Requirements

• Node.js v18 or higher
• Docker — required for plum server start (the web UI stack). Runner nodes (plum node start) run as a plain Node process and do not need Docker.

1. Installation

Install Plum globally

npm install -g plum-e2e

The -g flag is required. Plum is a CLI tool — it must be installed globally to use plum commands anywhere on your machine.

Initialize a new project

Create a folder for your tests and run plum init inside it:

mkdir my-tests
cd my-tests
plum init

This sets up your project with a working test scaffold:

my-tests/
├── tests/
│   ├── features/          — Gherkin .feature files (your test cases)
│   ├── step_definitions/  — TypeScript step implementations
│   ├── pages/             — Page Object Models
│   └── utils/             — Browser setup, hooks, shared helpers
├── .env                   — Base URL and browser settings
├── .gitignore             — Pre-configured to exclude .env and reports/
├── plum.plugins.json      — Add extra npm packages for your tests
└── tsconfig.json          — IDE type resolution (no local install needed)

The tests/ folder includes working example tests against SauceDemo so you can run something immediately.

Configure your target URL

Open .env and set your application's URL:

BASE_URL=https://your-app.com
IS_HEADLESS=false

| Variable | Description | | ------------- | ---------------------------------------------------- | | BASE_URL | The URL Playwright opens at the start of tests | | IS_HEADLESS | true to run headlessly, false to see the browser |

Add extra packages (optional)

If your tests need additional npm packages, add them to plum.plugins.json:

{
	"dependencies": {
		"@faker-js/faker": "^9.0.0"
	}
}

Plum installs these automatically before each run. Commit this file so your whole team uses the same packages.

2. Starting the Server

Plum includes a full web UI for triggering tests, viewing reports, and scheduling runs.

Start

plum server start

or the shorthand:

plum start

The first time you run it, Plum asks a few questions (press Enter to accept the default shown in parentheses):

| Prompt | Default | What it sets | | ---------------------- | ------------------------- | ----------------------------------------------------------------------- | | App URL (BASE_URL) | from your .env | The URL Playwright opens at the start of every test | | Headless? | No | Whether browsers run hidden | | Backend port | 3001 | Host port for the API | | Frontend (UI) port | 5173 | Host port for the web UI | | Primary public URL | http://<your-ip>:<port> | The address you give runner nodes (see Runner Setup) |

Your answers are saved to .plum-server.json, so the next plum server start reuses them without asking.

First-user setup

On the very first start, Plum detects that no user accounts exist and prompts you to create one:

No users found — create your first account to get started.
✔ Your name … Jane Smith
✔ Email address … [email protected]
✔ Password …
✓ Account created for [email protected]. You can now log in.

After that, open the UI at the frontend port it prints (default http://localhost:5173) and sign in. Additional users can be invited from Settings → Account or the Settings → Users page.

If you skip the CLI prompt, visit http://localhost:5173/setup in your browser to create the first account.

Docker must be running before you use this command. Plum builds and starts the backend, database, and UI automatically.

Skip the prompts by passing flags (handy for CI):

plum server start --base-url https://your-app.com --headless true --backend-port 3001 --frontend-port 5173

Change settings later

plum server reconfig

Re-asks every question and saves your answers without starting the stack. Run plum server start afterwards to apply them.

Stop

plum server stop

or the shorthand:

plum stop

Your data (reports, schedules, settings) is preserved in the database volume. Only the running containers are stopped.

3. Writing Tests

Plum uses Cucumber and Gherkin to write human-readable test cases.

Cucumber Basics

Gherkin is a plain-English language for writing test scenarios. Each test lives in a .feature file and follows this structure:

@suite-login
Feature: Login

  @test-login-1
  Scenario: User can log in with valid credentials
    Given I am on the login page
    When I enter valid credentials
    Then I should see the dashboard

Key concepts:

| Term | What it is | | ------------------ | ---------------------------------------------------------------------- | | Feature | A group of related scenarios (one per file) | | Scenario | A single test case | | Given | Sets up the initial state | | When | Performs an action | | Then | Asserts the expected outcome | | Background | Steps that run before every scenario in a file | | Scenario Outline | A parameterized scenario that runs once per row in an Examples table | | @tag | A label used to run specific tests or suites |

Useful links:

• Gherkin syntax reference
• Cucumber step definitions
• Playwright documentation

Project Structure

Tests follow a three-layer structure: Feature → Step Definition → Page Object.

Feature File — what to test

# tests/features/Login.feature

@suite-login
Feature: Login

  @test-login-1
  Scenario: User can log in with valid credentials
    Given I am on the login page
    When I enter valid credentials
    Then I should see the dashboard

Tags (@suite-login, @test-login-1) let you run specific tests or entire suites. Every suite and scenario should have its own tag.

