maptiles-doctor

Check a MapLibre/Mapbox style against the artifacts it actually ships with — PMTiles, MBTiles, TileJSON, sprites, glyphs and the vector tiles themselves — and report where they disagree.

A style can be valid JSON, pass every schema validator, and still ship a broken map: a source-layer was renamed in the tileset, an icon left the sprite, a glyph range stopped being served, a property an expression reads is no longer in the tiles. Nothing in the style is wrong on its own — it just no longer agrees with what is deployed next to it.

📖 Documentation · Repository

Install

npx maptiles-doctor check style.json --source basemap=world.pmtiles

npm install --save-dev maptiles-doctor

Requires Node 24.18.1 or newer.

Usage

maptiles-doctor check <style> [options]
maptiles-doctor schema [options]

check options

| Option | Default | What it does | | ------------------------------ | ---------------- | --------------------------------------------------------------------------------------------------------------------------------------------------------- | | -s, --source <id=path> | — | Point a style source id at the artifact to check it against: a .pmtiles or .mbtiles file, or a TileJSON file or URL. Repeatable; overrides the style. | | -f, --format <format> | pretty | pretty, json, sarif, github, html. | | -o, --output <path> | stdout | Write the rendered report to a file. | | --fail-threshold <severity> | broken | Lowest severity that exits 1: info, warning, risky, broken. | | --timeout-ms <ms> | 10000 | Per-request network timeout. | | --offline | off | Never touch the network; every remote read becomes an incomplete check. | | --no-sample-tiles | sampling on | Check declared metadata only, without reading real tiles. | | --max-sample-tiles <count> | 3 | Tile addresses probed per source. | | --sample-at <lon,lat> | built-in anchors | Sample over a specific location, for a source the built-in anchors miss. | | --sampled-absence <severity> | info | Severity when only a partial sample says something is absent. broken is rejected. | | --canary <lon,lat,zoom[,id]> | — | Render a view with MapLibre GL in a headless browser. Repeatable. | | --canaries <path> | — | JSON file holding an array of canary definitions. | | --screenshot-dir <dir> | — | Where canary screenshots and diffs are written. | | --baseline-dir <dir> | — | Directory of <canary-id>.png baselines to compare against. | | --max-diff-ratio <ratio> | 0.005 | Fraction of differing pixels tolerated against a baseline. |

schema options

| Option | Default | What it does | | --------------------- | ------- | --------------------------------------------------------- | | -o, --output <path> | stdout | Write the report JSON Schema to a file instead of stdout. |

Exit codes

| Code | Meaning | | ---- | --------------------------------------------- | | 0 | Passed, or only findings below the threshold. | | 1 | Findings at or above the fail threshold. | | 2 | Invalid invocation, or a runtime error. |

An incomplete run never exits non-zero on its own. It reports what could not be verified rather than claiming a pass.

Severity means evidence strength

broken means an artifact was read and proves the mismatch. risky means the evidence points at a mismatch without closing it. info is weak evidence — a name a partial sample did not happen to supply. A check that could not run at all is reported as incomplete and never as a pass.

Two rules follow: a partial sample can never produce broken (even --sampled-absence refuses it), and a failed check is never a passed check. MapLibre overzooms, so a layer drawn above its source's maxzoom is normal and is never reported.

Related packages

• @maptiles-doctor/core — the engine, for programmatic use.
• @maptiles-doctor/report — HTML and SARIF renderers.

License

Apache-2.0
