RAMLParserTS

Parse RAML 1.0 and OpenAPI 3.x specifications into structured data — in the browser, with no backend and no Node runtime.

Extracted data includes API info, endpoints, parameters, responses, security schemes, and functional/non-functional requirements from description tables.

Status: early development. See DESIGN.md for the agreed design and PARITY.md for differences from the Swift original.

Features

• Parses RAML 1.0 and OpenAPI 3.0/3.1 specifications
• Resolves !include directives (RAML, YAML, JSON, plain text) from a folder/zip dropped into the page
• Expands RAML traits, resource types, and uses: libraries; resolves OpenAPI $refs
• Extracts endpoints, parameters, responses, and security schemes
• Extracts functional and non-functional requirements from description tables
• Lints documentation omissions (missing descriptions, examples, acceptance criteria) with per-rule configuration and file:line attribution
• Runs 100% client-side: suitable for static web pages (ESM + IIFE builds)

Supported formats

| Format | Support | | ----------- | ------------------------------ | | RAML 1.0 | ✅ | | OpenAPI 3.x | ✅ | | RAML 0.8 | ❌ rejected with a clear error | | Swagger 2.0 | ❌ rejected with a clear error |

Installation

npm install raml-parser-ts

Or use the IIFE build from a plain <script> tag:

<script src="dist/raml-parser-ts.global.js"></script>
<script>
  // global: RAMLParser
</script>

Usage

import {
  discoverRoots,
  lintSpec,
  loadZip,
  parseFiles,
  parseSpec,
} from "raml-parser-ts";

// One-shot from dropped files (zip or folder):
const spec = await parseFiles(event.dataTransfer.files);
console.log(spec.apiInfo.title, spec.endpoints.length);

// Or step by step (e.g. to show a root picker):
const vfs = loadZip(new Uint8Array(await file.arrayBuffer()));
const roots = discoverRoots(vfs); // valid root candidates only
const spec2 = parseSpec(vfs, roots[0]); // resolve + extract

// Documentation-omission lint (DESIGN.md §18):
const { findings } = lintSpec(spec2); // per-rule enable/severity via options

spec is a plain JSON-serialisable ParsedSpec — apiInfo, endpoints, requirements, diagnostics. Non-fatal problems arrive as diagnostics; fatal ones throw RamlParseError. Every entity carries source { file, line } provenance pointing at its own key, and lint findings do the same. See DESIGN.md §9–§10 for the model and docs/requirement-tables.md for the FR/NFR extraction grammar.

Quick tour

The gif above is a real recording of the bundled viewer. To reproduce it:

1. npm install && npm run build:ui — builds viewer/dist/index.html, one self-contained file.
2. Open viewer/dist/index.html in a browser (from disk — no server needed).
3. Drop examples/demo-inventory-api-1.0.0-raml.zip onto the page — a synthetic MuleSoft-style export, all content invented.
4. Pick demo-inventory-api.raml in the root picker (the zip also holds a tiny OpenAPI root so the picker appears).
5. Browse Endpoints (params, bodies, examples, security), Requirements (FR/NFR tables with scope and file:line provenance), Diagnostics and Raw.
6. Export endpoints.md / requirements.md, or print the page.

The demo zip is regenerated from examples/demo/ with npm run demo:zip; the gif is re-recorded with npm run demo:gif (Playwright recording + ffmpeg).

Viewer

A single-file Svelte viewer for browsing a dropped spec (folder or zip), with markdown exports and print styles. The built page runs from disk, offline, with no backend — nothing leaves your machine.

Views: Endpoints (with inline lint badges and an "only endpoints with findings" filter), Requirements, Lint (documentation omissions grouped by severity, each with target and file:line), Diagnostics, Raw. Exports: endpoints.md, requirements.md, lint.md, plus print styles.

npm run dev:ui     # develop with hot reload
npm run build:ui   # write viewer/dist/index.html (self-contained)
npm run check:ui   # build + Playwright drop-to-render smoke

Development

npm install
npm run check   # typecheck + lint + tests + build

See CONTRIBUTING.md. No CI is configured — run npm run check before pushing. The Playwright smoke (npm run check:ui) needs npx playwright install chromium once first.

Credits

Ported from RAMLParserKit by Richard Dyce (MIT, Swift).

License

MIT — see LICENSE.