Page Object — how to interact with the page

// tests/pages/LoginPage.ts

import { page } from '../utils/browser';

export class LoginPage {
	static async goToLoginPage() {
		await page().goto(process.env.BASE_URL as string);
	}

	static async enterCredentials(username: string, password: string) {
		await page().fill('#username', username);
		await page().fill('#password', password);
		await page().click('button[type="submit"]');
	}

	static async verifyDashboardVisible() {
		await page().waitForSelector('#dashboard');
	}
}

Methods are static and use the page() helper from utils/browser.ts — you never pass a page instance around.

Step Definition — connects Gherkin to code

// tests/step_definitions/LoginSteps.ts

import { Given, When, Then } from '@cucumber/cucumber';
import { LoginPage } from '../pages/LoginPage';

Given('I am on the login page', async () => {
	await LoginPage.goToLoginPage();
});

When('I enter valid credentials', async () => {
	await LoginPage.enterCredentials('[email protected]', 'password123');
});

Then('I should see the dashboard', async () => {
	await LoginPage.verifyDashboardVisible();
});

Generate a Step

Use plum create-step to interactively scaffold a new step definition and page object method:

plum create-step

Follow the prompts — Plum writes the boilerplate, you fill in the implementation.

Run Tests Locally

Use plum run-test to run tests directly on your machine without Docker:

plum run-test                            # run all tests
plum run-test @test-login-1              # run a single scenario
plum run-test @suite-login               # run an entire suite
plum run-test --parallel 4               # run all tests across 4 workers
plum run-test --parallel 4 @suite-login  # run a suite in parallel
plum run-test --browser firefox          # run in a specific browser

| Flag | Description | | ------------------ | --------------------------------- | | @tag | Run only tests matching the tag | | --parallel <n> | Run across n parallel workers | | --browser <name> | chromium (default) or firefox |

plum run-test syncs your tests, installs dependencies, and runs Cucumber. No Docker needed.

4. Test Repository

Plum includes a built-in test case management system accessible from the Test Repository tab in the UI.

Test Suites and Cases

Organise test cases into suites. Each suite and case gets an auto-assigned ID (e.g. TS-001, TC-001). The prefix is configurable in Settings → Repository.

Each test case has:

• Title and Description
• Priority — Critical, High, Medium, or Low
• Test Steps — an ordered table with columns: Action, Test Data, Expected Output
• Automated tag — a Cucumber @tag name that links this case to an automated scenario (e.g. test-login-1)
• History — a timeline of every result, from manual test runs and automated builds

Linking automated tests

Set the Automated tag on a test case to match a Cucumber @tag in your feature files. After every automated run, Plum scans the results and:

1. Marks matching cases as automated
2. Records a pass/fail entry in the case's history

@test-login-1
Scenario: User can log in with valid credentials

If TC-042 has automatedTag = test-login-1, it will be marked automated and updated after each build — no manual linking required.

Test Runs

Create a Test Run (e.g. "Sprint 12 regression") and drag test cases from the suite browser into the run. Then switch to Execute mode to step through each case and mark it pass / fail / blocked / skip.

Results are recorded in the case's history and the run's progress bar updates in real time.

Migrating IDs

If you change the test ID prefix (e.g. from TC to CASE), use Settings → Repository → Run Migration to rename all existing IDs at once. Cucumber tags in your code are intentionally left unchanged — update those separately.

5. Runner Setup

Runners are additional machines that execute tests in parallel alongside the primary server, letting you distribute a large suite across many nodes. A node runs as a plain Node process — no Docker required.

Each node automatically installs Chromium and Firefox — no browser selection needed. When triggering a test run from the UI, you choose which browser to use at run time.

Start a runner node

On the machine that will act as a runner, navigate to your Plum project and run:

plum node start

Plum asks a few questions, registers the node with your server automatically, starts it in the background, then opens the runner management menu:

| Prompt | Default | What it sets | | ------------------ | ------------------------- | -------------------------------------------------------------------- | | Primary URL | last used | The server this node registers with (e.g. http://192.168.1.5:3001) | | Local port | 3001 | The port this node process listens on | | Advertised URL | http://<your-ip>:<port> | The address the server uses to reach this node | | Runner name | node-<random> | The name shown in the UI | | Auth token | auto-generated | Shared secret; press Enter to keep the generated one |

The node starts as a background daemon — your terminal is free immediately. Logs go to backend/logs/runner-<id>.log. Settings are saved to .plum-node.json, so re-running reuses them and never creates a duplicate.

