Toucan Payments MCP Server

The official Model Context Protocol (MCP) server for Toucan Payments. Connect AI assistants—including Claude Desktop, Cursor, VS Code, Windsurf, and custom LLM agents—directly to Toucan Payments online payment gateway APIs using secure Bearer authentication tokens.

Inspired by industry-standard implementations such as the Pine Labs Online MCP Server, this server provides a production-grade, highly observable, and container-ready bridge between generative AI models and payment infrastructure.

Architecture & Hosting

The Toucan Payments MCP Server provides dual runtime modes designed to serve both local AI paired-programming tools and centralized cloud infrastructure:

flowchart TD
    subgraph AI Assistants & Clients
        Claude[Claude Desktop]
        Cursor[Cursor IDE]
        VSCode[VS Code / Copilot]
        Agent[Autonomous LLM Agent]
    end

    subgraph Toucan Payments MCP Server
        CLI[toucan-mcp CLI / Stdio Transport]
        SSE[SSE / Streamable HTTP Server :8000]
        Router[Tool Registry & Security Validator]
        PromExporter[Prometheus Metrics Exporter :9090 / :8000/metrics]
        TraceEngine[Langfuse & LangSmith Tracer]
    end

    subgraph Observability
        Prom[Prometheus Server]
        Graf[Grafana Dashboard :3000]
        LF[Langfuse Cloud / Self-Hosted]
        LS[LangSmith Cloud]
    end

    subgraph Toucan Payments Gateway
        PayLinkAPI["POST /api/paylink/cre (Merchant API - PDF 1)"]
        CheckStatusAPI["POST /api/pay/v1/checkStatus (Pay API - PDF 2)"]
        CheckoutAPI["POST /api/auth/getpaymentsession (Checkout API - PDF 3)"]
        CallbackEngine["Payment Callbacks / Webhooks"]
    end

    Claude -->|Stdio JSON-RPC| CLI
    Cursor -->|Stdio JSON-RPC| CLI
    VSCode -->|Stdio JSON-RPC| CLI
    Agent -->|SSE / HTTP| SSE

    CLI --> Router
    SSE --> Router

    Router --> PromExporter
    Router --> TraceEngine
    PromExporter --> Prom
    Prom --> Graf
    TraceEngine --> LF
    TraceEngine --> LS

    Router -->|Bearer Auth / HTTPS| PayLinkAPI
    Router -->|Bearer Auth / HTTPS| CheckStatusAPI
    Router -->|Form URL / HTTPS| CheckoutAPI
    CallbackEngine -.->|Validate| Router

Hosting Modes

Local Stdio Mode (Default): Executed as a child process by Claude Desktop, Cursor, or VS Code over stdin/stdout. A background daemon exposes Prometheus metrics on port 9090.
Internal Server Mode (SSE / Streamable HTTP): Hosted on internal infrastructure or Kubernetes behind reverse proxies (Nginx/ALB). Exposes /sse and /messages for MCP streaming, /health for container probes, and /metrics for Prometheus scraping on port 8000.

Prerequisites

Python 3.10+ or Astral uv (recommended for zero-overhead virtual environments).
Node.js 18+ (optional, only if launching via npx toucan-payments-mcp).
Docker & Docker Compose (optional, for full containerized deployment).
Toucan Payments Credentials: Bearer access token, merchant number, and terminal credentials provisioned by the Toucan Payments acquiring team.

Packaging & Distribution

The server is packaged for universal distribution across three primary mediums:

Python Package Index (PyPI):

pip install toucan-payments-mcp
# Or using uv:
uv tool install toucan-payments-mcp

Node Package Manager (NPM / npx): Execute directly without manual repository cloning:
```
npx -y toucan-payments-mcp start
```

Docker Hub / Container Image:

docker build -t toucan-payments-mcp:latest .

