ts-route-openapi

Generate an OpenAPI 3.0.3 spec from a TypeScript route→controller codebase by statically analyzing the source with ts-morph — no runtime instrumentation, decorators, JSDoc, or annotations required.

Your route registrations and TypeScript types are the documentation:

// users.controller.ts
export interface CreateUserInput {
  name: string;
  age?: number;
}

export class UsersController {
  static getById(id: string): { id: string; name: string } { /* ... */ }
  static create(input: CreateUserInput): Promise<{ ok: boolean }> { /* ... */ }
}

// bootstrap.ts
app.get('/users/:id', UsersController.getById);
app.post('/users', UsersController.create);

npx ts-route-openapi tsconfig.json -o openapi.yaml -f yaml

openapi: 3.0.3
paths:
  /users/{id}:
    get:
      parameters:
        - name: id
          in: path
          required: true
          schema: { type: string }
      responses:
        "200":
          content:
            application/json:
              schema:
                type: object
                properties: { id: { type: string }, name: { type: string } }
                required: [id, name]
  /users:
    post:
      requestBody:
        content:
          application/json:
            schema: { $ref: "#/components/schemas/CreateUserInput" }
      # ...
components:
  schemas:
    CreateUserInput:
      type: object
      properties: { name: { type: string }, age: { type: number } }
      required: [name]

Install

npm install --save-dev ts-route-openapi

CLI usage

npx ts-route-openapi [tsconfig] -o openapi.json -f json --title "My API" --api-version 1.0.0
npx ts-route-openapi [tsconfig] -o openapi.yaml -f yaml --watch

| Flag | Default | Description | | ------------------------- | --------------- | ------------------------------------- | | [tsconfig] (positional) | tsconfig.json | Path to the project's tsconfig.json | | -o, --out <file> | openapi.json | Output file path | | -f, --format <fmt> | json | Output format: json or yaml | | --title <title> | API | Spec info.title | | --api-version <version> | 1.0.0 | Spec info.version | | --descriptions | off | Include JSDoc summaries, descriptions, deprecation, and property descriptions | | -w, --watch | off | Regenerate when project source files change |

Programmatic usage

import { generate } from 'ts-route-openapi';

const doc = generate(
  'path/to/tsconfig.json',
  { title: 'My API', version: '1.0.0' },
  { descriptions: true },
);

How it works

The tool loads your project via its tsconfig.json and discovers routes three ways:

1. Registration call-sites — any call of the shape something.<verb>('/path', handler) where <verb> is one of get, post, put, patch, delete and the first argument is a string literal. The handler can be a controller method reference (UsersController.getById), an inline arrow function, or an identifier pointing at a function.
2. NestJS decorators — @Controller('base') classes with @Get/@Post/@Put/@Patch/@Delete methods.
3. tRPC routers — router({...}) / t.router({...}) procedure maps, including nested sub-routers. Each .query()/.mutation() procedure is exposed as a synthetic GET/POST <base>/<dotted.path> route (default base /trpc, configurable via generate()'s trpc.basePath option).

It then uses the TypeScript type checker on the handler to extract parameter and return types. Your registrations are the single source of truth — nothing to keep in sync.

Framework support

| Framework | Types read from | | --- | --- | | Express | Request<Params, ResBody, ReqBody, Query> and Response<T> generics | | Fastify | FastifyRequest<{ Params; Body; Querystring; Reply }> route generic + handler return type; route schema.body / schema.querystring / schema.params from Zod or JSON-schema object literals | | NestJS | @Param('x')/@Query('x')/@Body() decorated, typed method params + return type | | Hono | TypedResponse<T> from c.json(...) return types; path params from :tokens; zValidator('json' | 'query', schema) for Zod request schemas | | Koa (+ @koa/router) | paths and :token params only (ctx carries no static route types) | | tRPC | .input(zodSchema) for the request (query param for queries, body for mutations); .output(zodSchema) or the resolver's return type for the response | | Anything else | plain-typed handlers via the classification convention below; unknown framework objects fall back to :token string params |

A registered route always makes it into the spec: when no types are recognizable the tool documents the path and its :token params as strings rather than dropping the route.

