%" — the quoted placeholder is replaced as a raw JSON number, dropping the surrounding quotes. Use when your device expects a numeric field, e.g. { "position": "%%POSINT%%" } becomes { "position": 42 }.

When a placeholder is present the plugin trusts the request to drive the blind to the exact target, so no separate stop command is sent (unless trigger_stop_at_boundaries is true).

`file://` — run a shell command

Prefix any URL with file:// to run a shell command instead of an HTTP request. Useful for MQTT publishes, serial commands, or custom scripts. See the Wiki for examples.

`http_success_codes`

HTTP status codes that count as success. Defaults to [200]; set to e.g. [200, 202, 204] if your device returns something else.

Motion timing and calibration

motion_time (ms) is how long the motor takes to move fully open ↔ fully closed. This is required even when pos_url is configured — it tells the plugin when the blind should have arrived, so it doesn't hammer the device with status checks.

Tip: filming the blinds with your phone gives the most accurate timing. If multiple blinds run on the same controller and you see network errors when they all move at once, set slightly different motion_time values per blind (e.g. 9800, 10000, 10200).

Per-direction and non-linear motion (`motion_time_graph`)

When up and down speeds differ, or motion is non-linear (slow start, fast middle, etc.), use motion_time_graph:

"motion_time_graph": {
    "up":   [{ "pos": 0, "seconds": 0 }, { "pos": 50, "seconds": 9.7 }, { "pos": 100, "seconds": 14.3 }],
    "down": [{ "pos": 100, "seconds": 0 }, { "pos": 0, "seconds": 23.7 }]
}

Each direction must include entries for both pos: 0 and pos: 100. Intermediate points describe a piecewise-linear curve. motion_time_graph takes precedence over motion_time when both are set.

response_lag_ms adds a fixed pre-motion delay to account for network or RF latency between sending the command and the motor actually starting.

Position polling

| Option | Default | Description | | ------------- | ------- | ------------------------------------------------------------------------------------------------------- | | pos_url | — | URL polled for the actual blind position. Must return 0–100, or use pos_jsonata to extract it. | | pos_poll_ms | 15000 | Milliseconds between polls (minimum 5000). | | pos_jsonata | — | JSONata expression run against the parsed JSON response to extract the position. |

If your device returns plain text (e.g. just 42), no pos_jsonata is needed. If it returns JSON like {"ShutterPosition1": 42}, set pos_jsonata to ShutterPosition1. If it returns JSON without a clear field name, the plugin uses the first numeric value in the object.

Position webhook (push-based updates)

When your device or another automation can push position changes, run a small HTTP listener so HomeKit stays in sync without polling. Send any HTTP method to http://<homebridge-host>:<webhook_port>/ — the body is ignored; only the query string matters:

| Query string | Effect | | --------------------- | --------------------------------------------------------------------------------------------------------------------- | | ?pos=<0-100> | Update both CurrentPosition and TargetPosition. Use this to sync HomeKit after the device has moved. | | ?target=<0-100> | Update TargetPosition only, without driving the motor. Use when an external system has already moved the blind. | | ?pos=<N>&target=<N> | When both are present, pos wins. |

| Option | Default | Description | | ------------------------ | ------- | -------------------------------------------------------------- | | webhook_port | 0 | Port to listen on. 0 disables the listener. | | webhook_http_auth_user | — | Optional Basic Auth username. | | webhook_http_auth_pass | — | Optional Basic Auth password. | | webhook_https | false | Use HTTPS instead of HTTP. | | webhook_https_keyfile | — | Path to TLS private key. Auto-generated and cached if omitted. | | webhook_https_certfile | — | Path to TLS certificate. Auto-generated and cached if omitted. |

Credentials are compared with timing-safe equality, and self-generated certificates rotate automatically before expiry.

Outbound position mapping (`send_pos_jsonata`)

JSONata expression that maps the HomeKit target (0–100) to whatever value your device expects before substituting into %%POS%% or %%POSINT%%. The input to the expression is the integer position; the output is substituted directly.

"send_pos_jsonata": "$round( ( 100 - $number($) ) * 255 / 100 )"

The above inverts the value and scales it from 0–100 to 0–255.

Reliability and retries

| Option | Default | Description | | ----------------------- | ------- | ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ | | request_timeout_ms | 10000 | Per-attempt HTTP timeout. Lower values prevent stalls when the device is unreachable. | | command_repeat_count | 1 | Send each move command this many times in sequence. Helps with unreliable RF blinds that miss the first command. | | obstruction_threshold | 1 | Number of consecutive failed requests required before HomeKit's ObstructionDetected is set to true. Increase to filter out transient flakes (e.g. a brief Wi-Fi blip). The counter resets to zero on the next successful request. | | set_debounce_ms | 0 | Wait this many milliseconds after the last TargetPosition change before issuing the move command. Coalesces the burst of events the Home app fires while the user is dragging the slider into a single HTTP request against the device. 0 disables debouncing. |

Per-URL maxAttempts, retryDelay, and timeout overrides take precedence over the global values.

Battery (optional)

Battery-powered blinds (e.g. Soma, Ikea, some Bond-controlled units) can expose their charge level in HomeKit. When battery_url is set, the plugin adds a HomeKit Battery service alongside the WindowCovering and polls the URL on a slow cadence (default every 5 minutes).

| Option | Default | Description | | ----------------------- | -------- | ------------------------------------------------------------------------------------------------------------------------ | | battery_url | — | URL polled to read battery percentage. Must return 0–100, or use battery_jsonata to extract from a larger payload. | | battery_jsonata | — | JSONata expression run against the parsed JSON response to extract the battery level. | | battery_poll_ms | 300000 | Milliseconds between battery polls. Minimum 30000. Battery state changes slowly, so a long interval is fine. | | battery_low_threshold | 20 | iOS shows the low-battery indicator when BatteryLevel is at or below this value. |

Battery-poll failures do not trip ObstructionDetected — the blind itself may be perfectly reachable on its primary URLs.