Quick Start

1. Clone & Setup Virtual Environment

git clone https://github.com/toucan-payments/toucan-payments-mcp.git
cd toucan-payments-mcp

# Using Astral uv (recommended):
uv venv --python 3.12
uv pip install -e ".[tracing,dev]"

# Or using standard python venv:
python -m venv .venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate
pip install -r requirements.txt
pip install -e .

2. Configure Credentials

Run the interactive configuration CLI:

toucan-mcp configure

Or create a .env file from the provided template:

cp .env.example .env

Fill in your credentials:

TOUCAN_ENV=uat
TOUCAN_ACCESS_TOKEN=eyJhbGciOiJSUzI1NiJ9...
TOUCAN_MERCHANT_NUMBER=479487461200974
TOUCAN_TERMINAL_NUMBER=81457699

3. Verify Connection

toucan-mcp test

4. Auto-Configure AI Assistant

toucan-mcp setup cursor        # For Cursor IDE
toucan-mcp setup claude-desktop # For Claude Desktop
toucan-mcp setup vscode        # For Visual Studio Code
toucan-mcp setup windsurf      # For Windsurf

CLI Commands Reference

The toucan-mcp CLI mirrors the command suite of modern enterprise MCP servers:

| Command | Description | |:---|:---| | toucan-mcp start | Launch the server in stdio transport mode (default) | | toucan-mcp start --transport sse --port 8000 | Launch server in HTTP / SSE mode for internal hosting | | toucan-mcp configure | Interactively configure Bearer token and merchant defaults | | toucan-mcp test | Test network latency and credentials against Toucan gateway | | toucan-mcp setup <client> | Automatically configure AI client (cursor, claude-desktop, vscode, windsurf) | | toucan-mcp setup <client> --print | Print MCP client JSON configuration snippet without writing | | toucan-mcp status | Print active configuration, environment mode, and telemetry status | | toucan-mcp --version | Display current package version |

Supported AI Clients

1. Cursor IDE

Configuration file location: ~/.cursor/mcp.json

{
  "mcpServers": {
    "toucan-payments": {
      "command": "toucan-mcp",
      "args": ["start", "--transport", "stdio"],
      "env": {
        "TOUCAN_ENV": "uat",
        "TOUCAN_ACCESS_TOKEN": "YOUR_BEARER_TOKEN",
        "TOUCAN_MERCHANT_NUMBER": "479487461200974",
        "TOUCAN_TERMINAL_NUMBER": "81457699"
      }
    }
  }
}

2. Claude Desktop

Configuration file locations:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json
Windows: %APPDATA%\Claude\claude_desktop_config.json

{
  "mcpServers": {
    "toucan-payments": {
      "command": "toucan-mcp",
      "args": ["start"],
      "env": {
        "TOUCAN_ENV": "uat",
        "TOUCAN_ACCESS_TOKEN": "YOUR_BEARER_TOKEN"
      }
    }
  }
}

3. Visual Studio Code

Configuration file location: .vscode/mcp.json

{
  "servers": {
    "toucan-payments": {
      "command": "toucan-mcp",
      "args": ["start"],
      "env": {
        "TOUCAN_ENV": "uat",
        "TOUCAN_ACCESS_TOKEN": "YOUR_BEARER_TOKEN"
      }
    }
  }
}

Available Tools Specification

In alignment with the architect's instructions, the initial release focuses on core payment capabilities:

1. `create_payment_link` (Write Operation)

Generates a payment link matching the Toucan Payments Create Pay Link API specification (1.pdf).

Endpoint: POST /api/paylink/cre
Supported Options: Fixed amount, customer-entered amount, single-use, reusable, partial payments, customizable ISO-8601 expiry timestamps.
Parameters:
- amount (Optional[float | str]): Payment amount. If omitted, customer enters amount at payment time.
- currency (str, default "INR"): ISO-4217 currency code.
- description (str, default "purchase"): Transaction description displayed to customer.
- one_time_use (bool, default True): Link expires immediately upon first successful payment.
- allow_partial (bool, default False): Allows customer to pay partial instalments.
- expiry_hours (int, default 24): Hours before link expiration.
- expiry_date (Optional[str]): Explicit ISO timestamp (e.g. 2026-05-01T23:59:59).
- merchant_number, terminal_number, terminal_model_key, merchant_model_key, merchant_name: Optional overrides for terminal routing.