After setup, the runner management menu opens automatically. From there you can start, stop, restart, and ping any runner registered on the primary. Exit the menu any time — the node keeps running.

Skip the prompts with flags (handy for CI or scripted nodes):

plum node start --primary http://192.168.1.5:3001 --port 3001 --name ci-node-1

| Flag | Description | | ------------------ | ---------------------------------------------------------------------------------------- | | --primary <url> | Server to auto-register with. Omit to only print the details for manual entry. | | --url <url> | Address the server calls back. Defaults to <lan-ip>:<port>; pass a domain to override. | | --port <n> | Local HTTP port the node listens on (default 3001). | | --token <secret> | Auth token. Auto-generated and saved if omitted. | | --name <name> | Runner name shown in the UI. |

Nodes behind a domain or reverse proxy

--url is the address the server calls back and is used exactly as given, while --port is the local port the node listens on. So a node behind an HTTPS reverse proxy is:

plum node start --primary https://plum.example.com --url https://node1.example.com --port 3001

The server reaches the node at https://node1.example.com; the proxy forwards to the node on port 3001. The advertised --url must be reachable from the server.

Manage runners

plum manage-runners

Opens the interactive runner management menu at any time (reads the primary URL from your saved node config). You can also pass a different server:

plum manage-runners --primary http://192.168.1.5:3001

In development, the equivalent command is npm run manage-runners from the backend/ directory.

Change settings later

plum node reconfig

Re-asks every question, re-registers with the primary, and prints the updated card — without starting the node. Run plum node start afterwards to launch it.

Register manually (fallback)

If you run plum node start without a reachable --primary, Plum prints the node's name, url, and token instead. Add it by hand:

1. Open the Plum UI at http://localhost:5173
2. Go to Settings → Runners
3. Click Add Runner and paste the node's URL, token, and name

Stop a runner node

plum node stop

Stops the node started from the current folder. You can also stop individual runners from the plum manage-runners menu.

Command Reference

| Command | Description | | ----------------------------- | ------------------------------------------------------------------------------ | | plum init | Initialize a new project in the current folder | | plum server start | Start the full UI stack via Docker, interactively (alias: plum start) | | plum server reconfig | Re-enter server settings (URL, ports) without starting | | plum server stop | Stop the server and preserve data (alias: plum stop) | | plum run-test | Run all tests locally without Docker | | plum run-test @tag | Run tests matching a tag | | plum run-test --parallel N | Run tests across N parallel workers | | plum run-test --browser <b> | Run in a specific browser (chromium or firefox) | | plum create-step | Interactively scaffold a new step definition | | plum node start | Configure, register, and start a runner node; opens the runner management menu | | plum node reconfig | Re-enter node settings + re-register, without starting | | plum node stop | Stop the runner node started from this folder | | plum manage-runners | Open the interactive runner management menu |

Development

This section is for contributors developing Plum itself. If you're a user, the sections above are all you need.

Clone and install

git clone https://github.com/silverlunah/plum.git
cd plum
npm run init

npm run init installs all dependencies across the monorepo (root, backend, and frontend) in one command.

Start the stack

npm run docker:up    # build and start all services (detached)
npm run docker:down  # stop all services

The UI will be available at http://localhost:5173 after docker:up completes.

After any backend dependency or schema change, re-run npm run docker:up to rebuild the containers.

Backend — writing and running tests

All test development happens inside the backend/ directory, where the Playwright + Cucumber runner lives:

cd backend

Run tests:

npm test                     # run all tests
npm test -- @test-1          # run a specific scenario by tag
npm test -- @suite-login     # run an entire suite
npm test -- --parallel 4     # run all tests in parallel

Generate a step definition:

npm run create-step

Interactive prompt that creates a new step and its page object method.

Scaffold a new test:

npm run create-test

Interactive prompt that creates a new .feature file, page object, and step definition file from a template — ready for you to implement.

Manage runner nodes:

npm run manage-runners

One interactive menu to add a new runner (registers it with the primary and optionally starts it), and to start / stop / restart / ping the local node processes it manages. In dev the primary runs in Docker and nodes run as bare host processes, reached via host.docker.internal. PIDs are tracked in .runners.local.json and logs go to backend/logs/ so you can manage nodes across terminal sessions.

Test file locations

backend/tests/
  features/          — Gherkin .feature files
  step_definitions/  — TypeScript step implementations
  pages/             — Page Object Models
  utils/             — Browser setup, hooks, helpers

Frontend

The frontend dev server runs outside Docker for fast hot module replacement:

cd frontend
npm run dev

Available at http://localhost:5173. The backend (via Docker) serves API requests at http://localhost:3001.