Optional behavior

Extra HomeKit controls

Position quirks

| Option | Default | Description | | ---------------------------- | ------- | ---------------------------------------------------------------------------------------------------------------------------- | | invert_position | false | Swap the 0% and 100% endpoints in HomeKit. Common for awnings/shades where "closed" means physically extended. | | use_same_url_for_stop | false | Re-send the most recent up/down URL instead of stop_url. For blinds that toggle on a single endpoint. | | trigger_stop_at_boundaries | false | Send a stop command even when moving to fully open or fully closed. Most blinds stop themselves; only enable if yours don't. |

Identity and diagnostics

| Option | Default | Description | | --------------- | ------- | -------------------------------------------------------------------------------------------------------------------------- | | unique_serial | false | Use a UUID-based serial/model in HomeKit. Required for some external integrations (e.g. Eve) that expect distinct serials. | | verbose | false | Log additional diagnostics: every poll, motion calculations, JSON parse errors, etc. Useful when debugging. |

HomeKit characteristics exposed

The accessory implements the standard HAP WindowCovering service plus an AccessoryInformation service. The following characteristics are wired:

| Characteristic | Direction | Notes | | --------------------- | ---------- | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | CurrentPosition | read | Returns the cached last-known position immediately; never blocks on the network. Polled in the background when pos_url is set, and persisted across Homebridge restarts. | | TargetPosition | read/write | Writes trigger the move pipeline. Optionally debounced via set_debounce_ms. | | PositionState | read | INCREASING / DECREASING / STOPPED. | | ObstructionDetected | read | Set on retry-exhausted failures (after obstruction_threshold consecutive failures). Clears on the next success. | | HoldPosition | write | Standard HAP characteristic on the WindowCovering tile itself — the Home app exposes it inline, and Siri/automations can target it ("stop the blinds"). Sends stop_url. |

HoldPosition is different from the optional show_stop_button feature (below): the latter adds a separate HomeKit Switch accessory. Most users should rely on HoldPosition. The Stop button is kept for setups that already have automations bound to that switch.

Full advanced example

A maximalist example showing every supported option at once. You almost certainly don't need most of this — copy from examples/ instead and only reach for these knobs if your blind genuinely needs them.

{
    "accessory": "BlindsHTTP",
    "name": "Window",
    "up_url": {
        "url": "http://1.2.3.4/window/up?pos=%%POS%%",
        "body": "{}",
        "headers": { "API-Token": "aaabbbcccddd" },
        "method": "PUT",
        "maxAttempts": 5,
        "retryDelay": 2000,
        "timeout": 8000
    },
    "down_url": {
        "url": "http://1.2.3.4/window/down?pos=%%POS%%",
        "body": "{}",
        "headers": { "API-Token": "aaabbbcccddd" },
        "method": "PUT"
    },
    "stop_url": {
        "url": "http://1.2.3.4/window/stop",
        "headers": { "API-Token": "aaabbbcccddd" },
        "method": "PUT"
    },
    "send_pos_jsonata": "$round( ( 100 - $number($) ) * 255 / 100 )",
    "pos_url": "http://1.2.3.4/window/position",
    "pos_poll_ms": 15000,
    "pos_jsonata": "ShutterPosition1",
    "http_success_codes": [200, 204],
    "response_lag_ms": 0,
    "request_timeout_ms": 10000,
    "command_repeat_count": 1,
    "obstruction_threshold": 1,
    "set_debounce_ms": 0,
    "battery_url": "http://1.2.3.4/window/battery",
    "battery_jsonata": "BatteryLevel",
    "battery_poll_ms": 300000,
    "battery_low_threshold": 20,
    "motion_time_graph": {
        "up": [
            { "pos": 0, "seconds": 0 },
            { "pos": 50, "seconds": 9.7 },
            { "pos": 100, "seconds": 14.3 }
        ],
        "down": [
            { "pos": 100, "seconds": 0 },
            { "pos": 0, "seconds": 23.7 }
        ]
    },
    "show_toggle_button": false,
    "show_stop_button": false,
    "show_favorite_buttons": [25, 75],
    "use_same_url_for_stop": false,
    "trigger_stop_at_boundaries": false,
    "invert_position": false,
    "webhook_port": 51828,
    "verbose": false
}

Migration from v2

v3 is a TypeScript rewrite, but every v2 configuration key still works. Any key that has been renamed (e.g. position_url → pos_url) will continue to work and log a one-time warning at startup. See CHANGELOG.md for the full list of changes.

Development

npm install
npm run lint         # ESLint (flat config, typescript-eslint)
npm run typecheck    # tsc --noEmit
npm test             # vitest
npm run build        # emits dist/
npm run format       # prettier --write
npm run smoke        # end-to-end packaging check (requires npm run build first)

prepublishOnly chains format:check, lint, typecheck, test, build, and smoke, so a clean npm publish proves the whole pipeline.

How to contribute

Bug reports, feature requests, and pull requests are welcome. When filing an issue, please include the relevant Homebridge log lines (run with verbose: true for additional context) and your config (with secrets redacted).

Credits

A huge thank you to @zwerch, the original creator of this plugin.

Support this project

If this plugin saves you time and you'd like to say thanks:

Star and share the projects you like
PayPal — one-time donations to dxdc
Venmo — one-time donations