2. `check_payment_status` (Read Operation)

Queries the real-time processing status of a payment matching the Toucan Payments Check Status API specification (2.pdf).

Endpoint: POST /api/pay/v1/checkStatus
Parameters:
- invoice_number (str, required): Unique transaction invoice number or orderNo (minimum 15 digits, e.g. 176129831762956).
- rrn (Optional[str]): Optional Retrieval Reference Number (RRN) from bank transaction.
- terminal_number (Optional[str]): Terminal number associated with the transaction (defaults to configured terminal).
- merchant_number (Optional[str]): Merchant account number (defaults to configured merchant).
Output: Returns approval status (actionCode: "00" signifies success), approval code, RRN, settled amounts, customer masked VPA, and timestamps.

3. `verify_payment_callback` (Verification Operation)

Validates and parses asynchronous webhook/callback payloads from Toucan Payments (2.pdf pages 6–7).

Parameters:
- callback_payload (Union[str, dict], required): Raw JSON payload received on webhook endpoint.
- expected_terminal_number (Optional[str]): Expected terminal number.
- expected_invoice_number (Optional[str]): Expected invoice number.
Validation Rules:
- Verifies pspRefNo format: ensures it matches the combination terminalNumber + invoiceNumber.
- Confirms payeeRespCode == "00" and status == "SUCCESS".
- Returns formatted verification breakdown and standard Toucan acknowledgment response ({"success": true}).

4. `check_gateway_health` (Read Operation)

Diagnoses end-to-end connectivity between the MCP server and Toucan Payments endpoints.

Validates active environment URLs, Bearer token presence, round-trip HTTP latency, and Prometheus exporter status.

5. `create_checkout_session` / `get_payment_session` (Checkout Operation - PDF 3)

Initiates a web checkout session matching the Toucan Payments Check Out-API specification (3.pdf).

Endpoint: POST /api/auth/getpaymentsession
Request Format: Content-Type: application/x-www-form-urlencoded
Parameters:
- order_id (str, required): Unique transaction invoice number or order ID (minimum 15 digits, e.g. 12022025173230443). Form key: o.
- amount (Union[float, int, str], required): Transaction monetary amount to charge (e.g. 23). Form key: ta.
- customer_name (str, required): Sender / customer full name (e.g. srikanth). Form key: name.
- customer_phone (str, required): Sender / customer mobile phone number (e.g. 8745696254). Form key: phone.
- customer_email (str, required): Sender / customer email address (e.g. [email protected]). Form key: emailId.
- currency (str, default "INR"): ISO-4217 currency code. Form key: c.
- terminal_id (Optional[str]): Mapped terminal ID (defaults to configured TOUCAN_TERMINAL_NUMBER or 45789944). Form key: t.
- merchant_token (Optional[str]): Merchant designated JWT authorization token (defaults to configured TOUCAN_ACCESS_TOKEN). Form key: mac.
- merchant_url (Optional[str]): Merchant environment URL (defaults to configured merchant base URL). Form key: murl.
- hash_amount (Optional[str]): SHA-512 hexadecimal hash of transaction amount ta (computeSHA512(str(ta))). Automatically computed if omitted! Form key: ha.
Response Behavior:
- Extracts the checkout navigation URL from the HTTP Location response header (HTTP 302 Found) or JSON response body ({"Location": "..."}).
- Navigates the customer to the checkout page or displays it in a mobile WebView. Subsequent payment flows (UPI, Card, NetBanking) are handled within the checkout interface.
Error Codes (from PDF 3):
- 302: Redirect URL returned in Location header (or failure URL if terminal or parameters are invalid).
- 200: Request successful but redirect URL was not sent from backend.
- 404: Given Merchant token is not authorized to access the API.