Parameter classification convention (plain typed handlers)

For each handler parameter, in declaration order:

1. Path params — any parameter whose name matches a :token in the route path (e.g. id in /users/:id) is classified as a path parameter.
2. Body — the first remaining parameter that is object-typed (and not an array) is classified as the request body.
3. Query — every other remaining parameter is classified as a query parameter.

Response

The handler's return type is used as the schema for the 200 response, unwrapping Promise<T> to T when present.

Schema mapping

• Primitives (string, number, boolean), arrays, and nested objects map to their OpenAPI equivalents; optional properties (?) are omitted from required.
• String-literal unions ('a' | 'b') map to enum; numeric-literal unions to a number enum; other unions map to oneOf (discriminated object unions become oneOf over $refs). null/undefined members are stripped.
• Date maps to { type: string, format: date-time }.
• Callable-typed properties (functions, methods) map to { description: 'Function: <signature text>' } instead of an empty schema — e.g. onSave: (id: string) => void becomes { description: 'Function: (id: string) => void' }. A property's own JSDoc (when --descriptions is enabled) overrides the signature text.
• Named interface/class/type alias declarations from your project are hoisted into components.schemas and referenced via $ref (recursive types self-reference); library/node_modules types are inlined.
• Zod validator schemas in Hono and Fastify route metadata map common builders (object, string, number, boolean, array, enum, optional, nullable, literal, and literal unions). Unsupported constructs degrade to {} with a stderr note.
• When --descriptions is enabled, handler JSDoc adds operation summary/description, @deprecated marks operations deprecated, and property JSDoc becomes schema property description.

Security config

Add ts-route-openapi.config.json next to your tsconfig.json to emit OpenAPI security metadata:

{
  "securitySchemes": {
    "bearerAuth": { "type": "http", "scheme": "bearer" },
    "apiKeyAuth": { "type": "apiKey", "in": "header", "name": "x-api-key" }
  },
  "security": [{ "bearerAuth": [] }],
  "securityOverrides": [
    { "method": "GET", "path": "/health", "security": [] },
    { "path": "/public/**", "security": [] }
  ],
  "publicDecorator": "Public"
}

securitySchemes is copied to components.securitySchemes; security is applied to every operation unless a securityOverrides entry matches the route verb and glob path. For NestJS, @Public() on a class or method drops the default security when publicDecorator is set.

Examples

Runnable, idiomatic Express, Fastify, NestJS, Hono, Koa, tRPC, and framework-free examples — each with its generated openapi.yaml committed — live in examples/. No adapters or code changes: install, run the CLI, get the spec.

Contributing

Planning work lives in the ts-route-openapi Plan GitHub Project, not long-lived plan documents in the repository. The main branch is protected; send changes through pull requests and keep review threads resolved before merging.

See CONTRIBUTING.md for the full workflow.

Limitations

• Status codes are detected, not exhaustive: res.status(N) / reply.code(N) / @HttpCode(N) produce per-status responses. throw new X(...) is also detected when X is a NestJS built-in HttpException subclass (by name), a generic HttpException(_, status), or a local class whose own or inherited status/statusCode property is a numeric literal. Express's app.use((err, req, res, next) => ...) error-handling middleware contributes its res.status(N) calls to every route registered on the same app/router instance, whether or not the middleware lives in the same file. Statuses set any other way — resolved dynamically, thrown from a re-exported third-party exception class, or set by middleware on a router mounted into the app (app.use('/prefix', router)) rather than the app instance itself — are not seen.
• Callable types (functions, methods) map to a schema-less { description: 'Function: <signature text>' } (overridden by the property's own JSDoc when present) rather than being hoisted like an object type. An overloaded callable's description joins every signature with |.

License

MIT
