opentui-tape

Realtime financial visualisations for OpenTUI: candles, sparklines, depth ladders, option chains, and ticker tables — with sub-cell precision via opentui-glyphfit.

Status: 0.2.0-alpha — Phase 2.5 chrome pass shipped. Candle, Sparkline, DepthLadder, YAxis, XAxis, InfoBar, VolumePane, PatternAnnotated, plus a composite Chart Renderable and a 26-pattern classifier. Options, tables, and animations land across phases 3–4. See DESIGN.md.

Why

Existing terminal charting tools (asciichart, chartscii, tickrs) round bar geometry to whole cells. A candle whose high reaches 0.6 of a cell renders as a full block — same as one reaching 0.99.

opentui-tape uses glyphfit's analytically-derived ShapeVector data to map fractional row coverage to the right eighth-block, quadrant, or half-block:

high = 99.96, low = 99.91 (cells span $0.05 each)

            ┃                  ←  no ink (above high)
            ▆                  ←  high reaches 0.6 into this cell
            █                  ←  body fills entirely
            ▃                  ←  low extends 0.3 below
            ┃                  ←  no ink

The same precision applies to sparklines, depth bars, and (in upcoming phases) option-chain heatmaps.

Install

bun add opentui-tape

Peer deps: @opentui/core >= 0.2.0, opentui-glyphfit >= 0.5.0.

Quick start

The composite Chart Renderable wires the candle, axes, info bar, volume pane, and pattern annotation together with one constructor:

import { createCliRenderer } from "@opentui/core"
import { Chart } from "opentui-tape"

const renderer = await createCliRenderer({ exitOnCtrlC: true })
const chart = new Chart(renderer.root.ctx, {
  width: "100%", height: "100%",
  symbol: "DEMO",
  barInterval: 60_000,
})
renderer.root.add(chart)

stream.on("tick", t => chart.onTick(t))

For ad-hoc layouts (e.g. a candle paired with a depth ladder, or a multi-pane dashboard), instantiate the constituent Renderables directly — Chart is just opinionated wiring on top.

See demos/chart.ts (composite, minimal) and demos/desk.ts (manual composition + DepthLadder + theme cycle) for runnable examples (bun run demo:chart / bun run demo).

API

Renderables

new Chart(ctx, options)              // composite: candle + axes + info bar + volume + annotation
new Candle(ctx, options)             // streaming OHLC chart
new Sparkline(ctx, options)          // single-row mini chart
new DepthLadder(ctx, options)        // horizontal bid/ask bars per price level
new YAxis(ctx, options)              // right-aligned price labels + connector
new XAxis(ctx, options)              // single-row time/date labels
new InfoBar(ctx, options)            // symbol · last · change · H / L · volume
new VolumePane(ctx, options)         // column-aligned volume bars
new PatternAnnotated(ctx, options)   // single-row bias glyph overlay

Each accepts standard RenderableOptions (width/height/flex/etc.) plus a domain-specific options object. See src/renderables/*.ts for the full shape.

Pattern classifier

import { classify, classifyAll } from "opentui-tape/patterns"

// single-shot — match the trailing window
const matches = classify(bars)
//   ⇒ [{ name: "bullish-engulfing", confidence: 0.78, bullish: true }, ...]

// historical walk — every position with at least one hit
const hits = classifyAll(bars)
//   ⇒ [{ index: 17, matches: [...] }, ...]

26 named single-, two-, and three-bar patterns with multi-match output sorted by descending confidence. Tunable thresholds via ClassifyOptions.

Cell-math (pure)

For custom rendering, the underlying generators are exported:

import {
  candleCells, sparkCells,
  horizontalBarCells, depthLadderCells, volumePaneCells,
  yAxisTicks, xAxisTicks, renderXAxisRow,
  drawShapeCells, CANDLE, SPARK, DEPTH,
} from "opentui-tape"

const ops = candleCells(bars, scale, rect, theme)
drawShapeCells(buffer, ops, CANDLE)

Generators reuse a single CellOp per yield — zero per-cell allocation.

Charsets

import { CANDLE, SPARK, DEPTH } from "opentui-tape/charsets"

CANDLE and SPARK are subsets of glyphfit's BLOCKS shape data. DEPTH adds the left-eighth blocks (▏▎▍▌▋▊▉█) which glyphfit does not ship today — the shape data is declared inline.

Development

bun install
bun test               # 260+ tests (unit + visual snapshot + screenshot)
bun run typecheck
bun run build          # → dist/ (ESM + .d.ts), used by `prepublishOnly`
bun run demo           # synthetic candles + depth ladder + chrome
                       # hotkeys: q quit · t theme · i interval · r reset
                       #          +/- maxSize · p pause · s save PNG
bun run demo:chart     # minimal: composite Chart only

Visual snapshot tests

tests/visual/*.visual.test.ts render Candle / Sparkline into a real OpenTUI test buffer (via @opentui/core/testing's createTestRenderer) and snapshot the resulting character grid. Snapshots live in tests/visual/__snapshots__/ and serve as a regression net for geometry (cell placement, body/wick alignment, sub-cell precision) before any demo run. Update with bun test --update-snapshots after intentional visual changes.

Phase status

| Phase | Status | Includes | |---|---|---| | 1 | shipped | Candle, Sparkline, cell-math primitives, CANDLE / SPARK charsets | | 2 | shipped | DepthLadder + DEPTH charset, screenshot capture | | 2.5 | shipped | Pattern classifier (26 names), PatternAnnotated, YAxis, XAxis, InfoBar, VolumePane, composite Chart Renderable | | 2.6 | next | tape-store v0 (durable ring buffer), OrderBook composite, CANDLE_BOX charset variant | | 3 | planned | OptionChain, Heatmap, Greeks display | | 4 | planned | TickerTable, Shimmer, Drawer, AXIS charset, React bindings | | 5 | planned | Themes, devtools overlay, starter template |

See DESIGN.md for the full design and rationale.

License

MIT — see LICENSE.