Observability & Monitoring

Enterprise-grade observability is built directly into the server core.

Prometheus Metrics Exporter

When running in SSE / HTTP Mode (--transport sse): Metrics are served at http://<host>:8000/metrics.
When running in Stdio Mode (--transport stdio): A lightweight background daemon automatically serves Prometheus metrics at http://localhost:9090/metrics.

Exported Metrics:

| Metric Name | Type | Labels | Description | |:---|:---|:---|:---| | toucan_mcp_tool_calls_total | Counter | tool_name, status | Total MCP tool invocations | | toucan_mcp_tool_duration_seconds | Histogram | tool_name | Latency distribution of tool calls | | toucan_api_requests_total | Counter | endpoint, method, http_status | Outbound HTTP calls to Toucan gateway | | toucan_api_duration_seconds | Histogram | endpoint | Outbound HTTP round-trip latency | | toucan_mcp_active_sessions | Gauge | — | Active client connections |

Grafana Dashboards

A ready-to-use Grafana dashboard is located in grafana/dashboards/toucan_mcp.json. When running with Docker Compose, Grafana automatically provisions:

Tool execution rates (QPS)
Tool success vs error breakdown (pie chart)
95th percentile tool execution latency
Outbound API round-trip latency
HTTP response status code distribution

Langfuse Tracing

To trace LLM tool invocations with execution inputs, outputs, latencies, and metadata in Langfuse:

LANGFUSE_PUBLIC_KEY=pk-lf-...
LANGFUSE_SECRET_KEY=sk-lf-...
LANGFUSE_HOST=https://cloud.langfuse.com

LangSmith Tracing

To enable LangSmith / OpenTelemetry tracing:

LANGSMITH_API_KEY=lsv2_pt_...
LANGSMITH_PROJECT=toucan-payments-mcp
LANGCHAIN_TRACING_V2=true

Docker & Containerized Deployment

Deploy the MCP server alongside Prometheus and Grafana with a single command:

docker compose up -d

Exposed Endpoints:

Toucan MCP Server: http://localhost:8000/sse (Health: http://localhost:8000/health, Metrics: http://localhost:8000/metrics)
Prometheus UI: http://localhost:9091
Grafana Dashboard: http://localhost:3000 (User: admin, Password: admin)

Configuration Reference

All settings can be specified via environment variables or inside .env:

| Variable | Type | Default | Description | |:---|:---|:---|:---| | TOUCAN_ENV | string | uat | Gateway environment (uat or prod) | | TOUCAN_ACCESS_TOKEN | string | None | Bearer authentication token | | TOUCAN_MERCHANT_BASE_URL | string | https://merchant.testtoucanpay.in | Merchant terminal API base URL | | TOUCAN_PAY_BASE_URL | string | https://pay.testtoucanpay.in | Check status API base URL | | TOUCAN_MERCHANT_NUMBER | string | 479487461200974 | 15-digit merchant account number | | TOUCAN_TERMINAL_NUMBER | string | 81457699 | Mapped terminal number | | TOUCAN_TERMINAL_MODEL_KEY| string | 698eca3189da3511a664ff0c | Terminal model key | | TOUCAN_MERCHANT_MODEL_KEY| string | 6926c8df4c8cc605d6e7141a | Merchant model key | | TOUCAN_MERCHANT_NAME | string | Mobility | Merchant display brand name | | MCP_TRANSPORT | string | stdio | Transport protocol (stdio, sse, streamable-http) | | MCP_HOST | string | 0.0.0.0 | Host interface for HTTP binding | | MCP_PORT | int | 8000 | Port for HTTP/SSE binding | | PROMETHEUS_ENABLED | bool | true | Enable Prometheus metrics exporter | | PROMETHEUS_PORT | int | 9090 | Prometheus scrape port in stdio mode |

Testing

Run the automated test suite with pytest:

pytest -v
