msc-built-in-ai-embedding

<msc-built-in-ai-embedding /> is a web component based on Chrome Built-in AI Semantic Embedder API. Web developers could use <msc-built-in-ai-embedding /> to generate vector embeddings with EmbeddingGemma and provide vivid features like semantic search or text similarity comparison.

<msc-built-in-ai-embedding /> is a non-UI component. But it will provide current status in data-status. That means web developers have maximum creation to build UI through this information.

Basic Usage

<msc-built-in-ai-embedding /> is a web component. All we need to do is put the required script into your HTML document. Then follow <msc-built-in-ai-embedding />'s html structure and everything will be all set.

• Required Script

  <script
    type="module"
    src="https://unpkg.com/msc-built-in-ai-embedding/mjs/wc-msc-built-in-ai-embedding.js">
  </script>

• Structure

  Put <msc-built-in-ai-embedding /> into HTML document. It will have different functions and looks with attribute mutation.

  <msc-built-in-ai-embedding>
    <!-- style by yourself -->
    <button type="button">
      Try AI features
    </button>
  </msc-built-in-ai-embedding>

There will be serverial status to indicate Built-in AI status. Check msc-built-in-ai-embedding[data-status] out.

• available：AI ready to use.
• downloadable：Need to download LLM first (browser supported).
• downloading：LLM downloading (browser supported).
• unsupported：current browser doesn't support Built-in AI Semantic Embedder API.
• unavailable：current browser doesn't support Built-in AI Semantic Embedder API.

Once <msc-built-in-ai-embedding /> in status: downloading, <msc-built-in-ai-embedding /> will show download progress in attribute data-progress.

Such as:

<msc-built-in-ai-embedding
  data-status="downloading"
  data-progress="45"
>
  <button type="button">
    Try AI features
  </button>
</msc-built-in-ai-embedding>

JavaScript Instantiation

<msc-built-in-ai-embedding /> could also use JavaScript to create DOM element. Here comes some examples.

<script type="module">
import { MscBuiltInAiEmbedding } from 'https://unpkg.com/msc-built-in-ai-embedding/mjs/wc-msc-built-in-ai-embedding.js';

const buttonTemplate = document.querySelector('.my-button-template');

// use DOM api
const nodeA = document.createElement('msc-built-in-ai-embedding');
document.body.appendChild(nodeA);
nodeA.appendChild(buttonTemplate.content.cloneNode(true));

// new instance with Class
const nodeB = new MscBuiltInAiEmbedding();
document.body.appendChild(nodeB);
nodeB.appendChild(buttonTemplate.content.cloneNode(true));
</script>

Use <msc-built-in-ai-embedding />

<msc-built-in-ai-embedding /> provide same method as Chrome Built-in AI Semantic Embedder API. That means web developers need to create() embedder before embed().

• Embed a single string

<script type="module">
const ai = document.querySelector('msc-built-in-ai-embedding');

if (['unavailable', 'unsupported'].includes(ai.status)) {
  console.log('The current browser does not support the Built-in AI Semantic Embedder API.');
} else {
  try {
    await ai.create();
    const result = await ai.embed(
      "The quick brown fox jumps over the lazy dog.",
      { taskType: "semantic-similarity" }
    );
    ai.destroy();

    console.log(result);
  } catch(err) {
    console.log(err);
  }
}
</script>

• Embed a batch of strings

<script type="module">
const ai = document.querySelector('msc-built-in-ai-embedding');

if (['unavailable', 'unsupported'].includes(ai.status)) {
  console.log('The current browser does not support the Built-in AI Semantic Embedder API.');
} else {
  try {
    await ai.create();
    const result = await ai.embed(
      [
        "Built-in AI APIs use on-device models.",
        "Embeddings are high-dimensional vectors representing semantic meaning.",
      ],
      { taskType: "semantic-similarity" }
    );
    ai.destroy();

    console.log(result);
  } catch(err) {
    console.log(err);
  }
}
</script>

Property

| Property Name | Type | Description | | ----------- | ----------- | ----------- | | status | String | Getter current status. (available、downloadable、downloading、unsupported、unavailable) |

Mathods

| Mathod Signature | Description | | ----------- | ----------- | | create() | Create the embedder instance. | | embed(string = '' [, options = {}]) | Embed a single string or batch of strings. The embed function takes an optional parameter called taskType which allows you to optimize the embedding quality for specific use cases. | | destroy() | Destroy current embedder instance. |

※ Note: Except for destroy(), all the above methods are async.

Events

| Event Signature | Description | | ----------- | ----------- | | msc-built-in-ai-embedding-ready | Fired when LLM download done. | | msc-built-in-ai-embedding-download-progress | Fired when LLM downloading. Developers could gather result information through event.detail. |

Reference

• <msc-built-in-ai-embedding /> demo
• Built-in AI Semantic Embedder API
• YouTube tutorial
• WEBCOMPONENTS.ORG
