Photon Grid for React — React Data Grid & Data Table Component

Overview

Photon Grid for React (photon-grid-react) is the official React wrapper for Photon Grid Core — a framework-agnostic data grid / data table engine written in TypeScript with zero runtime dependencies.

One <PhotonGrid /> component binds React props and callbacks to the core engine: virtual scrolling, sorting, filtering, grouping, editing, and cell renderers written as ordinary React components.

A modern, lightweight alternative to AG Grid, TanStack Table, MUI DataGrid and react-data-grid.

Installation

npm install photon-grid-react

yarn add photon-grid-react

pnpm add photon-grid-react

photon-grid-core is a regular dependency and is installed for you. react and react-dom (≥18) are peer dependencies you already have.

No CSS import is required: the core injects its own stylesheet on first render.

Quick start

import { useCallback } from 'react';
import { PhotonGrid } from 'photon-grid-react';
import type { PhotonGridColumnDef } from 'photon-grid-react';
import type { GridApi, GridOptions } from 'photon-grid-core';

// Only `field` is required — colId, header and type are defaulted for you.
const columns: PhotonGridColumnDef[] = [
  { field: 'sku',      header: 'SKU',      width: 110, pinned: 'left' },
  { field: 'product',  header: 'Product',  width: 190 },
  { field: 'category', header: 'Category', width: 140 },
  { field: 'price',    header: 'Price',    width: 120, type: 'number', editable: true },
  { field: 'released', header: 'Released', width: 130, type: 'date' },
];

const rows = [
  { sku: 'PG-1001', product: 'Photon Keyboard', category: 'Hardware', price: 1249, released: '2024-01-18' },
  { sku: 'PG-1002', product: 'Quantum Mouse',   category: 'Hardware', price:  349, released: '2024-02-04' },
  { sku: 'PG-1003', product: 'Nebula Dock',     category: 'Hardware', price: 2199, released: '2024-02-22' },
];

// Declared outside the component (or memoized): a new `options` identity
// recreates the grid.
const options: Partial<GridOptions> = {
  mode: 'light',
  rowHeight: 40,
  showSerialNumber: true,
  pagination: { enabled: true, pageSize: 10 },
  editing: { mode: 'cell' },
};

export function Products() {
  const onGridReady = useCallback((api: GridApi) => {
    api.sizeColumnsToFit();
  }, []);

  return (
    // The grid fills its host, so give the host a height.
    <div style={{ height: 460 }}>
      <PhotonGrid
        columns={columns}
        dataSet={rows}
        options={options}
        onGridReady={onGridReady}
        onCellValueChanged={(e) => console.log('cell changed', e)}
      />
    </div>
  );
}

Props

| Prop | Type | Description | | --------- | --------------------------- | ----------- | | columns | PhotonGridColumnDef[] | Column definitions. Renderer slots accept React components as well as plain functions. | | dataSet | Record<string, unknown>[] | Row data. | | options | Partial<GridOptions> | Everything else — theme, selection, editing, pagination, row model, master/detail, AI panel. A new object identity recreates the grid, so memoize it. | | loading | boolean | Toggles the loading overlay through GridApi.setLoading, so scroll position, selection and column layout survive. Configure its look with options.loadingOverlay. |

Event callbacks

onGridReady receives the GridApi, which is full programmatic control over the grid.

| Group | Callbacks | | --- | --- | | Lifecycle | onGridReady, onDataChanged, onLoadingChanged | | Rows | onRowClicked, onRowDoubleClicked, onRowSelected | | Cells | onCellClicked, onCellDoubleClicked, onCellValueChanged, onCellSelectionChanged | | Columns | onColumnResized, onColumnMoved, onColumnsStateChanged | | Data ops | onSortChanged, onFilterChanged, onPageChanged | | Misc | onThemeChanged, onExportComplete |

React cell renderers

Renderer slots accept React components directly — the wrapper mounts and unmounts them as rows are virtualized and recycled. The renderer params arrive as props (value, row, rowIndex, colDef, colIndex, api):

const StatusBadge = ({ value }: Record<string, unknown>) => (
  <span className="badge">{String(value)}</span>
);

const columns: PhotonGridColumnDef[] = [
  { field: 'status', header: 'Status', renderer: { display: StatusBadge } },
];

Pass { kind: 'component', component, props } instead when you want to map the params to a narrower prop type of your own.

Master–detail panels work the same way:

const OrderDetail = ({ data, ctx }) => (
  <button onClick={() => ctx.emit('save', data)}>Save {data.account}</button>
);

<PhotonGrid options={{ masterDetail: { enabled: true, renderer: OrderDetail } }} />

Features

• Virtual row and column rendering — millions of rows, thousands of columns
• React components as cell, header, editor and master–detail renderers
• Column pinning, resizing, reordering, auto-size, size-to-fit, column groups
• Sorting, multi-column sorting, filtering, quick filter, filter panels
• Row grouping with aggregations, tree data, master–detail rows
• Client, server-side and infinite row models
• 15+ cell editors, declarative and async validation, fill handle, clipboard, undo/redo
• Excel-style formula engine (=A1+B1) with 55+ functions
• Light/dark modes and five variants, all CSS-custom-property driven
• CSV / Excel export and import, summary rows, status bar, context menus, charts
• Full keyboard navigation, ARIA roles, screen-reader support, RTL
• Natural-language AI panel (optional, with a Gemini back-end)

Links

• GitHub — https://github.com/abdulwahid-csit/photon-grid
• Issues — https://github.com/abdulwahid-csit/photon-grid/issues
• Core engine — https://www.npmjs.com/package/photon-grid-core
• Angular wrapper — https://www.npmjs.com/package/photon-grid-angular
• Vue wrapper — https://www.npmjs.com/package/photon-grid-vue

Keywords

react, react grid, react data grid, react table, react data table, react datatable, react table component, reacttable, tanstack table alternative, ag-grid react alternative, mui datagrid alternative, react-data-grid alternative, grid, data grid, datagrid, table, data table, datatable, table data, spreadsheet, excel grid, editable table, virtual scroll, virtualized table, infinite scroll, large dataset, million rows, tree grid, row grouping, sorting, filtering, pagination, column pinning, column resize, column reorder, row selection, cell selection, csv export, excel export, enterprise data grid, typescript, hooks

License

MIT © Abdul Wahid

⭐ If Photon Grid is useful to you, consider starring the repository.
